2 Deck showers USA The Saturn family grows. Discover all the new finishes at www.OSCULATI.com Code 15.470.xx DISCOVER MORE Saturn shower y grows Discover all the new finishes at www One hand shower, 3 different styles. Deck Shower
3 Deck showers USA Saturn shower with integrated hot/cold water mixer REGISTERED DESIGN HOT & COLD Shower with built-in mixer. Flat hidden design. Horizontal or vertical mounting. Shower housing fitted with anti-vibration washer. Hot and cold water setting through rotation of the shower body. Water flow regulation by a push lock button that allows to block the water jet and avoid waste. Built-in mixer for precise temperature setting and maintaining between openings. Oversize head and delicate water jet Chromed brass body for strength and durability Braided nylon hose for maximum flexibility \ Video Code Mounting Base material Base color Type of fastening Minimum internal space Flange diameter Hose m OPTIONAL carbon fiber shower rod 15.470.01 Horizontal ABS plastic white Locknut 230 84 4 15.480.29 15.470.02 Horizontal ABS plastic chromed Locknut 230 84 4 15.480.29 15.470.04 Horizontal ABS plastic Black Locknut 230 84 4 15.480.29 15.470.11 Vertical ABS plastic white Bonding 160 120 4 15.480.29 15.470.12 Vertical ABS plastic chromed Bonding 160 120 4 15.480.29 15.470.13 Vertical Stainless steel Glossy Studs 160 140 4 15.480.29 15.470.14 Vertical ABS plastic Black Bonding 160 120 4 15.480.29 \ 15.470.01 \ 15.471.01 \ 15.470.11 \ 15.471.11 \ 15.470.02 \ 15.471.02 \ 15.470.12 \ 15.471.12 \ 15.471.13 \ 15.480.29 \ 15.470.14 Saturn cold-water shower REGISTERED DESIGN / DISEGNO DEPOSITATO ONLY COLD Flat hidden design. Horizontal or vertical mounting. Shower housing fitted with anti-vibration washer. The flow is adjusted by touching a push lock button that blocks the water jet and prevents waste. \ 15.471.01 \ 15.471.12 Code Mounting Base material Base color Type of fastening Minimum internal space Flange diameter Hose m OPTIONAL carbon fiber shower rod 15.471.01 Horizontal ABS plastic white Locknut 230 84 4 15.480.29 15.471.02 Horizontal ABS plastic Chrome Grey Locknut 230 84 4 15.480.29 15.471.04 Horizontal ABS plastic Black Locknut 230 84 4 15.480.29 15.471.11 Vertical ABS plastic white Bonding 160 120 4 15.480.29 15.471.12 Vertical ABS plastic Chrome Grey Bonding 160 120 4 15.480.29 15.471.13 Vertical Stainless steel Glossy Studs 160 140 4 15.480.29 15.471.14 Vertical ABS plastic Black Bonding 160 120 4 15.480.29
4 Deck showers USA Classic Evo deck shower with Tiger stainless steel shower head Stainless steel shower head, UV-resistant ASA white housing. White door RETAIL (1pc) White door BULK (10pcs) Stainless steel door RETAIL (1 pc) mm Pipe in Hose m recess outer dimensions 15.163.00 15.163.00BU 15.163.70 Ø70x44 Ø95 Net PVC 2.5 15.163.01 15.163.01BU 15.163.71 Ø70x44 Ø95 Net PVC 4 15.163.30 15.163.30BU 15.163.80 Ø70x44 Ø95 SS 2.5 15.163.31 15.163.31BU 15.163.81 Ø70x44 Ø95 SS 4 15.163.60 15.163.60BU 15.163.90 Ø70x44 Ø95 White nylon 2.5 15.163.61 15.163.61BU 15.163.91 Ø70x44 Ø95 White nylon 4 15.290.55Hose bag (option) \ 15.163.00/01 \ 15.163.80/81 \ Net PVC \ White nylon \ Stainless steel \ 15.163.00/01/60/61 \ 15.163.70/71/80/81/90/91
5 Deck showers USA New Edge deck shower with Tiger stainless steel shower head Stainless steel shower head, UV-resistant ASA white housing. White door RETAIL (1pc) White door BULK (10pcs) Stainless steel door RETAIL (1 pc) mm Pipe in Hose m recess outer dimensions 15.164.00 15.164.00BU 15.164.70 Ø70x40.5 88x95 Net PVC 2.5 15.164.01 15.164.01BU 15.164.71 Ø70x40.5 88x95 Net PVC 4 15.164.30 15.164.30BU 15.164.80 Ø70x40.5 88x95 SS 2.5 15.164.31 15.164.31BU 15.164.81 Ø70x40.5 88x95 SS 4 15.164.60 15.164.60BU 15.164.90 Ø70x40.5 88x95 White nylon 2.5 15.164.61 15.164.61BU 15.164.91 Ø70x40.5 88x95 White nylon 4 15.290.55Hose bag (option) \ 15.164.00/01 \ 15.164.80/81 \ 15.164.00/01/60/61 \ 15.164.70/71/80/81/90/91 \ White nylon \ Net PVC \ Stainless steel Classic Evo deck shower with Mizar push-button shower Chromed brass shower head, UV-resistant ASA white housing. White door RETAIL (1pc) White door BULK (10pcs) Chromed door RETAIL (1 pc) Chromed Door BULK (10pcs) Stainless steel door RETAIL (1 pc) mm Pipe in Hose m recess outer dimensions 15.250.00 15.250.00BU 15.250.06 15.250.06BU 15.250.70 Ø70x44 Ø95 Net PVC 2.5 15.250.01 15.250.01BU 15.250.07 15.250.07BU 15.250.71 Ø70x44 Ø95 Net PVC 4 - - 15.150.06 15.150.06BU 15.250.80 Ø70x44 Ø95 SS 2.5 - - 15.150.07 15.150.07BU 15.250.81 Ø70x44 Ø95 SS 4 15.250.60 15.250.60BU - - 15.250.90 Ø70x44 Ø95 White nylon 2.5 15.250.61 15.250.61BU - - 15.250.91 Ø70x44 Ø95 White nylon 4 15.290.55Hose bag (option) \ 15.250.00/01 \ 15.150.06/07 \ 15.250.70/71 \ Stainless steel \ 15.250.00/01/60/61 \ White nylon \ 15.250.06/07; 15.150.06/07 \ 15.250.70/71/80/81/90/91 \ Net PVC New Edge deck shower with Mizar push-button shower Chromed brass shower head, UV-resistant ASA white housing. White door RETAIL (1pc) White door BULK (10pcs) Chromed door RETAIL (1 pc) Chromed Door BULK (10pcs) Stainless steel door RETAIL (1 pc) mm Pipe in Hose m recess outer dimensions 15.243.00 15.243.00BU 15.243.06 15.243.06BU 15.243.70 Ø70x40.5 88x95 Net PVC 2.5 15.243.01 15.243.01BU 15.243.07 15.243.07BU 15.243.71 Ø70x40.5 88x95 Net PVC 4 - - 15.143.06 15.143.06BU 15.243.80 Ø70x40.5 88x95 SS 2.5 - - 15.143.07 15.143.07BU 15.243.81 Ø70x40.5 88x95 SS 4 15.243.60 15.243.60BU - - 15.243.90 Ø70x40.5 88x95 White nylon 2.5 15.243.61 15.243.61BU - - 15.243.91 Ø70x40.5 88x95 White nylon 4 15.290.55Hose bag (option) \ 15.243.00/01 \ 15.243.06/07 \ 15.243.70/71 \ 15.243.00/01/60/61 \ 15.243.06/07; 15.143.xx \ 15.243.70/71/80/81/90/91
