3 New in September 2025 Dudge 77 round electric aluminium table leg IP66 ELECTRIC ANTIROTATION Electric round table leg in three stages made of silver anodized aluminum, suitable for both outside and inside the boat, with anti-rotation. For single-leg operation, a switch (ON)-OFF-(ON) type 14.192.03 or similar is required. For operation in pairs, order control unit/receiver 48.730.02 For operation with remote control, order control unit/receiver 48.730.02 + 48.730.03. Code V No. of heights Max A Speed mm/s Colour Height when retracted mm Height when extended mm Table plate mm Base mm Max load kg 48.733.12 12 3 10 35 Silver 378 778 200x200 200x200 100 48.733.24 24 3 5 35 Silver 378 778 200x200 200x200 100 Dudge 77 square electric aluminium table leg IP66 ELECTRIC Electric table leg in three stages made of anodized aluminum in silver or black, suitable for both outdoor and indoor use on the boat. For single-leg operation, a switch (ON)-OFF-(ON) type 14.192.03 or similar is required. For operation in pairs, order control unit/receiver 48.730.02 For operation with remote control, order control unit/receiver 48.730.02 + 48.730.03. Code V No. of heights Max A Speed mm/s Colour Height when retracted mm Height when extended mm Table plate mm Base mm Max load kg 48.731.12 12 3 10 35 Silver 378 778 200x200 200x200 100 48.731.24 24 3 5 35 Silver 378 778 200x200 200x200 100 48.732.12 12 3 10 35 Black 378 778 200x200 200x200 100 48.732.24 24 3 5 35 Black 378 778 200x200 200x200 100 Control and Synchronization Systems for Table Legs Dudge 77 Code Description For pedestals IP degree 48.730.02 Control unit/receiver to synchronize two legs of the same table and/or to use a remote control 48.733.XX; 48.731.XX; 48.732.XX 69K 48.730.03 Four-way remote control to operate single or double table pedestals (control unit 48.730.02 is mandatory) 48.733.XX; 48.731.XX; 48.732.XX - \ 48.730.02 \ 48.730.03
4 New in September 2025 \ 01.119.20 \ 01.119.21 \ 01.119.20 Claw Maxi steel chain stopper AISI 316 AISI 316 steel chain stoper perfect to enhance anchoring system safety. Prevents accidental descent of the anchor while sailing, and protects the winch from excessive loads and strains at anchor. Simple installation from above using countersunk screws. Two models available for 8–10mm and 12–14mm chains. Code Base mm For chain Ø mm 01.119.20 100x67 8/10 01.119.21 140x92 12/14 Available from February 2026 \ 01.119.21 Mooring lines with eye and integrated shock absorber SHOCK ABSORBER Double braid made of 100% high-tenacity polyester with elastic shock absorber inside. Pre-spliced with a large eye to facilitate mooring and enhance comfort and safety, especially when cruising. Antitwist, UV and abrasion-resistant. Code Colour Ø mm Length m Breaking load kg Eye Ø cm Shock absorber mm 06.490.12 Black 12 8 1800 40 600 06.490.14 Black 14 10 2300 40 600 06.490.16 Black 16 11 2500 60 600 06.490.20 Black 20 12 4500 60 600 Available from November Mooring line with spliced ring and reinforced cover Pre-spliced, wide-looped line with polyester fabric protective cover. Soft, robust and easy to handle. White/Black Ø mm Length m Eye Ø cm Breaking load kg 06.489.16 16 11 60 2500 06.489.20 20 12 80 4500 06.489.24 24 13 80 6800 Available from November Watertight SS cable gland AISI 316 IP68 Waterproof IP68 cable glands made of SS AISI 316. Code Base Ø Overhang mm For cables mm 14.187.11 46 20 5 - 8 14.187.12 52 22 7 - 12 14.187.13 56 26 13 - 17 Available from November
5 New in September 2025 Clip for ladder closure The nylon clip attaches to the ladder's tube, ensuring a safe position while navigating, and when not in use, it folds onto the deck, integrating into its shockproof EPDM mounting base. Easily applicable on the deck with two self-tapping mounting screws. Code Suitable for ladders 49.560.19 49.536.XX; 49.540.XX; 49.541.XX; 49.551.XX; 49.553.XX Recessed bushing for carbon pole with hinge cover Made of stainless steel with locking hasp and staple, locking seal and mounting counterflange - 46.814.90. Water drainage setup for a Ø 12 mm pipe, including mounting counterflange (code 46.814.90). The closure discreetly protects the glass when not in use. It is possible to customize the cap with a logo upon request. Code For poles of Ø mm Description mm A B C D 46.814.00 38 Recess-fit bushing, straight 95 141.5 56 74 46.814.01 38 6° angled recessed bushing 95 141.5 56 74 46.814.90 38 Extra mounting counterflange 100 - - - 46.819.00* 50 Recess-fit bushing, straight 108 150 70 90 46.819.01* 50 6° angled recessed bushing 108 150 70 90 * Available from November \ 46.814.00/01; 46.819.00/01 \ 46.814.01; 46.819.00 \ 46.814.90 \ 46.814.00; 46.819.00 Articulated, bedside reading, dimmable LED spotlight Comes with USB-port type-C-2A. Touch ON-OFF switch and dimmer. Material: chromed aluminium spotlight and articulated arm covered in black silicone. Code Finish V W Switch lumen K Length mm 13.867.60 Chromed + black silicone 12/24 2 Touch 135 3000 376 Available from November
6 New in September 2025 Mini plastic locker suitable for housing two CV 500 cylinders, ventilated, with front opening 2 X 500 GR The storage compartment is equipped with a 30 mbar gas regulator, shutoff valve, and double connection for accommodating two cylinders with screwable valve (EN417) max 500 gr. Can hold gas cylinders type CV450 or CV500 with maximum diameter 120 mm and height 130 mm (recommended model Cadac/Dometic CA500-N). Complete with adjustable fitting suitable for 8mm gas pipe in accordance with ISO 10239. Door with integrated ventilation hole. Code Front mm Recess mm Depth mm 50.254.00 380x280 280x180 180+30 \ 20.291.00 \ Video Frigo° fridge with clean touch front panel Versatile and compact fridges. Easily installed in any boat or vehicle. Features a convenient freezer compartment. Equipped with a high-performance compressor and low energy consumption, with internal control command to adjust the temperature and an antifingerprint treated, anodized brushed aluminum door panel. Reversible door opening. Available finishing frames that allow flush or protruding installation. Code Capacity l V A mm OPTIONAL frame Width depth Height 50.961.00 50 12/24 5/2.5 380 500 535 17 50.961.30 50.961.02 85 12/24 5/2.5 475 555 635 21 50.961.32 \ 50.961.00 \ 50.961.02