6 Deck showers USA New Edge deck shower with Boris shower head Plastic shower head with chromed head, UV-resistant ASA housing. White door with white compartment RETAIL (1 pc) White door with white compartment BULK (10 pcs) Chromed door with white compartment RETAIL (1 pc) Chrome door with white compartment BULK (10 pcs) Stainless steel door with white compartment RETAIL (1 pc) Black door with black compartment RETAIL (1 pc) mm Pipe in Hose m recess outer dimensions 15.248.00 15.248.00BU 15.248.06 15.248.06BU 15.248.70 15.248.56 Ø70x40.5 88x95 Net PVC 2.5 15.248.01 15.248.01BU 15.248.07 15.248.07BU 15.248.71 15.248.57 Ø70x40.5 88x95 Net PVC 4 - - 15.148.06 15.148.06BU 15.248.80 - Ø70x40.5 88x95 SS 2.5 - - 15.148.07 15.148.07BU 15.248.81 - Ø70x40.5 88x95 SS 4 15.248.60 15.248.60BU - - 15.248.90 - Ø70x40.5 88x95 White nylon 2.5 15.248.61 15.248.61BU - - 15.248.91 - Ø70x40.5 88x95 White nylon 4 \ 15.248.00/01 \ 15.148.06/07 \ 15.248.70/71 \ 15.248.56 \ 15.248.00/01/60/61 \ 15.248.06/07; 15.148.xx \ 15.248.7x/8x/9x \ 15.248.56/57 New Edge deck shower with Niagara shower head Chromed ABS shower head with, UV-resistant ASA white housing. White door RETAIL (1pc) White door BULK (10pcs) Chromed door RETAIL (1 pc) mm Pipe in Hose m recess outer dimensions 15.160.01 15.160.01BU 15.160.20 Ø70x40.5 88x95 Net PVC 2.5 15.160.02 15.160.02BU 15.160.21 Ø70x40.5 88x95 Net PVC 4 15.160.30 15.160.30BU 15.160.50 Ø70x40.5 88x95 SS 2.5 15.160.31 15.160.31BU 15.160.51 Ø70x40.5 88x95 SS 4 15.160.60 15.160.60BU - Ø70x40.5 88x95 White nylon 2.5 15.160.61 15.160.61BU - Ø70x40.5 88x95 White nylon 4 15.290.55Hose bag (option) \ 15.160.01/02 \ 15.160.50/51 \ 15.160.0x/3x/6x \ 15.160.2x/5x
7 Deck showers USA Nuvola deck shower with Keji shower head STAINLESS LOOK REGISTERED DESIGN Housing with AISI316 stainless steel insert. Inclined at 45° for flat or vertical mounting. Fitted with Keji oversized shower head and anti-limescale sprayer. Equipped with Keji shower with oversized head and anti-limescale sprayers. Code RETAIL (1pcs) mm Pipe in Hose m Recess hole outer dimensions 15.275.01 90x70 120x100 Net PVC 2.5 15.275.02 90x70 120x100 Net PVC 4 15.275.11 90x70 120x100 SS 2.5 15.275.12 90x70 120x100 SS 4 15.275.21 90x70 120x100 White nylon 2.5 15.275.22 90x70 120x100 White nylon 4 \ 15.275.01/02 \ 15.275.11/12
8 Deck showers USA \ 15.303.00/01 \ 15.303.30/31 Elissa deck shower with Tiger shower head AISI 316 AISI316 stainless steel housing with self-supporting lid. Fitted with Tiger stainless steel shower head and inside anti-vibration rubber washer. Code RETAIL (1pcs) mm Pipe in Hose m Recess hole outer dimensions 15.303.00 90x70 118x97 Net PVC 2.5 15.303.01 90x70 118x97 Net PVC 4 15.303.30 90x70 118x97 SS 2.5 15.303.31 90x70 118x97 SS 4 15.303.60 90x70 118x97 White nylon 2.5 15.303.61 90x70 118x97 White nylon 4 \ 15.304.00/01 \ 15.304.30/31 Elissa deck shower with Keji shower head AISI 316 REGISTERED DESIGN AISI316 stainless steel shower housing with self-supporting lid. Fitted with Keji overdimensioned shower head and inside anti-vibration rubber washer. Code RETAIL (1pcs) mm Pipe in Hose m Recess hole outer dimensions 15.304.00 90x70 118x97 Net PVC 2.5 15.304.01 90x70 118x97 Net PVC 4 15.304.30 90x70 118x97 SS 2.5 15.304.31 90x70 118x97 SS 4 15.304.60 90x70 118x97 White nylon 2.5 15.304.61 90x70 118x97 White nylon 4 \ 15.305.00/01 \ 15.305.30/31 Elissa deck shower with Keji II Continuum Flow shower head AISI 316 CONTINUUM FLOW REGISTERED DESIGN AISI316 stainless steel shower housing with self-supporting lid. Fitted with Keji II Continuum Flow overdimensioned shower head and inside anti-vibration rubber washer. Code RETAIL (1pcs) mm Pipe in Hose m Recess hole outer dimensions 15.305.00 90x70 118x97 Net PVC 2.5 15.305.01 90x70 118x97 Net PVC 4 15.305.30 90x70 118x97 SS 2.5 15.305.31 90x70 118x97 SS 4 15.305.60 90x70 118x97 White nylon 2.5 15.305.61 90x70 118x97 White nylon 4
9 Deck showers USA Deck shower with mixer Chromed brass tap with ceramic mixer. Recess-fit white UV-resistant ASA housing. white Type of compartment vano mm Hot/cold water mixer recess outer dimensions 17.239.10 New Edge Ø70x40.5 88x95 17.051.00 17.239.50 Classic EVO Ø70x44 Ø95 17.051.00 \ 17.239.10 \ 17.239.10 \ 17.239.50 \ 17.239.50 \ 17.239.50 Nuvola deck shower with mixer STAINLESS LOOK Chromed brass tap with ceramic mixer. ASA housing with AISI316 stainless steel insert. Code mm Recess hole External enclosure 15.239.60 90x70 120x100 Elissa deck shower with mixer AISI 316 AISI316 stainless steel housing with self-supporting lid. Fitted with cylindrical knob mixer. Code mm recess External enclosure 17.239.90 90x70x46 118x97 Bag for shower hose Convenient plastic-mesh bag made for the hose of the below-deck shower to prevent getting entangled in the other equipment and making it impossible to extract the shower head. Easy to fasten and adapt to all situations. Code To be used with shower boxes Mounting 15.290.55 Classic EVO single, horizontal mounting, Mizar shower: 15.250.00/01/06/07; 15.150.06/07; New Edge single, horizontal mounting, Mizar and Niagara shower: 15.243.00/01/06/07; 15.143.06/07; 15.160.xx; Double oval, Mizar shower: 15.240.01/02/30/31; 15.140.30/31; 15.241.01/02; New Edge double, Mizar shower: 15.257.01/02/30/31; 15.257.41/42. To be snapped in and/or glued 15.290.56 Classic EVO single, wall mounting, Mizar shower: 15.250.03/04/09/10; 15.150.09/10. To be screwed \ 15.290.55 \ 15.290.56 \ 15.290.55 \ 15.290.56
10 Deck showers USA Oval deck shower with Mizar mixer and push-button shower head Chromed brass shower and white UV-resistant ASA housing. Fitted with hot/cold water mixer. Flat or bulkhead mounting. White door RETAIL (1pc) White door BULK (10pcs) Chromed door RETAIL (1 pc) Chromed Door BULK (10pcs) mm Pipe in Hose m recess outer dimensions 15.240.01 15.240.01BU 15.240.30 15.240.30BU 150x80x40 185x131 Net PVC 2.5 15.240.02 15.240.02BU 15.240.31 15.240.31BU 150x80x40 185x131 Net PVC 4 - - 15.140.30 15.140.30BU 150x80x40 185x131 SS 2.5 - - 15.140.31 15.140.31BU 150x80x40 185x131 SS 4 15.240.60 - - - 150x80x40 185x131 White nylon 2.5 15.240.61 - - - 150x80x40 185x131 White nylon 4 15.290.55Hose bag (option) \ 15.240.01/02 \ 15.140.30/31 \ 15.240.0x/6x \ 15.240.3x; 15.140.3x \ Mizar shower head 15.242.02 \ White nylon \ Stainless steel \ Net PVC Oval shower box with mixer and push-button shower Desy Chromed plastic shower and white UV-resistant ASA housing. Fitted with hot/cold water mixer. Flat or bulkhead mounting. White door RETAIL (1pc) Chromed door RETAIL (1 pc) Chromed Door BULK (10pcs) mm Pipe in Hose m recess outer dimensions 15.240.20 15.240.33 15.240.33BU 150x80x40 185x131 Net PVC 2.5 15.240.21 15.240.34 15.240.34BU 150x80x40 185x131 Net PVC 4 15.290.55Hose bag (option) \ 15.240.20/21 \ 15.240.33/34 \ 15.240.2x \ 15.240.3x \ Desy deck shower 15.238.03 \ 15.240.2x
11 Deck showers USA New Edge deck shower with Mizar mixer and push-button shower head Chromed brass shower and white UV-resistant ASA housing. Fitted with hot/cold water mixer. Flat or bulkhead mounting. White door RETAIL (1pc) White door BULK (10pcs) Chromed door RETAIL (1 pc) Chromed Door BULK (10pcs) mm Pipe in Hose m recess outer dimensions 15.257.01 15.257.01BU 15.257.30 15.257.30BU 148x74x40 180x105 Net PVC 2.5 15.257.02 15.257.02BU 15.257.31 15.257.31BU 148x74x40 180x105 Net PVC 4 15.290.55Hose bag (option) \ 15.257.01/02 \ 15.257.30/31 \ Mizar shower head 15.242.02 \ 15.257.0x \ 15.257.3x New Edge deck shower with Boris mixer and push-button shower head Plastic shower with chromed head and white UV-resistant ASA housing. Fitted with hot/ cold water mixer. Flat or bulkhead mounting. White door RETAIL (1pc) White door BULK (10pcs) Chromed door RETAIL (1 pc) Chromed Door BULK (10pcs) mm Pipe in Hose m recess outer dimensions 15.257.20 15.257.20BU 15.257.33 15.257.33BU 148x74x40 180x105 Net PVC 2.5 15.257.21 15.257.21BU 15.257.34 15.257.34BU 148x74x40 180x105 Net PVC 4 15.158.20 15.158.20BU - - 148x74x40 180x105 SS 2.5 15.158.21 15.158.21BU - - 148x74x40 180x105 SS 4 15.257.60 15.257.60BU - - 148x74x40 180x105 White nylon 2.5 15.257.61 15.257.61BU - - 148x74x40 180x105 White nylon 4 \ 15.257.20/21 \ 15.257.33/34 \ Boris shower head 15.248.02 \ 15.257.3x \ 15.257.2x/6x; 15.158.2x
12 Deck showers USA Elissa deck shower with Tiger mixer and shower head AISI 316 AISI316 stainless steel housing with self-supporting/soft-close lid. Fitted with Tiger stainless steel shower head and inside anti-vibration washer. Mixer with cylindrical knob. Code mm Pipe in Hose m outer dimensions Recess hole 15.323.00 175x105 152.5x77 Net PVC 2.5 15.323.01 175x105 152.5x77 Net PVC 4 15.323.30 175x105 152.5x77 SS 2.5 15.323.31 175x105 152.5x77 SS 4 15.323.60 175x105 152.5x77 White nylon 2.5 15.323.61 175x105 152.5x77 White nylon 4 Elissa deck shower with Keji mixer and shower head AISI 316 REGISTERED DESIGN AISI316 stainless steel housing with self-supporting/soft-close lid. Fitted with Keji chromed plastic shower head with oversized head. Inside anti-vibration washer. Mixer with cylindrical knob. Code mm Pipe in Hose m outer dimensions Recess hole 15.324.00 175x105 152.5x77 Net PVC 2.5 15.324.01 175x105 152.5x77 Net PVC 4 15.324.30 175x105 152.5x77 SS 2.5 15.324.31 175x105 152.5x77 SS 4 15.324.60 175x105 152.5x77 White nylon 2.5 15.324.61 175x105 152.5x77 White nylon 4 Elissa deck shower with Keji II Continuum Flow mixer and shower head AISI 316 CONTINUUM FLOW REGISTERED DESIGN AISI316 stainless steel shower housing with soft-close self-supporting lid. Fitted with Keji II Continuum Flow chromed brass overdimensioned shower head and inside anti-vibration washer. Cylinder knob mixer. Ideal in combination with Rocky pole 15.480.20. Code mm Pipe in Hose m outer dimensions Recess hole 15.325.00 175x105 152.5x77 Net PVC 2.5 15.325.01 175x105 152.5x77 Net PVC 4 15.325.30 175x105 152.5x77 SS 2.5 15.325.31 175x105 152.5x77 SS 4 15.325.60 175x105 152.5x77 White nylon 2.5 15.325.61 175x105 152.5x77 White nylon 4
13 Deck showers USA Adriana recess-fit deck shower Deck shower for deluxe boats. Fitted with a large Bossini adjustable jet shower head with cold/hot water mixer. UV-resistant ASA housing. The shower head is easy to pull out and also works as cover. No lid for easier use and to prevent the tube to get stuck and damaged. Code Finish mm Pipe in Hose m Compartment shower head recess outer dimensions 15.480.00 White ASA Chromed 132x271 162x303 SS 4 Rocky shower telescopic rod for outdoor purposes This rod makes it possible to have a shower head on the stern gangplank. Made of black anodized aluminum + stainless steel accessories. Allows the shower to be oriented in all directions and heights. Lightweight and telescopic for easy storage, rod outer diameter 35 mm (order 34.355.00 for bulkhead stowage). Ideal to match Adriana deck shower 15.480.00 or Keji II Continuum Flow 15.237.06. Code Version For showers Type Description 15.480.21 Without lid - Standard Base Recessed stainless steel + POM bushing 15.480.26 With lid - Delux Base Flush with sliding cover, POM bushing and countersunk screws 15.480.20 Aluminium Generic Rod Universal shower rod in black anodized aluminium 15.480.28 Carbon Generic Rod Universal carbon shower rod 15.480.29 Carbon Saturn type 15.470. xx Rod Carbon shower rod only for Saturn shower 15.470.xx \ 15.480.21 \ 15.480.21 \ 15.480.26 \ 15.480.26 \ 15.480.26 \ 15.480.20 \ 15.480.20 \ 15.480.29 \ 15.480.20
14 Deck water outlets USA \ 16.441.18 \ 16.441.38 \ 16.441.88 \ 16.441.18 New Edge quick-coupling washdown hose connector It connects the onboard fresh water system or to the washdown salt water pump and it keeps the line under pressure. The washing hose plugs in onto the inlet and automatically activates the pump. UV resistant ASA box, chromed brass device. white chromed SS mm Ø Recess Internal protrusion 16.441.18 16.441.38 16.441.88 69 50 17.224.01 OPTIONAL 1/2” male elbow fitting to plug into rear inlet hose 36.189.01; 36.189.03; 36.189.04 OPTIONAL Front male plug-in fitting \ 16.441.88 \ 16.441.38 \ 16.441.55 \ 16.441.55 \ 16.441.95 \ 16.441.75 Classic EVO quick-coupling washdown hose connector It connects the onboard fresh water system or to the washdown salt water pump and it keeps the line under pressure. The washing hose plugs in onto the inlet and automatically activates the pump. UV resistant ASA box, chromed brass device. white chromed SS mm Ø Recess Internal protrusion 16.441.55 16.441.75 16.441.95 69 43 17.224.01 OPTIONAL 1/2” male elbow fitting to plug into rear inlet hose 36.189.01; 36.189.03; 36.189.04 OPTIONAL Front male plug-in fitting \ 16.441.95 Nuvola quick-coupling hose connector for deck washdown STAINLESS LOOK It connects to the onboard (fresh) water system or to the (salt water) washdown pump and keep the line under pressure. The washing tube snaps into the hose connector and automatically activates the pump. UV-resistant ASA housing with AISI316 stainless steel insert, chromed brass mechanism. Code mm Recess hole Internal projection 16.444.00 90x70 52.5 17.224.01 OPTIONAL 1/2” male elbow fitting to plug into rear inlet hose 36.189.01; 36.189.03; 36.189.04 OPTIONAL Front male plug-in fitting
15 Deck water outlets USA Elissa quick fitting hose connector for deck washdown AISI 316 It connects to the onboard water system (fresh water) or to the washdown pump (salt water) and keeps the line under pressure. The washing tube snaps into the plug and automatically activates the pump. AISI316 stainless steel compartment, self-supporting hatch. Code mm Recess hole Internal projection 16.443.00 90x70 50 Bayonet flush fitting for washdown The device connects under deck to Washdown pumps or similar items and it keeps the pump under pressure. When the bayonet fitting connects the washing hose, the device automatically opens and activates the pump. 100% stainless steel. Garden-type quick fitting on the end caps (36.189.02). Code Description Replacement plastic fitting 16.442.22 Bayonet fitting + straight plastic fitting 16.442.31 (right) 16.442.23 Bayonet fitting + sloped plastic fitting 16.442.30 (inclined) The sloped fitting makes opening easier in case of high-pressure washdown pumps or when the fitting is in a position difficult to plug. \ 16.442.31 \ 16.442.31 \ 16.442.30 \ 16.442.22 + 16.442.31 \ 16.442.23 + 16.442.30