7 New in September 2025 Cruiser 32A plug and socket 32A IP67 IEC 60309-5 Nautical socket and plug for 32A - 220V shore power cable. Made of PA6, equipped with high energy efficiency contacts and an IP67 closure cap. The plug is designed to ensure an ergonomic grip, and the rotating ring allows it to be securely fastened to the boat's socket with an IP67 watertight seal, while the rubber cap ensures an IP44 seal when not connected. The clean design and compact dimensions allow for convenient installation of the socket anywhere in the cockpit. Compliant with European safety standards IEC 60309-5. Code Description Lid Base 14.432.02 Pa6 nylon plug - - 14.432.01 Socket Nylon Pa6 Nylon Pa6 14.432.11 Socket Stainless steel Nylon Pa6 14.432.21 Socket Stainless steel Nylon Pa6 14.432.31 Socket Stainless steel Stainless steel 14.432.40 Socket Nylon Pa6 Nylon Pa6 Available from February 2025 \ 14.432.01 \ 14.432.11 \ 14.432.40 Complete set for 220V 16A system 16A IP67 IEC 60309-5 NO TOOL Complete 220V boat power supply set for dock charging column. The kit includes Cruiser electrical socket for boat installation, 16A wired electrical panel with magnetothermic circuit breaker, Schuko socket, 3m 3G wiring and a 10m cable for charging column connection. The system is available in four different layouts to choose the socket that best suits the hull color. Code Lid Base Cable length m 16A Panel Power cable 14.416.70 Nylon Pa6 Nylon Pa6 10 14.737.16 14.416.20 14.416.71 Nylon Pa6 Nylon Pa6 10 14.737.16 14.416.20 14.416.72 Nylon Pa6 Nylon Pa6 15 14.737.16 14.416.25 14.416.80 Stainless steel Nylon Pa6 10 14.737.16 14.416.20 14.416.81 Stainless steel Nylon Pa6 10 14.737.16 14.416.20 14.416.82 Stainless steel Nylon Pa6 15 14.737.16 14.416.25 Shower/Tap Removable Kit Shower head with PVC hose and quick connector for gardening. Designed to provide fast connections and versatile solutions, it is compatible with quick coupling washdown hose connector. Usable as both a handheld shower and a tap, easy to connect and remove after use. Code Length m Terminal joints For hose connectors Tap support 15.211.00 2.5 1/2" F + Quick garden connection 16.441.18. 16.441.38. 16.441.75. 16.441.88.16.441.95. 16.442.60. 16.442.61. 16.442.70. 16.442.71. 16.443.00. 16.444.00 17.019.02 \ 17.019.02
8 New in September 2025 \ 14.315.01/05 \ 14.315.02/06 \ 14.315.03/07 FLAT stainless steel switches 12/24V SS316 LONG PIN FLAT anti-vandal switches with AISI 316 stainless steel body, CNC-manufactured. Compatible with 12V and 24V systems. Capacity 20A. IP67 protection rating. LED light crown in 3 different colors. Available with standard ON-OFF and temporary ON. White LED Red LED Blue LED Function V A 14.315.01 14.315.02 14.315.03 ON-OFF 12/24 20 14.315.05 14.315.06 14.315.07 (temporary ON)-OFF 12/24 20 Pre wired connector for flat switches 14.315.XX Code 14.315.20 Simplifies 14.315.XX switches wiring, 12/24V operation. Jumper cable for “Push ON” or “Always ON” LED configuration. Cable length 15 cm. Fastening ring to prevent accidental cable disconnection. Pre-wired connector with circuit breaker for flat switches 14.315.XX INTEGRATED CIRCUIT BREAKER Simplifies 14.315.XX switches wiring. Equipped with automatic reset circuit breaker. Jumper cable for “Push ON” or “Always ON” LED configuration. Cable length 15 cm. Fastening ring to prevent accidental cable disconnection. Code Function Capacity A V 14.315.31 Pre-wired connector with circuit breaker 5 12/24 14.315.32 Pre-wired connector with circuit breaker 10 12/24 14.315.33 Pre-wired connector with circuit breaker 15 12/24 14.315.34 Pre-wired connector with circuit breaker 20 12/24 Available from November \ 38.511.02 \ 38.511.02 Deluxe pull handle FLUSH ERGONOMIC Small stainless steel handle. The rotary opening system provides a large and ergonomic grip in a reduced space. For recess-fit mounting. Fitted with anti-vibration closing system. Code Width mm Length mm Version 38.511.00 20 84 90° Edges 38.511.02* 20 84 Edge radius 8 mm * Available from November \ Video
9 New in September 2025 Airwalk Multifunctional inflatable PVC gangway AIR PLATFORM GANGWAY SUP The inflatable gangway by Osculati is made of nautical PVC with excellent abrasion resistance and UV protection. The Dropstitch technology used in SUPs makes them extraordinarily rigid and safe, ensuring safe and convenient passage. Features anti-slip EVA surface on the upper walkable area and on the lower part of the nylon sliders to prevent wear on the dock. For use, the gangway can be inflated with a manual or electric pump to a pressure of 15 PSI – 1 bar, then deflated and easily stored in a storage compartment due to its compact size (80x30x15 cm). Another function of this product is its ability to be used as a SUP with fins; by removing the nylon sliders, two snap-in fins can be attached that allow for good paddling. For safe walking on the gangway, a handrail kit (code 42.681.90) is available as an option. It is made with two rods of 30 mm diameter in aluminium and a nautical peak of 6 mm with a tensioning device. The system is easily applicable and removable with high-strength hooks on the edge of the gangway. Code Description Material A B C 42.681.00 Gangway PVC 240 70 15 42.681.90 Handrail Kit Aluminium 240 - 80 Available from November \ 42.681.90 \ Snap-in fins \ Anti-abrasion slider Telescopic slide-out ladder AISI 316 EXTRA LARGE STEPS (57 MM) SLIDING BRACKETS Made of AISI 316 stainless steel. 57-mm wide steps for increased comfort. Tube centre distance 305 mm. Equipped with a system featuring sliding plates ensuring complete retraction of the ladder into the profile of the platform , leaving no protruding parts when not in use. Code Steps Length mm Width mm No. Colour open closed 49.541.84 4 Black 1140 398 352