16 Deck water inlets USA \ 16.445.34 Heavy Duty New Edge recess-fit hose connector for fresh water QUICK SWIVEL CONNECTION PRESSURE REDUCING VALVE For the use of dockside water, this innovative system stably reduces the pressure to 3 bar, protecting the piping from potential damage. The compact device, equipped with an adjustable pressure regulator and orientable brass check valve, ensures a safe and constant flow. The dockside water hose can be easily connected using a gardening snap fitting (code 36.189.02). The outlet thread is 3/4" BSP. Even if the system remains connected to the dock, the pressure is maintained stable at 3 bar, regardless of the supply network pressure. white chromed SS mm Ø Recess Internal protrusion 16.445.14 16.445.34 16.445.84 69 110-110 \ 16.445.14 \ 16.445.84 \ 16.445.53 Heavy Duty Classic Evo recess-fit fresh water inlet QUICK SWIVEL CONNECTION PRESSURE REDUCING VALVE For the use of dockside water, this innovative system stably reduces the pressure to 3 bar, protecting the piping from potential damage. The compact device, equipped with an adjustable pressure regulator and orientable brass check valve, ensures a safe and constant flow. The dockside water hose can be easily connected using a gardening snap fitting (code 36.189.02). The outlet thread is 3/4" BSP. Even if the system remains connected to the dock, the pressure is maintained stable at 3 bar, regardless of the supply network pressure. white chromed SS mm Ø Recess Internal protrusion 16.445.53 16.445.73 16.445.83 69 110-110 \ 16.445.73 \ 16.445.83 Elissa hose connector for fresh water AISI 316 QUICK SWIVEL CONNECTION PRESSURE REDUCING VALVE For the use of dockside water, this innovative system stably reduces the pressure to 3 bar, protecting the piping from potential damage. The compact device, equipped with an adjustable pressure regulator and orientable brass check valve, ensures a safe and constant flow. The dockside water hose can be easily connected using a gardening snap fitting (code 36.189.02). The outlet thread is 3/4" BSP. Even if the system remains connected to the dock, the pressure is maintained stable at 3 bar, regardless of the supply network pressure. Code mm Recess hole Internal projection 16.443.20 90x70 110-110
17 Faucets USA
18 Faucets USA \ 17.046.02 \ 17.047.02 \ 17.046.03 Slide series Made of chromed brass. It can be mounted inside the sink for a flat design countertop. Code Function Knob Hose adaptor 17.046.02 Cold water Italy 3/8" male 17.046.03 Cold water Italy 3/8" male 17.047.02 Hot + cold water Italy 2 x 3/8" male \ 17.046.02 \ 17.047.02 \ 17.046.03 Folding spout with flow restrictor Rotating and folding chromed brass spout. It can be mounted inside the sink for a flat design countertop. Code Function Knob Hose adaptor 17.046.40 Cold water no 3/8" male \ 17.051.01 \ 17.048.00 \ 17.051.06 \ 17.051.00 Shower series Ideal for indoor/outdoor showers, fitted with 3 x lower connection hoses made of stainless steel sheath. Code Function Handle Base Ø mm Overhang mm Mounting neck 17.048.00 Hot/cold water mixer Round 42 45 32-mm Ø + 37-mm long 17.051.00 Hot/cold water mixer T 42 45 32-mm Ø + 37-mm long 17.051.01 Hot/cold water mixer Oval 42 45 32-mm Ø + 37-mm long 17.051.06 Hot/cold water mixer Slim 42 45 32-mm Ø + 37-mm long
19 Faucets USA Style series Made of chromed brass. It can be mounted inside the sink for a flat design countertop. Code Function Knob Hose adaptor 17.046.20 Cold water Italy 3/8" male 17.046.22 Hot + cold water Italy 2 x 3/8" male \ 17.046.22 \ 17.046.20 \ 17.046.22 \ 17.046.20 Slim series In chromed brass. Can be mounted inside the sink to achieve a completely smooth surface. Possibility of installation on a vertical wall. Code Function Knob Mixer in Hose adaptor 17.046.06 Cold water Slim - 3/8" male 17.049.06 Hot/cold water mixer Slim Ceramic - 17.049.05 Hot/cold water mixer Slim Ceramic - \ 17.049.06 \ 17.049.05 \ 17.046.06 \ 17.046.06 \ 17.049.05 \ 17.049.06 \ 17.049.05/06 Wheel double-connection series Made of chromed brass. It can be mounted inside the sink for a flat design countertop. Code Function Knob Mixer in 17.049.10 Hot/cold water mixer Slim Ceramic
20 Bow rollers and anchors accessories USA \ 01.120.07/10/15/20 \ 01.121.07/10/20 \ 01.120.xx \ 01.121.xx Bow roller + Trefoil® anchor with anti-water plate AISI 316 SELF LAUNCHING Bow roller for anchor with coupling plate for perfect closure of the hull hole. This system makes the plate strike against the roller preventing water from leaking into the forepeak. The roller is designed to match the Trefoil anchor for a combination of high-level products in style and performance. The system can be easily installed by 4 studs behind the roller and is fitted with two sheaves for smooth sliding of the chain. Entirely made of mirror-polished AISI 316 stainless steel. It is recommended to install it on the chain by means of the Twist joint 01.738.01. Windlass ideal pull angle at 5° / 20° from the roller horizontal axis. Code Description mm MatchingA B C D 01.120.07 Trefoil anchor 7.5 kg 535 230 352 - 7.5 01.121.07 01.120.10 Trefoil anchor 10 kg 588 331 383 - 10 01.121.10 01.120.15 Trefoil anchor 15 kg 650 348 430 - 15 01.121.10 01.120.20 Trefoil anchor 20 kg 702 370 468 - 20 01.121.20 01.121.07 Bow roller 7.5 kg 150 168 232 322 6.3 01.120.07 01.121.10 Bow roller 10 kg 117 203 279 305 9.3 01.120.10/15 01.121.20 Bow roller 20 kg 206 224 270 254 12.6 01.120.20 \ Video
21 Bow rollers and anchors accessories USA Mr. Fantastic extendable roller EXTENDABLE IDEAL FOR VERTICAL BOW SELF LAUNCHING Made from mirror-polished stainless steel, ideal for Trefoil anchors or similar. It is equipped with an innovative system with gas springs that allows the anchor to move away from the bow before being lowered. Simultaneously, a tilting motion enables the automatic drop of the anchor, maintaining a safe distance from the bow. Its lightweight and sports shape is well-suited to the hull and its steel frame is designed to withstand high loads. Code For anchors kg Extension mm A mm B mm C mm D mm Ø mm Plate thickness mm Version 01.338.07 7.5 - 10 130 468 357 120 228 8.4 5 Mirror-polished 01.338.15 10 - 15 200 625 480 120 270 10.4 5 Mirror-polished 01.338.30 20 - 30 220 750 600 140 310 10.4 8 Electropolished \ Video
22 Bow rollers and anchors accessories USA Twist joint still turns AISI 316 PATENT Made of mirror-polished AISI316 stainless steel. With the latest asymmetric anchors (Bruce, Delta, Trefoil® etc.), when the anchor is raised, it most probably turns the wrong side. The Twist swivelling connector turns the anchor correctly and it reeves into the roller or hawsehole. A shackle connects the fixed eye to the anchor. Code Chain Ø mm Connecting shackle A mm B mm C mm 01.738.01 6/8 01.080.10 220 60 28 01.738.02 10/12 01.080.10/12/14 320 83 38 Chain Rainbow marker PATENT METS NOMINATION 2003 Coloured plastic inserts for fitting into chain links. Sold in kits for marking 25 cm of calibrated chain. Insert colours For calibrated chain Ø mm No of inserts white blue yellow red Green 01.500.06BI 01.500.06BL 01.500.06GI 01.500.06RO 01.500.06VE 6 14 01.500.08BI 01.500.08BL 01.500.08GI 01.500.08RO 01.500.08VE 8 10 01.500.10BI 01.500.10BL 01.500.10GI 01.500.10RO 01.500.10VE 10 8 01.500.12BI 01.500.12BL 01.500.12GI 01.500.12RO 01.500.12VE 12 8 Chain Rainbow marker kit, assorted colours PATENT METS NOMINATION 2003 Assorted pack of Chain Rainbow sufficient to mark an entire length of calibrated chain. The kit consists of 5 colours (white, blue, yellow, red, and green). Code For calibrated chain Ø mm Number of inserts 01.501.06 6 70 01.501.08 8 50 01.501.10 10 40 01.501.12 12 40 \ 01.500.xx \ 01.501.xx
23 Navigation Lights USA Nemo navigation lights up to 20 m, RINA type-tested Nemo LED navigation lights for vertical mounting LED AISI 316 Black polycarbonate body and mirror-polished AISI316 stainless steel case. Easy to install on both the hull and the deck. RINA type-approved in compliance with the COLREG72 regulations. For vessels up to 20 metres with visibility not exceeding 2NM. RETAIL Bulk 6 pairs Content Light colour Visibility NM V W 11.470.01 11.470.01BU Couple of lights 112.5° left + 112.5° right 2 12 0.4+0.4 11.470.04 11.470.04BU Single light 135° stern 2 12 0.4 \ 11.470.01/01BU \ 11.470.04/04BU \ 11.470.01/01BU \ 11.470.01/01BU \ 11.470.04/04BU Nemo LED navigation lights for recess mounting LED AISI 316 Black polycarbonate body and mirror-polished AISI316 stainless steel case. Easy to install on both the hull and the deck. For optimal orientation of the light sector, it is recommended to mount on a surface angled at about 22° relative to the bow axis. RINA type-approved in compliance with the COLREG72 regulations. For vessels up to 20 metres with visibility not exceeding 2NM. RETAIL Bulk 6 pair Content Light colour Visibility NM V W 11.473.01 11.473.01BU Couple of lights 112.5° left + 112.5° right 2 12 0.4+0.4 Nemo LED navigation lights for horizontal mounting LED AISI 316 Black polycarbonate body and mirror-polished AISI316 stainless steel case. Easy to install on both the hull and the deck. RINA type-approved in compliance with the COLREG72 regulations. For vessels up to 20 metres with visibility not exceeding 2NM. RETAIL Bulk 6 pairs Content Light colour Visibility NM V W 11.480.01 11.480.01BU Couple of lights 112.5° left + 112.5° right 2 12 0.4+0.4 11.480.03 11.480.03BU Single light 225° bow 3 12 0.4 11.480.05 11.480.05BU Single light 112.5° + 112.5° bicolor 2 12 0.4 \ 11.480.01/01BU \ 11.480.01/01BU \ 11.480.03/03BU \ 11.480.05/05BU
24 Navigation Lights USA \ 11.000.24 360° removable anchor light with telescopic pole EXTENSIBLE COLREG72 ABYC-C5 For vessels < 20 m, certified COLREG72 and ABYC-C5. Mooring light with stainless steel telescopic pole. Extensible from 70 to 120 cm in length, fitted with 360° white light (2 MN visibility). When not in use, the light can be stored in the peak since its size can be reduced. Sold with base plate 11.000.24. Code Length cm Light colour V W 11.039.90 70/120 Black 12 2 Borea push up LED navigation light for hulls up to 20 m AISI 316 LED Technopolymer + mirror-polished AISI316 stainless steel body. Slightly rotate the upper stainless steel plate to raise the light to its use position. Code V Version Visibility For hulls up to m 11.053.05 12/24 112.5° left + 112.5 right 2 NM 20
25 Table Lights USA Aurora pop-out LED table light LED IP65 Flush with the table top when off, it pops out and automatically lights up by slightly rotating the stainless steel upper ring. Dimmer switch upon request (13.448.01) to dim the light for ambient effect. Mirror-polished AISI316 stainless steel upper element. WARNING: 1 dimmer can manage up to 6 lamps at a time. Code Version Base V W Optional dimmer lumen K mm A B 13.448.06 Short Square 12/24 8 13.448.01 500 3000 71 110 13.448.00 Standard Square 12/24 8 13.448.01 500 3000 140 222 13.448.10 Standard Round 12/24 8 13.448.01 500 3000 140 222 13.448.01 Touch dimmer for Aurora 12/24V 50W IP68 \ 13.448.10 \ 13.448.01 \ 13.448.00/06 \ 13.448.06 \ 13.448.00 \ 13.448.00 \ 13.448.00/06 \ 13.448.10 \ 13.448.10 Pull-out LED light pole for table applications Designed to light up indoor/outdoor tables. Mirror-polished stainless steel LED light pole, chromed brass lamp holder. Light intensity (100% - 50% - 20% - 0) adjustable by means of a touch switch. 12V power supply through a base 13.440.10/16 sold separately. Code V W lumen K LED beam angle No of LEDs Base with cap in AISI 316 OPTIONAL 13.440.02 12 4 440 3000 360° 48 13.440.10 \ 13.440.10 \ 13.440.02 \ 13.440.02
26 Simple Latch USA Eclipse anti-vibration pull latch EXTRA LARGE HANDLE Featuring an extremely easy grip: - 316 mirror-polished stainless steel; - Flush deck design. - large ergonomic handle; - Spring retractable handle. - plastic spacer with invitations for custom cutting. Code External Ø mm Bore Ø mm Ø hatch thickness mm 38.164.00 60 50 0-24
27 Push Lock USA Eclipse PUSH LOCK pull latch (push closure) EXTRA LARGE HANDLE Featuring an extremely easy grip: - 316 mirror-polished stainless steel; - Flush deck design. - large ergonomic handle; - Spring retractable handle. - It opens from inside and outside. Code Lock Accepts thicknesses mm External Ø mm Recess Ø mm 38.163.01 no 9-19 60 50 38.163.02 Yes 9-19 60 50 \ Key for 38.163.02 \ 38.163.01 \ 38.163.02