10 New in September 2025 PIRANHA P4 POLYMER LED underwater light IP68 Piranha P4 Polymer is made from a polymer having mechanical properties similar to bronze. Particularly suited for vessels exposed to intense galvanic currents. Like all models of the Piranha series, it features the "surface mount" technology that greatly simplifies installation. P4 incorporates X-Beam patented technology, active thermal control, Hydro Block, protection against polarity reversal, and anti-marine vegetation coating. Light beam distribution at 60°. RINA IEC 60529 Type Approval Code V W No of LEDs K lumen LED colour 13.350.01 12/24 12 4 6500 2000 white 13.350.02 12/24 12 4 - 2000 blue 13.350.03 12/24 12 4 - 2000 White + Blue 13.350.04 12/24 12 4 - 2000 RGBW PIRANHA P4 HI-POWER LED underwater light IP68 The Piranha P4 HI-POWER series is designed for small boats. High luminous performance, intensity up to 4000 lumens in color changing models. This version retains all Bluefin LED technologies: X-Beam, active thermal control, Hydro Block, polarity reversal protection, and anti-fouling coating; light beam distribution at 60°. Material: Bronze RINA IEC 60529 Type Approval Code V W No of LEDs K lumen LED colour 13.350.10 12/24 24 4 6500 3100 white 13.350.11 12/24 24 4 - 3100 blue 13.350.12 12/24 24 4 - 3100 White + Blue 13.350.13 12/24 24 4 - 4000 RGBW
11 New in September 2025 PIRANHA P6 NI LED underwater light IP68 Piranha P6 Nitro featudures the innovative Nitro Boost function which allows for a temporary brightness increase up to +35% giving a stunning visual effect. Deactivated for dim lighing or to reduce power consumption. Extremely easy installation through a 13mm-hole for wiring. No external drivers required thanks to Builtin Driver technology. Heat protection has been further implemented: instead of switchting off at 65°C, the device reguletes itself by decreasing the light intensity thus maintaining operation safely. Equipped with Builtin Driver technology, protection from polarity reversal, anti-fouling coating; light beam distribution at 60°. Material: Bronze RINA IEC 60529 Type Approval Code V W No of LEDs K lumen LED colour 13.350.20 12 40 6 6500 4100 white 13.350.21 12 40 6 - 4100 blue 13.350.22 24 40 6 6500 4100 white 13.350.23 24 40 6 - 4100 blue 13.350.24 12/24 50 6 - 5000 RGBW PIRANHA P12 LED underwater light IP68 Piranha P12 produces a class leading 8,000 Lumens and the same simple installation typical of the series. Only a 13mm-hole for wiring is required. Three screws and sealant are needed to complete installation. Builtin Driver technology provides reverse polarity protection, anti-vegetation coating. Like the entire Bluefin LED range, it features advanced protections, notably sophisticated thermal management that regulates brightness according to temperature and ensures temporary use out of water (adoption is not recommended to preserve the visual effect). Light beam distribution at 60°. Material: Bronze RINA IEC 60529 Type Approval Code V W No of LEDs K lumen LED colour 13.350.30 12/24 55 12 6500 8000 white 13.350.31 12/24 55 12 - 8000 blue 13.350.32 12/24 55 12 - 8000 White + Blue
12 New in September 2025 PIRANHA P24 LED underwater light IP68 Piranha P24 is top-of-the-range and delivers 10,000 lumens. Optimal beam angle 60° for an intense visual effect. Very powerful and yet suitable for out of water use thanks to its self-adjusting thermal control that reduces intensity in case of overheating. Builtin Driver technology provides reverse polarity protection, anti-vegetation coating. Material: Bronze RINA IEC 60529 Type Approval Code V W No of LEDs K lumen LED colour 13.350.40 12/24 120 24 6500 12000 white 13.350.41 12/24 120 24 - 12000 blue 13.350.42 12/24 120 24 - 12000 White + Blue 13.350.43 12/24 120 24 - 10000 RGBW MAKO M12 throughhull underwater light IP68 The compact design of Mako M12 thru-hull light features high performances comparable to larger models. Only a 65mm-hole is required for installation. The driver can be replaced even when the vessel is in the water. Provides 7,100 lumens at 60° angle and only 75 Watts. No external drivers required thanks to Builtin Driver technology. Active thermal control, high/low tension protection, reverse polaruty protection and anti-fouling coating. Material: Bronze RINA IEC 60529 Type Approval Code V W No of LEDs K lumen LED colour 13.350.90 12 70 12 6500 7100 white 13.350.91 12 70 12 - 7100 blue
13 New in September 2025 Stainless steel LED walkway lights LED lights for outdoor floor installations. Ideal for decks, walkways, quays and docks. Made of 316L stainless steel. Corrosion and weather resistant. • Protection rating: IP68 (completely waterproof). • Wiring: waterproof connector or integrated cable (variable lengths). • Osram LED with integrated constant current driver. • Tempered optical glass diffuser. • IP66 cable gland for cable entry, fully sealed. Comes with 7m-bipolar moisture resistant cable. • IP66 protection. Code V W K lumen LED colour mm 13.350.80 12/24 6 3000 600 white 100x19 BL-Switch LED beacon switch IP66 Code 13.350.70 BL-Switch LED Headlight Switch has been specifically designed for Bluefin LED beacons. It features the "Momentary Light Switch" function. IP66 waterproof rating. Water- and dustproof . It ensurs safe operation even in the most adverse conditions. This switch (12/24V) perfectly suits all models of the Bluefin LED range, however It is not suitable for beacons with color changing technology (RGBW). BL-Switch supports up to 20A abd provides efficient and reliable power management for Bluefin LED beacons.
14 New in September 2025 \ 14.302.00 \ 14.301.00 \ 14.303.00 \ 14.305.00 \ 14.305.10 \ 14.103.00 \ 14.102.00 \ 14.103.01 MARINCO sockets and plugs 16A at 230V 16A 230V Completely waterproof. Made from high-strength glass-fibre reinforced thermopolymer, contacts in nickel-plated brass. Code Description A V Poles 14.301.00 Male 3-wire plug with rear cable protection in “Valox” resin. IP56 16 230 3 14.302.00 3-core stainless steel AISI 316 socket, male contacts. IP56 16 230 3 14.303.00 3-wire male contact plug, front round version, with rear cable protection in “Valox” resin. IP56 16 230 3 14.305.00 3-core plug to be coupled with sockets 14.301/302/303.00, female contacts. IP56 16 230 3 14.305.10 3-wire plug dockside, male contact. IP56 16 230 3 14.103.00 Yellow watertight PVC cap for 14.305.00 - - - 14.102.00 Yellow watertight PVC cap for 14.305.10 - - - 14.103.01 Watertight cap to seal Marinco plugs. For plugs 14.305.00 + 14.103.00. 