28 Lift & Turn USA Line Black Large ergonomic handle The threaded shaft allows the adjustment at any height Ergonomic nut for easy calibration and emergency exit DISPONIBILE Flush deck design It can be closed every 90 (360 rotation) Optional key lock AISI 316 Stainless steel Waterproof Casted cam Open/close indicator Adaptable spacer Handle can be lowered every 90 38.161.XX - Characterized by a particularly easy grip, they enclose all the best features of the pull latches in a single model. Key LIFT & TURN compression latch
29 Lift & Turn USA Eclipse LIFT & TURN flush latch (with compression closure) - SMALL COMPRESSION SYSTEM EXTRA LARGE HANDLE Featuring a very comfortable grip, it offers all the best characteristics in a single flush deck design model. - 316 mirror-polished stainless steel; - flush aesthetics; - large ergonomic handle; - Handle can be lowered every 90°. - Foldable handle every 90°; - visual indicator open/closed; - ergonomic nut for easy calibration and allowing for emergency exit; - straight cam suitable for sliding door closure; - cam with two possible positions; - plastic spacer with invitations for custom cutting. Polished SS version Black SS version Lock External Ø mm Bore Ø mm Bulkhead thickness mm Stop stroke mm 38.161.01 38.161.61 no 60 50 3-26 22-94 38.161.02 38.161.62 Yes 60 50 3-26 22-94 \ Angled cam included 64 80 54 70 \ Universal straight cam included \ Key for 38.161.02 \ Spacer included \ 38.161.01 \ 38.161.02 \ 38.161.61 \ 38.161.62 Eclipse LIFT & TURN flush latch (with compression closure) - MEDIUM COMPRESSION SYSTEM EXTRA LARGE HANDLE Featuring a very comfortable grip, it offers all the best characteristics in a single flush deck design model. - 316 mirror-polished stainless steel; - flush aesthetics; - large ergonomic handle; - Handle can be lowered every 90°. - Foldable handle every 90°; - visual indicator open/closed; - ergonomic nut for easy calibration and allowing for emergency exit; - Straight cam suitable for sliding doors and having two different positions. - plastic spacer with invitations for custom cutting. Polished SS version Black SS version Lock External Ø mm Bore Ø mm Bulkhead thickness mm Stop stroke mm Kit No. of latches per kit (same key) 38.161.31 38.161.71 no 75 60 5-36 30-101 no - 38.161.32 38.161.72 Yes 75 60 5-36 30-101 no - 38.161.42 - Yes 75 60 5-36 30-101 Yes 2 38.161.43 - Yes 75 60 5-36 30-101 Yes 3 38.161.44 - Yes 75 60 5-36 30-101 Yes 4 38.161.45 - Yes 75 60 5-36 30-101 Yes 5 \ Angled cam included \ Key for 38.161.32; 38.161.4x 64 80 54 70 \ Universal straight cam included \ 38.161.31 \ 38.161.32 \ Spacer included \ 38.161.71/72
30 Lift & Turn USA Eclipse LIFT & TURN flush latch (with compression closure) - BIG COMPRESSION SYSTEM EXTRA LARGE HANDLE Featuring a very comfortable grip, it offers all the best characteristics in a single flush deck design model. - 316 mirror-polished stainless steel; - flush aesthetics; - large ergonomic handle; - Handle can be lowered every 90°. - Foldable handle every 90°; - visual indicator open/closed; - ergonomic nut for easy calibration and allowing for emergency exit; - Plastic modular spacer for different thickness bulkwards. Code Lock External Ø mm Bore Ø mm Bulkhead thickness mm Stop stroke mm 38.161.51 no 100 87 5.5-33 30-103 \ Angled cam included \ Spacer included \ Video Eclipse (medium) pull latch for Marinaio cabins or large lockers OPENING FROM INSIDE COMPRESSION SYSTEM Very comfortable grip, it encompasses all the best features of a flush deck pull latch. Internal handle for opening/closing from the inside. Code Lock External Ø mm Bore Ø mm Bulkhead thickness mm Stop stroke mm 38.161.39 no 75 60 5-36 30-101 \ 38.161.80 \ 38.161.81 \ 38.161.82 \ 38.161.90 Spares for Eclipse lift and turn latch Their different shapes easily fit multiple hatches or applications. Code Description Compatible models 38.161.80 Cam/lever 38.161.01/02/31/32/42/43/44/45/51 38.161.81 Cam/lever 38.161.01/02 38.161.82 Cam/lever 38.161.31/32/42/43/44/45 38.161.90 Spacers 38.161.01/02; 38.162.00; 38.152.40 38.161.91 Spacers 38.161.31/32/42/43/44/45 \ 38.161.91
31 Deck Hardwares USA Lift and turn flush pull latch with compression system AISI 316 COMPRESSION SYSTEM REGISTERED DESIGN / DISEGNO DEPOSITATO Smooth pull catch system, with the same features of similar products but smoother and more practical to use. Cam system mechanism that compresses the locker/cabinet when closed and releases the pressure when the handle is lifted. Totally watertight. Code Lock External Ø mm Ø hole in bulkhead mm Accepts thicknesses mm min max 38.159.01 no 82 68 5.5 45 38.159.02 Yes 82 68 5.5 45 Emergency open from inside Stainless steel toggle fastener suitable for trunks and hatches FULLY FLUSH OPEN AND CLOSE Mirror-polished AISI 316 stainless steel lever closure, designed to fit various applications and ensure the closure of any hatch. The locking pin with eccentric hole can be rotated to achieve the desired closing tension. Once installed, the device has a flush design with ergonomic handle for easier use. When open, the closing hook rotates at 180° and doesn't exceed the handle overall dimensions thus preventing to be hit by mistake. It includes a PVC template for easier installation. Code mm Screw size A B C 38.213.00 80 26 13 M4 38.213.01 100 32 16 M5 \ Fully flush when not in use Magnetic door stop AISI 316 FLUSH PATENTED (UTILITY MODEL) Code 38.155.80 Magnetic doorstop consisting of two components: door block with 18° inclined magnet and ground block with retractable plate. The magnet lifts the plate when the door is approaching and the block is activated. When not in use, the plate automatically returns to a flat, recessed, obstacle-free position. Equipped with shock and anti-vibration gaskets and a set of 2 gaskets (2 mm and 4 mm) to adjust the ground block height as required. For 4 to 10 mm floor height doors stops. \ Video
32 Deck Hardwares USA \ 38.511.00 \ 38.511.02 \ 38.511.02 \ 38.511.00 Deluxe pull handle FLUSH ERGONOMIC Small stainless steel handle. The rotary opening system provides a large and ergonomic grip in a reduced space. For recess-fit mounting. Fitted with anti-vibration closing system. Code Width mm Length mm Version 38.511.00 20 84 90° Edges 38.511.02 20 84 Edge radius 8 mm \ Video Deluxe 2 pull latch FLUSH ERGONOMIC AUTOMATIC OPEN Code 38.511.10 Handle with wide ergonomic grip equipped with automatic pull-out system and snap lock. For recess-fit mounting. Fitted with anti-vibration closing system. Fixing with M4 studs, no visible screws.
33 Deck Hardwares USA Square pad eyes with HR folding forged eye AISI 316 FORGE RING Mirror-polished square pad eyes with full forge eye for maximum mechanical strength. Fitted with anti-vibration rubber. It comes in a recyclable display package showing breaking load values. Same centre distance as Wichard having similar dimensions. Code Type mm Ø ring section mm Breaking load kg A B C D 39.873.01 Square Small 57 27 45 23 6 2700 39.873.02 Square Medium 75 35 60 30 8 5100 Dome hidden mini cleat AISI 316 Ideal for fender lines, dinghies and little boats. Made of mirror-polished AISI316 stainless steel. Code Base mm Hole mm Fixing Breaking load kg 40.135.60 52x46 19 screws 2400 Smash Lock fender fixing AISI 316 FAST LOCK Innovative deck accessory for fast fastening of the fenders and line fixing. Made of AISI316 mirror-polished stainless steel, compact design and instant locking system. Designed for 6- to 10-mm Ø lines. Mounting with M5 countersunk head screws. Code mm For line Ø mm Ø Height 40.160.10 76 25 6/8/10
34 Cleats USA Silhouette cleat AISI 316 REGISTERED DESIGN / DISEGNO DEPOSITATO Mirror-polished AISI316 stainless steel. Code A mm B mm C mm D mm E mm Ø studs 40.150.15 150 30.5 63.5 45 24.5 M8 40.150.20 200 40 85 60 32.5 M10 40.150.25 250 50 106.5 75 40.5 M12 40.150.32 320 64 136 96 52 M14 40.150.38 380 76 161.5 114 61.5 M16 \ 40.137.03 \ 40.137.05 \ 40.137.08 Nordik cleat AISI 316 Made of mirror-polished AISI316 stainless steel, 2-stud mounting. Code A mm B mm C mm D mm E mm Stud Ø mm Breaking load kg 40.137.01 150 45 90 47 30 8 4324 40.137.02 205 55 120 69 35 10 5058 40.137.03 265 70 150 83 40 12 5007 40.137.04 310 80 160 83 50 16 7246 40.137.05 310 80 200 83 85 w. basis oval 16 7791 40.137.06 360 90 198 100 60 16 8606 40.137.08 500 120 280 155 85 16 8984 \ 40.137.04 \ 40.137.05 \ 40.137.06 Straight fairlead made of stainless steel, Capri series AISI 316 REGISTERED DESIGN Code Description For rope up to Ø mm Optional studs A mm B mm C mm D mm E mm F mm 40.303.12 Straight 16 40.142.08; 40.142.09 M8 120 23 31 84 22 64 40.303.15 Straight 20 40.142.10; 40.142.11 M10 150 29 38 102 28 80 40.303.20 Straight 22 40.142.12 M12 200 39 48 135 37 105 Straight roller fairlead made of stainless steel, Capri series AISI 316 REGISTERED DESIGN Code Description For rope up to Ø mm Optional studs A mm B mm C mm D mm E mm F mm 40.305.00 Roller version 22 40.142.14 M14 212 58 62 154 37 88
35 Cleats USA Ghost II hidden cleat AISI 316 PERFECT GRIP SMOOTH MOVEMENT Watertight cleat with mounting screws from above. Very smooth operation. Ergonomic lifting handle. Fluorinated rubber O-ring for smooth sliding. ENAVE approved in compliance with ISO 15084:2003. Polished SS version Black SS version A mm B mm C mm D mm E mm F mm Ø H mm Ø G mm Workload Kg Fixing OPTIONAL drainage conduit 40.155.16 40.156.16 160 38 15 28 47 48 14 24 800 3 x M6 screws 40.155.72 40.155.24 40.156.24 240 52 20 44 70 72 18 32 2050 3 x M8 screws 40.155.74 40.155.31 40.156.31 310 68 25 56 85 93 22 41 5200 3 x M10 screws - \ Video \ 40.156.xx \ 40.155.xx \ 40.155.xx \ 40.155.xx \ 40.156.xx \ 40.156.xx
36 Self-tensioning Sun-shade System USA Mickey self-tensioning, modular and independent Bimini system It can be used as sunshade or water protection and is UV-resistant. Simple to assemble, disassemble and store. It can be installed in many different ways. The 15°-inclination basis are small and can be easily in different places of the deck depending on the needs and provide a wider coverage than traditional systems. Much more convenient than the standard systems available on the market (canopy not included). Flexible pole for Mickey system Fiberglass pole covered in carbon fibre with AISI316L stainless steel inserts. Code Ø mm Overall height A cm Distance gained with slope B cm Net height from flush deck C cm Recess D cm Total height extended mm 46.826.14 16 137 34 129 8 137 46.826.15 16 153.5 38 145 8 153.5 46.826.17 16 170 43 160 8 170 46.826.18 16 185 47 175 8 185 \ 46.825.00 \ 46.825.00 \ 46.825.00 \ 46.825.01 \ 46.825.01 \ 46.825.01 Stainless steel fastening bushing for Mickey system Recess-fit AISI316 stainless steel bushing with fastening counter-ring. Available in 3 models. Code Description Pole-Ø mm mm min/max deck thichness F mm A B C D E 46.825.00 No lid 16 52 40 54 4 26 8/40 46.825.01 Rotary lid 16 58 58 54 5 26 2/50 46.825.02 Watertight lid 16 69 62 54 10 26 2/50 \ 46.825.02 \ 46.825.02 \ 46.825.02 Mounting base on stainless steel pulpit Mickey system Code 46.825.10 Stainless steel AISI 316 bushing to be fixed where the pulpit crosses the support arm (to prevent bushing rotation). Adaptable to pulpits with diameters from 30 to 34 mm and support arm diameters from 25 to 28 mm. Accommodates a pulpit joint angle from 90° to 45°. Designed with a 15° angle towards the bow or stern and a 12° outward tilt of the vessel to create a self-tensioning system and maximise the size of the awning (Screws included). Fastening buckle for Mickey system AISI316 stainless steel buckle for a simpler fastening of the Bimini top to the pole. Code mm buckle for loop mm A B 1 2 46.825.09 74 50 40x5 20x3
37 Rigid Sun-shade System USA Bimini top with carbon tubes Bimini top modular system. High finish with mirror-polished swivel-lock bushings. Carbon pole for Bimini top The pole rotates by 90° inside the bushing and locks. The poles are fitted with tightening bushings. Clamcleat for easy adjustment and tensioning of the Bimini top already mounted on the pole. Compatible with recess-fit bushings 46.815.xx and 46.280.xx. Fastening rope: eye spliced Dyneema rope. It can be used for direct installation on the Bimini top by means of a 10-mm Ø pawl or a snap hook. Rope not included with the pole. Code Ø mm Height cm Optional wall mounting clip 46.816.02 38 130 34.358.38 46.816.04 38 150 34.358.38 46.816.06 38 170 34.358.38 46.816.07 38 185 34.358.38 46.816.08 38 200 34.358.38 46.816.10 38 230 34.358.38 46.821.02 50 170 34.358.50 46.821.04 50 200 34.358.50 46.821.06 50 230 34.358.50 46.817.00 MARLOW spliced line, length 130 cm with 50 cm adjustment \ Close-up of the fastening bushing \ 46.817.00 \ 34.358.38/50 Removable carbon pole for Bimini top 2 PCS MOUNT POLE The pole is made up of two section and is fitted with anticorodal aluminium bushings for fast mounting. Tightening bushings and a fastening line are also supplied. The pole rotates by 90° inside the busing and locks. Clamcleat for easy adjustment and tensioning of the Bimini top already mounted on the pole. Compatible with recess-mount bushings 46.815.00/01, the bulkhead mount bushing kit 46.815.10 and the bulkhead mount stowage system 34.358.38. Leaded Dyneema fixing line with ring, sold separately. Can be used to directly attach to the awning via a Ø 10.0 mm ball or carabiner. Code Ø mm Height cm No of sections 46.818.09 38 90/181 2 46.818.11 38 110/231 2 46.817.00 MARLOW spliced line, length 130 cm with 50 cm adjustment 34.358.38 Bulkhead stowage system \ 46.818.11 \ 46.818.09