16-30 Amp - - - \ 14.587.04 \ 14.487.03 \ 14.634.30 \ 14.634.31 \ 14.587.03 \ 14.636.10 \ 14.771.70 \ 14.103.02 MARINCO sockets and plugs 32A at 230V 32A 230V Completely waterproof. Made from high-strength glass-fibre reinforced thermopolymer, contacts in nickel-plated brass. Code Description A V Poles 14.487.03 3-core stainless steel AISI 316 male contact socket. IP56 32/50 230/115 3 14.634.30 Socket 4-wire male in resin “Valox”. IP56 32/50 230/115 3 14.634.31 Socket 3 wires male contacts square 32/50 230/115 3 14.587.03 3-wire plug to be coupled with socket 14.487.03, female contacts. IP56 32/50 230/115 3 14.636.10 3-wire plug, dockside, male. IP56 32/50 230/115 3 14.771.70 Yellow watertight PVC cap for 14.636.10 - - - 14.587.04 Waterproof yellow PVC cap for 14.587.06 - 14.587.09 - - - 14.103.02 Watertight cap to seal Marinco plugs. For plugs 14.587.03-06 + 14.587.04. 32-63 Amp - - - \ 14.487.01 \ 14.587.01 \ 14.587.02 \ 14.587.04 MARINCO 50A sockets and plugs at 125/250V 50A 125/250V Completely waterproof. Made from high-strength glass-fibre reinforced thermopolymer, contacts in nickel-plated brass. Code Description A V Poles 14.487.01 Socket 4 wires stainless steel AISI 316 male contacts. IP56 50 125/250 3+lateral 14.587.01 4-wire plug to be coupled with socket 14.487.01, female contacts. IP56 50 125/250 3+lateral 14.587.02 4-core plug male contacts 50 125/250 3+lateral 14.587.04 Waterproof yellow PVC cap for 14.587.06 - 14.587.09 - - - \ 14.487.06/09 \ 14.587.06/09 \ 14.587.04 \ 14.103.02 MARINCO sockets and plugs 63A at 230V 3 63A 230V Completely waterproof. Made from high-strength glass-fibre reinforced thermopolymer, contacts in nickel-plated brass. Code Description A V Poles 14.487.06 3-core stainless steel AISI 316 male contact socket. IP56 63 230 3 14.587.06 3-wire plug to be connected to socket 14.487.06 with female contacts. IP56 63 230 3 14.487.09 Socket 4 wires stainless steel AISI 316 male contacts. IP56 63 230 3+lateral 14.587.09 4-wire plug to be coupled with socket 14.487.09, female contacts. IP56 63 230 3+lateral 14.587.04 Waterproof yellow PVC cap for 14.587.06 - 14.587.09 - - - 14.103.02 Watertight cap to seal Marinco plugs. For plugs 14.587.03-06 + 14.587.04. 32-63 Amp - - -
15 New in September 2025 Precision Electric Lights MARINCO 100 W halogen precision lights with weatherproof IP56 ABS body and Lexan lenses. Capable of 370° rotation and 120° tilt. Power supply 12/24 V. Wireless panel SPLR-2 included, requires a power cable for 12/24 V. Optional wireless remote SPLR-1 (13.260.71) or wired panel SPLR-3 (13.260.72) available. Code Rotation Traverse V W Handheld remote control Fixed panel 13.260.21 370° 120° 12/24 100 13.260.71* 13.260.72 13.260.22 370° 120° 12/24 100 13.260.71* 13.260.72 * Requires a cable for 12/24V power supply \ 13.260.72 \ 13.260.71 \ 13.260.21 \ 13.260.22 Docking cable with locking device MARINCO Cables for dockside connection with IEC 60309 safety connectors and illuminated NEMA plug on the boat side. Supplied with waterproof closure cap and voltage indicator LED. Featuring robust anti-wear polyurethane sheath, high visibility yellow color, and overmolded joints for watertightness and UV resistance. Code Length m A Cable colour Cable section mm Amp (A) plug dock side Plug boat side 14.216.16 15 16 yellow 3x2.5 16 14.301.00 - 14.302.00 - 14.303.00 14.216.32 15 32 yellow 3x4 32 14.487.03 - 14.634.30 - 14.634.31 \ 14.216.32 \ 14.216.16 Socket and plug for electric motors MARINCO Kit for sockets and plugs for electric motors and onboard utilities with nickel-plated brass contacts, waterproof seal with cap and vibration-proof “locking” coupling. A plug-and-play solution that covers from small trolling motors to the most powerful systems: secure, waterproof connection with low voltage drop, ready for installations from 12 to 48 volts. Code A V Configuration 14.112.01 70 12/24/36/48 2 or 3 cables 14.112.02 40 12/24/36 2 cables \ 14.112.02 \ 14.112.01
16 New in September 2025 \ 15.290.23 \ 15.290.23 \ 15.290.33 \ 15.290.23/33 \ 15.290.24 WHALE Twist Mk2 integrated deck shower PATENT Enhanced features for the reference hot/cold shower in the sector. Available in white or black, with a new generation mesh tube: lighter, more flexible, stain-resistant and easier to stow. Technical data: - integrated hot/cold water mixer; - Compatibility with existing Twist systems; - Recesses at angle with colors matching the pumps; - chromed straight recess available; - new universal connection of ½”. Code Function Flange Colour Min. inner space mm Flange Ø mm hose cm Package 15.290.23 Hot / cold straight white 190 57 250 bulk / loose 15.290.24 Hot / cold Angled white 150 120 250 bulk / loose 15.290.25 Hot / cold Straight / Angled white 190/150 57/120 250 retail box 15.290.33 Hot / cold straight Black 190 57 250 bulk / loose 15.290.34 Hot / cold Angled Black 150 120 250 bulk / loose 15.290.35 Hot / cold Straight / Angled Black 190/150 57/120 250 retail box The angled version is suitable for installation on vertical walls and where there is limited inside space. \ 15.290.24/34 \ 41.412.00 \ 41.412.10 Support for Live Pole RAILBLAZA HEXX® transducers It perfectly places the soft grip at hip height for easy use. • 360° rotation of the transducer • Fully foldable for storage and save space • 1 Hexx base included • Storage bag included (only Hexx Live Pole 60 41.412.00) Code Cod. Railblaza Version Open dimensions mm Dimensions closed mm 41.412.00 11-4190-11 Hexx Live Pole 60 1550 830 41.412.10 11-4191-11 Hexx Live Pole 30 768 -
17 New in September 2025 \ 14.520-533.xx \ 14.523-524-534.xx BERKER® original modular switches and sockets __logo__CE__ To be fitteded in FLOW single or double design frame models. Single frame: 59.5x59.5 mm. Double frame: 59.5x178.5 mm. \ 14.536.0x \ 14.533.01 + 14.527.01 Type Product Anthracite black white chromed Module 16A single switch 14.520.01 14.520.02 14.520.03 16A double switch 14.521.01 14.521.02 14.521.03 16A diverter 14.522.01 14.522.02 14.522.03 10A single push button 14.523.01* 14.523.02* 14.523.03* 10A double push button 14.524.01* 14.524.02* 14.524.03* 16A Italian power socket 14.525.01 14.525.02 - 16A Schuko power socket 14.526.01 14.526.02 - USB A+C port 3+3A 14.527.01 - - Flow frames Single frame 14.533.01 14.533.02 14.533.03 Double frame 14.534.01 14.534.02 14.534.03 Frame with spring hatch 14.536.01 14.536.02 14.536.03 * For push-button+dimmer operation (Art. 14.540.00 required). 14.538.01 White lower rear protection cover, 22-mm protrusion, suitable for all modules 14.520/521/522/523/524. 14.538.02 High protection rear cover, 45mm protrusion, suitable for modules 14.525/526/527.01. Colour: white 14.538.03 Spacer required for 14.520/521/522/523/524 modules installation without recess. Colour: black anthracite. 14.538.04 Spacer required for 14.520/521/522/523/524 modules installation without recess. Colour: white. 14.540.00 Mono channel mini dimmer: operates on multi-voltage from 5V to 24V DC. To be used with 14.523/14.524.xx push-buttons or similar to adjust the brightness of ceiling lights/spotlights with incandescent or LED bulbs (when fitted). Maximum load 192W (24V). \ 14.520-522-523.02 \ 14.520-522-523.03 \ 14.521-524.01 \ 14.521-524.03 \ 14.521-524.02 \ 14.527.01 \ 14.526.02 \ 14.526.01 \ 14.525.01 \ 14.525.02 \ 14.533.03 \ 14.533.02 \ 14.533.01 \ 14.534.01 \ 14.534.02 \ 14.534.03 \ 14.536.03 \ 14.536.02 \ 14.536.01 \ 14.538.01 \ 14.538.02 \ 14.538.03 \ 14.538.04 \ 14.540.00 \ 14.520-522-523.01
18 New in September 2025 Hot-galvanized calibrated chain OK FOR WINDLASS Suitable for windlasses. The tangles of chain are delivered in wooden boxes or convenient packages easy to handle and stock. Each single metre of chain has an OSC distinctive mark to ensure quality. Length when stretched Ø mm Kg/m Working load kg Breaking load kg Standard P mm B mm 25 m 50 m 75 m 100 m 150 m 01.373.06-025 01.373.06-050 01.373.06-075 01.373.06-100 - 6 0.800 400 1600 DIN766 / ISO 18.5 20 01.373.08-025 01.373.08-050 01.373.08-075 01.373.08-100 - 8 1.400 800 3200 DIN766 / ISO 24 26 01.373.10-025 01.373.10-050 01.373.10-075 01.373.10-100 01.373.10-150 10 2.350 1250 5000 ISO 30 35 - 01.373.11-050 - 01.373.11-100 - 10 2.300 1250 5000 DIN766 28 36 01.373.12-025 01.373.12-050 01.373.12-075 01.373.12-100 01.373.12-150 12 3.350 1800 6500 ISO 36 40 - - - 01.373.13-100 01.373.13-150 13 3.800 2000 8000 DIN766 / ISO 36 47 - 01.373.14-050 - 01.373.14-100 01.373.14-150 14 4.400 2500 10000 DIN766 / ISO 42 47 - - - - 01.373.16-150 16 5.800 3200 12500 DIN766 45 58 - - - - 01.373.17-150 16 5.600 3200 12500 ISO 48 58 Available from November Hot-galvanized calibrated chain, Grade 70 high-resistance type OK FOR WINDLASS GRADE 70 Under the same mechanical resistance conditions, this chains enables the use of a lower section: a) 8-mm OSC-G7 instead of 10-mm standard; b) 10-mm OSC-G7 instead of 12-mm standard. This allows for a 40/60% saving in weight or, weight being equal, a 40 to 60% longer chain. The tangles of chain are delivered in wooden boxes or convenient packages easy to handle and stock. Each single metre of chain has an OSC-G7 distinctive mark to ensure quality. Length when stretched Ø mm Kg/m Working load kg Breaking load kg Standard P mm B mm 50 m 75 m 100 m 150 m 01.370.08-050 01.370.08-075 01.370.08-100 - 8 1.400 1400 5600 DIN766 / ISO 24 26 01.370.10-050 01.370.10-075 01.370.10-100 - 10 2.300 2200 8800 ISO 30 35 - 01.370.11-075 01.370.11-100 - 10 2.350 2200 8800 DIN766 28 36 - 01.370.12-075 01.370.12-100 01.370.12-150 12 3.300 3200 12800 ISO 36 40 Available from November AISI 316 stainless steel calibrated chain OK FOR WINDLASS AISI 316 Suitable for windlasses. The tangles of chain are delivered in wooden boxes or convenient packages easy to handle and stock. Each single metre of chain has an OSC distinctive mark to ensure quality. Length when stretched Ø mm Kg/m Working load kg Breaking load kg Standard P mm B mm 25 m 50 m 75 m 100 m 150 m 01.375.06-025 01.375.06-050 01.375.06-075 01.375.06-100 - 6 0.800 400 1600 DIN766 / ISO 18.5 20 01.375.08-025 01.375.08-050 01.375.08-075 01.375.08-100 - 8 1.400 800 3200 DIN766 / ISO 24 26 01.375.10-025 01.375.10-050 01.375.10-075 01.375.10-100 01.375.10-150 10 2.200 1250 5000 ISO 30 35 - 01.375.11-050 - 01.375.11-100 01.375.11-150 10 2.300 1250 5000 DIN766 28 36 - 01.375.12-050 01.375.12-075 01.375.12-100 01.375.12-150 12 3.200 1800 7240 ISO 36 40 Available from November
19 New in September 2025 Synthetic chamois leather Ultra-absorbent synthetic PVA leather. Absorbs 50% more than normal deerskin, dries perfectly without leaving streaks. Code cm Model Colour 36.642.01 66x43 Big yellow 36.642.03 66x43 Big rose 36.642.04 66x43 Big blue 36.642.02 66x64 Giant yellow \ 36.642.01/02 \ 36.642.01/02 Survival kit in accordance with M.D. 17/09/2024 valid only for Italy Code 22.705.00 This kit is designed for pneumatic units for private use, equipped with CE marking and compliant with UNI EN ISO 6185 parts 3/4, which in case of navigation within 12 nautical miles from the coast can replace the self-inflating raft with the survival kit. Comes in a 50x27x18cm waterproof bag, which contains: - Waterproof bag with retroreflective tape (23.765.03), - Inflation bellows (66.446.77), - Floating knife (10.285.60), - Rope 30 m (22.408.06), - Underwater torch with SOS flash (12.170.04), - Bailer (15.801.05), - Repair kit (66.237.00), - 2 sponges (36.643.00), - Whistle (21.755.00), - Floating anchor (32.756.01), - Floating Levilene rope (22.407.05), - 3x500 ml regulatory water for 6 people (22.705.05), - 2 oars (34.452.17). Important notes: - Add 1 pack of 500 ml of water for every 2 additional people on board, - The oars are not in the bag as they must be kept ready for use. Compact inflatable dinghies, C category CATEGORY C Compact tender with fiberglass hull and PVC air chamber. Suitable for sailing in seas up to force 6 and waves up to 2 meters high. Supplied with a control console, seats with storage, cushions, oars, bow cleat / bow eye pass-through, foot pump, and repair kit. The steering wheel and steering system are to be ordered separately according to your needs. For Italy only, in accordance with D.M. 17/09/24, for navigation within 12 miles from the coast, the life raft can be replaced. Code Length m Width m No. of people Max power HP Ø-cm tubes Air chambers Max load kg. ** 22.690.36 3.6 1.7 5 30 42 3 622 135