38 Rigid Sun-shade System USA \ 46.815.00/01; 46.820.00 \ 46.815.00/01; 46.820.00 \ 46.815.00/01; 46.820.00 Recessed bushing for carbon pole with rotating cover In stainless steel with a 180° rotating closure. Prepared for water drainage for pipe Ø 12 mm. The closure discreetly protects the glass when not in use. The closure can be customized with a logo upon request. Code For poles of Ø mm Description mm A B C D 46.815.00 38 Recess-fit bushing, straight 95 141.5 56 74 46.815.01 38 Recess-fit bushing, inclined at 6° 95 141.5 56 74 46.815.90 38 Mounting counterflange for recess-fit bushing 95 - - 74 46.820.00 50 Recess-fit bushing, straight 108 150 70 90 46.820.01 50 Recess-fit bushing, inclined at 6° 108 150 70 90 \ 46.815.00/01; 46.820.00/01 \ 46.815.01; 46.820.01 \ 46.815.00/01; 46.820.00/01 \ 46.815.90 \ 46.814.00; 46.819.00 Recessed bushing for carbon pole with hinge cover Made of stainless steel with locking hasp and staple, locking seal and mounting counterflange - 46.814.90. Water drainage setup for a Ø 12 mm pipe, including mounting counterflange (code 46.814.90). The closure discreetly protects the glass when not in use. It is possible to customize the cap with a logo upon request. Code For poles of Ø mm Description mm A B C D 46.814.00 38 Recess-fit bushing, straight 95 141.5 56 74 46.814.01 38 6° angled recessed bushing 95 141.5 56 74 46.814.90 38 Extra mounting counterflange 100 - - - 46.819.00* 50 Recess-fit bushing, straight 108 150 70 90 46.819.01* 50 6° angled recessed bushing 108 150 70 90 * Available from November \ 46.814.00/01; 46.819.00/01 \ 46.814.01; 46.819.00 \ 46.814.90 Wall bushing for carbon pole Ø 38 mm Composed of a double bracket, lower and upper, wall-mounted for awning pole. The pole rotates 90° within the bracket and remains locked. High aesthetic finish system thanks to the mirror-polished surface and front logo. Bulkhead mounting by means of two x M6x40 countersunk screws or longer ones. Blind lower support. Thru-hull upper support. Code For poles of Ø mm Description mm A B C D 46.815.10 38 Bulkhead bushing kit 92 106 65 74
39 Fender Profiles USA Fender profiles made of stainless steel and PVC bases Fender profiles AISI 316 Made-in-Italy AISI316 stainless steel C-shaped fender profiles. 3-m standard length, tapered and mirror-polished. Each bar is pickled and passivated for optimum resistance in salty environment. They can be used with dedicated UV-resistant PVC base plates available in white, black and grey, and with dedicated mirror-polished AISI316 stainless steel terminals. Code Description Bore type mm Bars m Bore centre distance White PVC base Grey PVC base Black PVC base SS end cap A B H 44.480.20 Profilo 20 flared 19 1.5 4.6 3 198 44.481.33 44.481.43 44.481.53 44.484.33 44.477.20 Profilo 20 deep-drawn 19 1.5 4.6 3 186 44.481.35 44.481.45 44.481.55 44.484.35 44.480.30 Profilo 28 flared 28 1.5 7 3 198 44.481.36 44.481.46 44.481.56 44.484.36 44.480.38 Profile 35 flared 35 1.5 9 3 198 44.481.37 44.481.47 44.481.57 44.484.37 Base in 24-m-roll \ 44.484.33/35 \ 33.484.36/37 \ 44.480.xx \ 44.481.33/43/53 \ 44.481.35/45/55 \ 44.481.36/46/56 \ 44.481.37/47/57 \ 44.480.20/30/38 \ 44.477.20 \ 44.480.38; 44.481.37/47/57 \ 44.477.20; 44.481.35/45/55 \ 44.480.30; 44.481.36/46/56 \ 44.480.20; 44.481.33/43/53 \ 44.480.xx; 44.477.20 \ 44.481.xx
40 Ladders USA
41 Ladders USA EasyUp Telescopic ladder with handles for installation above the bathing platform AISI 316 PATENT PENDING AUTOMATIC HANDLE The holding handle rises and lowers when the ladder is deployed. Extra-large step (52.5 mm). Mirror-polished AISI316 stainless steel. Code Steps Tube Ø mm Length mm Max width mm Closed height mm open closed 49.575.04 4 19/25/32/38 1185 480 515 60 Easy Up under-platform ladder with handles AISI 316 AUTOMATIC HANDLES Under-platform 4-step telescopic ladder made of AISI316 stainless steel. Fitted with overhanging rungs that make it easy to pull out the ladder and built-in climb-back handles that open and close automatically when pulling out or closing the ladder. 43-mm black plastic rungs for better comfort. Code Model Steps Length mm Width (C) mm Tube Ø mm No. Colour open (A) folded (B) 49.577.04 Normal 4 Black 1040 480 440 19/25/32/38 49.578.04 Big 4 Black 1040 480 520 19/25/32/38
42 Ladders USA \ Video EasyUp built-in telescopic ladder with railings REGISTERED DESIGN AUTOMATIC HANDLE Telescopic ladder recessed in stainless steel AISI316 with 4 steps. Equipped with integrated ascent handles that automatically raise and lower by rotating the ladder. The railing closing system makes it easier to retrieve the ladder from the gangplank. The ladder has a guided pull-out system for better and more precise sliding. Code Steps Tube Ø mm Length mm Max width mm Closed height mm open closed 49.569.04 4 19/25/32/38 1481 556 518 113.2
43 Ladders USA Recessed emergency ladder suitable for ISO 15085 and ABYC H-41 standards Ladder to be used to climb back onboard in case of emergency. - Watertight and reinforced ASA housing. - Pull-out cover to open the ladder. - Polyester tape ladder with stiff steps. - FLUO stripe on the steps for better visibility at night. Code ladder mm Colour Steps length when open step width 49.525.00 2400 250 white 7 Steel handle stainless steel AISI316 Fluo stripe on the stiff steps for better visibility at night Quick opening Recess-fit mounting Watertight and reinforced ASA housing Recess-fit emergency ladder suitable 49.525.00 - To comply with ISO 15085 standards Safety on board