20 New in September 2025 \ 48.402.02 Seat with foldable backrest and pull-out padding High-quality vinyl cushions, technopolymer zip fastener. Code Type Colour 48.402.01 Lined with high-quality vinyl White RAL 9010 48.402.02* Lined with high-quality vinyl Light grey + dark grey 48.402.03 Lined with high-quality vinyl White/Blue RAL 9002 + RAL 5013 48.402.05 Frame only, no cushions * Available from November \ 48.409.01 \ 48.409.02 \ 48.409.03 \ 48.409.03 Comfort seat with high foldable backrest Foldable technopolymer core and with storage net pocket. Soft vinyl upholstery with central diamond-shaped stitch texture Code Type Colour 48.409.01 With padding, ready to be covered To be covered 48.409.02 Lined with soft vinyl White RAL 9010 48.409.03 Lined with soft vinyl Light grey + dark grey Available from November \ Storage pocket \ 48.410.10 Ergonomic padded seat with H52 flip-up bolster Rotational moulded plastic core. HD foam padding. Opening in the lumbar region. In compliance with ABYC standards. Code Type Colour 48.410.02 Lined with soft vinyl White RAL 9010 48.410.10* Lined with soft vinyl Light grey + dark grey 48.410.12 With padding, ready to be covered * Available from November \ 48.410.42 \ 48.410.41 Double ergonomic padded seat with H99 flip-up bolster Rotationally moulded plastic core; high-density expanded foam padding; hole in lumbar area. Matches with 48.410.02/12 same shape. Sliding rail 48.715.00 to be purchased separately as OPTIONAL. Code Type Colour 48.410.40 With padding, ready to be covered - 48.410.41* Lined with soft vinyl White RAL 9010 48.410.42* Lined with soft vinyl Light grey + dark grey * Available from November
21 New in September 2025 Base for Maxi Seat Shells GAS SPRING Made of mirror-polished and anodized aluminium. increased diameter tubes of for high resistance and stability. Maximum size sliding rail for installation on all seat shells, even the largest and most comfortable ones. Height-adjustable. Code Height mm Type Table plate mm Pedestal Ø mm Base Ø mm Base finish 48.704.70 300/400 Telescopic 338x265 104/87 305 polished 48.704.71 430/610 Telescopic 338x265 104/87 305 polished 48.704.72 482/711 Telescopic 338x265 104/87 305 polished Available from November Foldable footrest board Anodized aluminium. Code Neck (D) Ø mm Compatible seat bases mm 48.715.02 104 48.704.70; 48.704.71; 48.704.72 400x435 (projection) Leg table leg for table mounting on side bulkhead System for mounting a table leg, consisting of a support plate to be fixed to a side partition and a removable table pedestal The system is easy to assemble and disassemble in a few seconds and stored in the dedicated peak. It matches tables made of composite material 48.417.50; 48.417.51; 48.417.52 Code Type Fixing Tube Ø mm Height mm Depth mm Mounting base Finish 48.722.00 Fixed side 60 555 387 146x146 Polished anodized aluminum Available from November
22 New in September 2025 GRIPPY TRACKER: the signalling buoy with integrated GPS and wireless handheld. MADE IN ITALY GRIPPY Tracker combines a powerful GPS receiver and mechanics able of self-adjust on the anchoring point. A microprocessor system detects high or low tide, the drift caused by currents and high wind, and counteracts any possible false alarm. It also detects attempted theft, tampering, and impacts on the anchor buoy. A very simple and userfrienfly handheld controls monitors the anchor all the time and if it drifts exceeding a preset range, the control immediately warns of the possible danger. Anchor buoy: - Automatic active adjustment of the perpendicular on the anchor for maximum point accuracy, - Autodetect high-low tide, - Possibility of fast charging via USB-C plug, - Battery life of over 5 days in full tracking mode, - ABR System (Automatic Brake Rope: when the device exceeds 90° inclination, while the anchor is sailed, thesliding of the rope is stopped immediately, allowing easy recovery of the buoy directly from its rope). - Buoy rope breaking load: 1000 kg, - Stainless steel safety buoy rope, - Nighttime lighting, - Railing support, - Solar charging. Handheld: - IPS 3.5" touch display, - Rechargeable battery (runtime of over 50 hours). Available in two versions: with or without GSM module included (SMS alarm system). Additionally available as an option, the GHOST function allows for the submersion of the buoy up to 3 meters on command, in scenarios where it might collide with the keel, and to resurface it using ultrasound controls. Code Model Anchor buoy rope length m Anchor buoy rope breaking load kg Stainless steel rescue cable Handrail support Nighttime lighting ABR System Ghost call module OPTIONAL Rechargeable Battery 01.221.02 With standard handheld device 20 1000 Yes, 1200 kg Yes Yes to solar charging Yes 01.221.10 Solar (anchorbuoy), USB Type-C (handheld) 01.221.03 With SMS alarm system included in the handheld device (GSM module) 20 1000 Yes, 1200 kg Yes Yes to solar charging Yes 01.221.10 Solar (anchorbuoy), USB Type-C (handheld) \ 01.221.02/03 \ Wireless handheld \ Wireless handheld \ Handrail support \ 01.221.10 \ Protection for anchor buoy ITALWINCH CS-V windlass AISI 316 Polished AISI316 stainless steel body. Vertical windlass for easy installation. It uses chain or rope/chain. Built-in chain counter sensor. IP67 watertight motor. For boats up to 8 m. Low without drum Motor Current draw A Gypsy Ø-mm chain Line Ø mm Max pull kg Working load kg Line speed m/min V W 02.402.11 12 500 60 6 12 670 90 23 10 02.402.12 12 800 90 6 12 800 100 25 10.5 02.402.13 12 800 90 8 12 800 100 25 10.5
23 New in September 2025 ROCK winch with automatic brake "Auto brake" The self-locking mechanism (activates with a minimum load of 25 kg) allows for safe use of the winch. No external gearing. Casing made of zinc-chromate steel and epoxy powder coating. Code Max pull kg Ratio Cable capacity m Accessories INCLUDED 02.130.02 681 5.1:1 17 m steel cable Ø 4.76 mm 6 m tape 48 mm + carabiner 1/4" 02.130.04 1135 11.1:1 17 m steel cable Ø 6.35 mm 10 m steel cable Ø 6.35 mm + snap hook 1/4" 02.130.05 1588 18.4:1 22 m of steel cable Ø 7.14 mm 10 m steel cable Ø 7.14 mm + snap hook 5/16" \ 02.130.05 Polycarbonate navigation lights with 2W-LED bulb. Made of white polycarbonate with plexiglass lens. Code Type mm LED bulb included 11.507.11 112.5° + 112.5° bicolor 80x58x38h 14.301.21 11.507.12 112.5° left 80x58x38h 14.301.21 11.507.13 112.5° right 80x58x38h 14.301.21 \ 14.301.21 \ 11.507.13 \ 11.507.11 \ 11.507.12 Stainless steel navigation lights with 2W-LED bulb Made of mirror polished AIS-316 stainless steel. Code Type mm LED bulb included 11.507.15 112.5° + 112.5° bicolor 80x58x38h 14.301.21 11.507.16 112.5° left 80x58x38h 14.301.21 11.507.17 112.5° right 80x58x38h 14.301.21 11.507.18 225° bow 80x58x38h 14.301.21 \ 14.301.21 \ 15.507.18 \ 15.507.17 \ 15.507.15 \ 15.507.16 Festoon LED bulb LED Equipped with LED having a 360° light cone. Code V Length mm LED Chip W lumen K Suitable for headlights Package 14.301.20 12 31 4 12 0.7 60 3000 For general use + lights with lampholder 2 pcs 14.301.21* 12 31 4 12 2 60 3000 Compact 12 and 11.507.xx 2 pcs 14.300.32 12 36 8 24 1.2 120 3000 For general use, 36-mm lamp holder centre distance 1 pcs 14.301.22 12 38 8 24 1.4 120 3000 Classic 12 / Utility 85 / Utility 77 2 pcs 14.301.24 12 44 12 36 2 180 3000 Maxi 20 2 pcs * High power version (2 W) \ 14.301.21 Battery switch Made of brass and bakelite, brass and silver-plated copper contacts. High-capacity industrial model (350 A 24 V - 2500 A (5 seconds). Code Pins mm 14.386.14 12 Fairlead gland Made of watertight nylon, for electric cables. Code Base Ø mm Overhang mm For cables mm 14.185.95 48 33 5-8 14.185.96 51 36 7-12 14.185.97* 52.5 48 10 - 16 * Available from November
24 New in September 2025 \ 16.104.42 Hose for outboard engine cable passage Reinforcement spiral. Manufactured in the same dimensions as those of OMC, Yamaha, Mercury, etc. original hoses. Code Colour Material Inside Ø mm Roll m Description Connection bush 16.104.38 grey PVC 50.8 10 PVC spiral hose with rigid PVC spiral 16.104.39; 16.104.40; 16.104.41 16.104.37 white PVC 50.8 10 PVC spiral hose with rigid PVC spiral 16.104.39; 16.104.40; 16.104.41 16.104.42 grey EVA 53 10 Deformation-resistant EVA spiral hose 16.104.39; 16.104.40; 16.104.41 Silicone sealant to optimise sealing between hose connector and hose Loxeal 59-30 is a mono-component acetic crosslinking silicone sealant. It ensures high performance at high temperatures and/or high pressures. Specific for sealing hose and hoseholder, both metal and plastic. Effective even in case of non perfect couplings, non-ideal dimensional tolerances. • Operating temperature: from -60°C to +250°C, with peaks up to +300°C • Appearance: viscous paste • Initial curing time: 10–20 minutes • Overall curing time: 24 hours for 2mm- thickness • Disassembly: allows disassembly using standard tools Code Colour Cartridge 17.100.11 red 75 ml Anaerobic PTFE sealant for threads Loxeal 18-10 is a low-strength anaerobic sealant formulated with PTFE, designed to ensure reliable sealing of threaded metal/metal or metal/plastic joints. Ideal for applications such as seawater intakes and ball valves. Effective sealant for gas, LPG, compressed air, oils, fuels, industrial fluids, and drinking water. The cured product forms an elastic film that resists vibrations, impacts, and thermal shocks, maintaining its sealing properties over time. Replaces P.T.F.E. tapes and hemp. • Viscosity (+25°C): 17,000–70,000 mPa·s (high thixotropy) • Operating temperature: from -55°C to +150°C • Curing time for handling: 20–40 minutes • Functional curing time: 1–3 hours • Residual torque: 2–5 N·m (ISO 10964) Code Colour Cartridge 17.100.10 white 250 ml
25 316 stainless steel spare baskets for GUIDI Ionio water strainers. Code G Nozzles-Ø D mm D1 mm H mm For strainer 17.646.00 3/4" - 1" 74 36 100 17.648.01 / 17.648.02 17.646.01 1"1/4 87 40 123 17.648.03 17.646.02 1"1/2 98 54 131 17.648.04 17.646.03 2" 124 64 160 17.648.05 17.646.04 2"1/2 155 93.5 188 17.648.06 17.646.05 3" 155 93.5 215 17.648.07 Rudder angle indicator Red and yellow backlit dial. Black dial, black bezel Black dial, glossy bezel White dial, glossy bezel Signal V mm Ø hole Ø P 27.320.18 27.321.18 27.322.18 0-190 Ω 12/24 57 51 45 \ 27.320.18 \ 27.321.18 \ 27.322.18 Professional WiFi weather station Weather station with a 5-in-1 sensor and WiFi connection, allowing for fullscreen display. Facts supplied: - Time (12 or 24 hour format) and date + calendar + weekdays in 15 languages - Double alarm with snooze mode - Inside/Outside temperature with minimum/maximum memory - Temperature perception with minimum/maximum memory - Indoor/outdoor humidity with minimum/maximum memory - Comfort level - Weather forecast - Barometric pressure - Rainfall - Wind speed and direction - Light and UV index - Heat index and dew point - WiFi connection through Tuya App and history on the same - Adjustable backlight - USB charging port - Frequency 433 MHz Code Base dimensions mm Sensor dimensions mm 28.918.05 205x32x130 350x47x135 Highly absorbent sponge. Code 36.643.00 High absorption capacity, extra durable and easy to handle. Retractable clothesline Code 38.330.01 Stainless steel retractable clothesline with self-tensioning nylon cable 2.8 m for bulkhead installation. Size-reduced when closed. Available from November New in September 2025
26 New in September 2025 Awning with telescopic arms, rigid roofs, Flying Bridge roofs Stainless steel telescopic arms (1.3/2 m) to slip into the fishing rod holder. Adjustable height. It can be folded when not in use. Usable open up to a speed of 20 knots. ATLAS fabric 310 gr/m2 waterproof, UV resistant and breathable. white Blu navy Black A cm B cm C cm 46.907.31 46.907.01 46.907.21 180 150 120 46.907.33 46.907.03 46.907.23 210 210 150 46.907.35 46.907.05 46.907.25 260 200 170 46.907.37 46.907.07 46.907.27 260 230 200 - 46.907.09 - 290 260 230 - 46.907.11 - 290 290 260 \ 46.910.01/04 \ 46.910.02/05 Oceansouth T-Top extension Extension kit designed to expand the shaded area. To be installed universally on any T-Top equipped with at least 2 rod holders 220g/m2 fabric in ATLAS waterproof and UV-resistant polyester; stainless steel telescopic tubes. No tools or drilling required for installation; easily removable for storage after use. white Blu navy Black A cm B cm 46.910.01 46.910.03* 46.910.02 137 121 46.910.04 46.910.06* 46.910.05 182 152 * Available from January 2026 Tailored cover for Yamaha engines Specifically shaped for the engine model, suitable for open area storage. Made of ATLAS 340 g/m2 fabric, waterproof, breathable and UV resistant. For engine head Colour Motor HP Year Leg Ventilated – can also be used during navigation 46.541.53 Black V6 VMAX SHO 200/250 2022-2024 - 46.541.28 white 4 cylinders 4T 1.8L F75D F90C/ F100F + VMAX90 2017> 20" Tailored cover for Suzuki engines Specifically shaped for the engine model, suitable for open area storage. Made of ATLAS 340 g/m2 fabric, waterproof, breathable and UV resistant. For engine head Colour Motor HP Year Leg Ventilated – can also be used during navigation 46.542.22 white V6 4T 3.6L DF200/225/250 2003> 25"
27 New in September 2025 Black aluminium Top II nameplate 44-mm-Ø tubular structure made of- painted aluminium and black epoxy resin. Frame for fabric top with 32.0-mm-Ø tubes . ATLAS fabric made of black polyester 400 gr/m2, waterproof and UV resistant. Hardware in stainless steel AISI 316. Aerodynamic design for travelling in total comfort up to 35-40 knots. Code Tube Ø mm top Width at base mm Length mm Width mm Height mm 48.195.16 44 1700 1600 1300 1700-1900 48.195.17 44 1700 1800 1300 1900-2100 48.195.18 44 1700 2000 1300 2100-2300 48.194.04 Fishing rod holder for 32-mm Ø tube Available from November \ 48.194.04 Anodized aluminum T-Top Manufactured in anodized tube Ø 32 mm. Universal, as the fittings can be adjusted at will. The fabric of the "Top" is in blue ATLAS polyester 400 g/m2, waterproof and UV resistant. All components are corrosion-resistant. Code Tube Ø mm Length A mm Width B mm Max width of console A1 mm Max height C mm Colour 48.194.11 32 1700 1200 1000 2010 blue 48.194.21 32 1700 1200 1000 2010 Black 48.194.12 32 1700 1400 1000 2010 blue 48.194.22 32 1700 1400 1000 2010 Black 48.194.04 Fishing rod holder for 32-mm Ø tube 48.194.03 Supports for navigation lights. Available from November \ 48.194.04 \ 48.194.03 Full cover for steering console with T-TOP Easy to position, it attaches under the T-Top. Elastic band in the seating area to ensure good adhesion. Complete closure using zipper and nylon strap with snap buckles for adjustment. Waterproof, breathable and UV-resistant ATLAS polyester fabric, 240 g/m2. grey Length mm Width mm Height mm 48.189.02 1500 1200 1800 48.189.03 1830 1200 1800 48.189.04 2150 1300 1800
28 New in September 2025 \ 14.351.16 \ 14.352.16/32 RATIO sockets and plugs Built-in 3-pole male socket with waterproof cover and rear cover for cable protection, contacts in silver-plated brass. Female flying plug (made of polycarbonate + Moplen) with cable locking system and silver-plated brass contacts; PVC plug cap with quick-rotation ring in UV-resistant Luran. Code Type Description A V 14.351.16 Socket Made of white polyamide 16 250 14.352.16 Socket Made of stainless steel 16 250 14.352.32 Socket Made of stainless steel 32 250 14.353.16 plug Made of thermoplastic 16 250 14.353.32 plug Made of thermoplastic 32 250 \ 14.353.16/32 RATIO cables Dock power cables for 16/25/32A (up to 250V). Top quality cables made of yellow PUR and moulded connectors. Watertight and long-lasting. Marine plug provided with a bayonet ring for watertight connection to the boat power socket. Voltage indicator and a protective cover included. Code Length m V A Cable section mm 14.354.15 15 250 16 3x1.50 14.355.15 15 250 16 3x2.50 14.356.15 15 250 32 3x4 14.356.25 25 250 25 3x4 14.357.25 25 250 32 3x6 \ 66.240.23 \ 66.240.03/04 \ 66.240.24 ADECO adhesive for neoprene and PVC fabrics Special bicomponent adhesives for inflatable boats made of neoprene and PVC. The most widely used in the market by all inflatable boat manufacturers. For dinghies Package Activator ml Description Sold to neoprene 66.240.02 2 kg 160 g Can + activator DIY 66.240.03 2 kg 160 g Can + activator Professionals 66.240.04 4.2 kg 750 g Can + activator Professionals 66.240.25 DIY spare activator 160 g. 66.240.23 Spare activator for professional use 160 g. 66.240.24 Spare activator for professional use 750 g. \ 19.355.10 \ 19.355.11 Flyscreen mesh for hatches for outdoor purposes Mosquito net for external mounting on the manhole. Instant attachment via weighted tape at the base. Code mm 19.355.07 360x360 19.355.08 430x300 19.355.09 530x530 19.355.10 620x620 19.355.11 720x720 \ 22.429.01 \ 22.429.02 \ 22.429.03 Bracket for ring lifebuoys Designed for use at beaches, pools, etc. Fits lifebuoys Ø 75 cm. Code Description 22.429.01 Universal life buoy support 22.429.02 160-mm high galvanized steel pole 22.429.03 Universal ring holder in plastic with cover Ring life buoy and line not included.
29 New in September 2025 TECMA Nano electric toilet bowl The Nano is the shortest model on the market combining comfort, reliability and performance. As silent as the other Tecma electric bowls, it is as short as 295 mm. Italian white ceramic, thermosetting polyester seat. Eco Rocker Switch control panel included. Fitted with solenoid to bypass the onboard plumbing. For installation with sea water inlet pump, order code 16.525.12 / 16.525.24 or similar. Code Model V mm Height Width depth 50.228.00 Nano 12 295 370 446 17.6 50.228.01 Nano 24 295 370 446 17.6 \ Control panel White gelcoat spray SPRAY Single-component gelcoat for quick touch-ups on fiberglass parts. Levels surface porosity and results in a satin finish of the applied color. Code Colour Package ml 65.520.11 White RAL 9003 400 65.520.21 Creamy white RAL 9010 400 65.520.22 Offwhite RAL 9001 400 Neutral colour gelcoat filler High resistance two-component gelcoat filler. To be used like a regular filler to be knifed-out. Restores the original chipped, scratched or dented gelcoat surface. Use coloring pastes (65.520.3x) to obtain the desired color. Code Package g 65.520.26 200 Polyester colorant paste for neutral gelcoat Single-component tubes to be matched with gelcoat 65.520.26. Available in various colors. Use the online available "colour wheel" obtain any desired shade of colour. Code Colour Package g 65.520.30 red 30 65.520.31 yellow 30 65.520.32 Black 30 65.520.33 brown 30 65.520.34 green 30 65.520.35 Sand 30 65.520.36 blue 30 \ Colour wheel Smooth tabletops ARC teak Fitted with edges and drains on each angle. Code mm 71.307.00 400x700 71.307.10 550x800 71.307.11 Ø 800 71.307.01 500x700 \ 71.307.00/01/10 \ 71.307.11
