News March 2026 2 \ 14.870.01/02 - 14.871.01 \ 14.870.03/04/06 - 14.871.02/03 \ 14.870.05 EGIS XD Flex Battery Disconnect The XD Flex series from Egis Mobile Electric is a modular platform for high-performance bistable battery disconnect relays, designed for applications with lead, AGM, GEL, LiFePO₄, or hybrid lead/ lithium systems. The range is optimized to handle both traditional voltage curves of lead batteries and the typical electrical behavior of lithium batteries, ensuring stable and reliable operation even with constant voltages and rapid load changes. Available in configuration: - Single; - Double; - Triple. The devices may include: - Remotely controllable relays; - Mechanical relays (manual only); - Combinations of the two types. Each electronic relay can be configured as: - Bistable battery disconnect relay: remote ON / OFF control via switch or control signal; - Voltage sensitive relay (VSR / ACR): Fully automatic management of connecting and disconnecting batteries based on voltage levels. Each XD Relay features: - Manual selector ON / LOCK OFF to force the relay state; - LED status indicator. In VSR mode, the system automatically manages the relays without manual intervention, optimizing the charging and isolation of the batteries. In relay mode, contacts can be controlled via external ON / OFF switches. Mechanical relays operate exclusively in manual mode and do not include electronic logic or automatic management. XD Flex models do not support NMEA 2000 integration or display on MFD. \ 14.870.07 \ 14.870.08 - 14.871.04 \ 14.870.09 Code Setup Position in the system Power supply V DC Max capacity A Dimensions (HxWxD) mm Use Continuous current Intermittent current Current peak (30 sec.) 14.870.01 VSR Everywhere 8-36 500 700 1500 95x66x50 Lead/AGM/Gel 14.870.02 Relay Everywhere 8-36 500 700 1500 95x66x50 Lead/AGM/Gel 14.870.03 VSR/Relay Right of the triple 8-36 500 700 1500 95x115x51.8 Lead/AGM/Gel 14.870.04 Relay/VSR Left of the triple 8-36 500 700 1500 95x115x51.8 Lead/AGM/Gel 14.870.05 Relay/Relay Everywhere 8-36 500 700 1500 95x115x51.8 Lead/AGM/Gel 14.870.06 VSR/Mech Right of the triple 8-36 500 700 1500 95x115x57.8 Lead/AGM/Gel 14.870.07 2-Pole Relay Everywhere 8-36 500 700 1500 95x164x51.8 Lead/AGM/Gel 14.870.08 Relay/VSR/Relay Everywhere 8-36 500 700 1500 95x164x51.8 Lead/AGM/Gel 14.870.09 Mech/VSR/Mech Everywhere 8-36 500 700 1500 95x164x57.8 Lead/AGM/Gel 14.871.01 VSR Everywhere 8-36 500 700 1500 95x66x50 Lithium 14.871.02 VSR/Relay Right of the triple 8-36 500 700 1500 95x115x51.8 Lithium 14.871.03 Relay/VSR Left of the triple 8-36 500 700 1500 95x115x51.8 Lithium 14.871.04 Relay/VSR/Relay Everywhere 8-36 500 700 1500 95x164x51.8 Lithium 14.890.01 Connection Bar for XD Relay 14.890.02 Connection bar for XD Relay with increased pitch 14.890.03 Connecting bar for XD Relay, L-shaped 14.890.04 Connecting bar for XD Relay, square shape \ 14.890.01 \ 14.890.02 \ 14.890.03 \ 14.890.04
News March 2026 3 EGIS XD NMEA 2000 Battery Disconnect The XD NMEA 2000 series from Egis Mobile Electric is a high-performance system consisting of bistable battery disconnect relays and voltage-sensitive relays (VSR / ACR), with integrated control and monitoring via the NMEA 2000 network. The devices are available in single, double, and triple configurations. Dual devices available in one of the following configurations: - Left relay / Right relay; - Left relay / right VSR; - Left VSR / Right Relay. The configuration is factory-set and cannot be modified in the field. Triple devices are available with a preset configuration (from left to right): - Relay / VSR / Relay: Only the central position can be configured as a Relay or VSR. In triple devices, the function of the central position is defined by the part number but can be modified in the field via DIP switch on the back of the device. Configuration via DIP switches allows setting: - NMEA 2000 network parameters (e.g., instance number, battery selection to monitor); - VSR activation and deactivation voltage thresholds. The operation is similar to other products in the XD series. Each position can support: - Battery disconnect relay; - Voltage sensitive relay (VSR); - Manual control ON / LOCK OFF; - Local and remote LED status indication; - Monitoring via NMEA 2000 network. XD NMEA 2000 devices transmit directly on the network: - Relay status; - State of the manual override; - Battery voltage. \ 14.872.01/02 \ 14.872.03/04/05 \ 14.872.06 Code Setup Position in the system Power supply V DC Max capacity A Dimensions (HxWxD) mm Use Continuous current Intermittent current Current peak (30 sec.) 14.872.01 VSR Everywhere 8-36 500 700 1500 95x66x50 Lead/AGM/Gel 14.872.02 Relay Everywhere 8-36 500 700 1500 95x66x50 Lead/AGM/Gel 14.872.03 VSR/Relay Right of the triple 8-36 500 700 1500 95x115x51.8 Lead/AGM/Gel 14.872.04 Relay/VSR Left of the triple 8-36 500 700 1500 95x115x51.8 Lead/AGM/Gel 14.872.05 Relay/Relay Everywhere 8-36 500 700 1500 95x115x51.8 Lead/AGM/Gel 14.872.06 Relay/VSR/Relay Everywhere 8-36 500 700 1500 95x164x51.8 Lead/AGM/Gel 14.890.01 Connection Bar for XD Relay 14.890.02 Connection bar for XD Relay with increased pitch 14.890.03 Connecting bar for XD Relay, L-shaped 14.890.04 Connecting bar for XD Relay, square shape \ 14.890.01 \ 14.890.02 \ 14.890.03 \ 14.890.04
News March 2026 4 \ 13.228.01/02 \ 13.225.49 \ 13.228.21/22 \ 13.225.59 Aldebaran Combo LED searchlight with console-operated joystick Body: diecast aluminium coated in white high-resistance and anti-corrosion resins. 100% watertight. 2-speed 355° horizontal rotation. 50° vertical rotation. Combo high-quality LED unit. 54W consumption corresponding to a traditional 100 W bulb. Version with powerful central 40+40 W-LED (replaceable in case of breakage). Dual-function device Spot light with concentrated (20°) and Flood broad light (45°). Protection against electronic interference. Headlights can be connected to 2 types of optional controls (independent or combined) for the desired configuration: 1) Console-operated joystick. 4.5-m cable included. Additional joystick controls to be installed via the 2-port cable 13.227.51. 2) Traditional remote control with bracket for dashboard installation. Range up to 40 m from the lighthouse. \ 13.225.31 \ 13.227.51 \ 13.225.50 Code Lighthouse colour V CD candles* W K lumen Range 0.25 lux* Joystick control INCLUDED or 2nd control OPTIONAL wireless remote control Connection cable for second joystick 4.5m 10 m extension cable for Joystick 13.228.01 white 12 200.000 40+40 6000 3000 895 13.225.49 13.225.50 13.227.51 13.225.31 13.228.21 Black 12 200.000 40+40 6000 3000 895 13.225.59 13.225.50 13.227.51 13.225.31 13.228.02 white 24 200.000 40+40 6000 3000 895 13.225.49 13.225.50 13.227.51 13.225.31 13.228.22 Black 24 200.000 40+40 6000 3000 895 13.225.59 13.225.50 13.227.51 13.225.31 * To be measured at the centre of the light beam. \ 13.225.50 \ 13.225.49/59 \ 30.596.01 \ 30.596.05 \ 30.596.05 \ 30.596.05 LED warning light IP67 It signals obstacles, signalling buoys, wharves, harbour entrances, etc. Fitted with seagull deterrent. Powered by lithium batteries charged via a mini solar panel. The light comes with a bracket and clamp for 18/32-mm tubes; UV-, oil- and corrosion-resistant; CE type-approved. Switching on: 1 - Automatic switch-on modes with flashing mode cycle (4 flashes in sequence x 52 cycles/minute). 2 - 30-m reach radio remote control. 3 - Manual. Manually- or radio remote control-operated functions: VERSION A - White fixed light. - White single FLASH. - White flashing light (4 FLASHES in sequence) - White SOS light. - Off. VERSION B - White fixed light. - White single FLASH. - White flashing light (4 FLASHES in sequence) - White SOS light. - Fixed three-color light (white/red/green); - Fixed red and green lights; - Off. Dimensions: 115x73 mm; weight: 225 gr + 120 gr (bracket). Code Light Version Visibility in nautical miles Battery life hours at 100% charge Flash Fixed Light Flash S.O.S Fixed Light 30.596.01 white A 1.5 2.0 300 30 12 30.596.05 RGW B 3.4 2.0 150 30 12
News March 2026 5 Removable tender chocks RAPID MARINE MADE IN UK UNIVERSAL Designed and manufactured in the United Kingdom, these self-adjusting universal mounts are handcrafted and designed to support most tenders up to 1000 kg; to be mounted on the swim platform, fly bridge or on the deck. The kit includes two types of mounts for securing the chocks: Flush fittings: They are fully recessed and leave the swim platform completely smooth. Low-profile fittings: Leave a protrusion of 5 mm. The kit (RMC500) includes: 2 universal chocks, 4 flush type fittings, 4 low profile fittings, and the fixing screws. Code Capacity kg supports LxPxH mm Padaye Anchoring Kit (optional) 22.505.01 1.000 590x160x230 22.505.10; 22.505.11 \ FLUSH Version \ Low Profile Version Ratchet tie-down straps with quick recessed coupling RAPID MARINE Set of 3 straps with a 'T' end for quick attachment to specific pad-eyes. Code Padeye type Belt thickness mm Up to kg Belt length m 22.505.10 Flush 25 500 1.2 22.505.11 Low profile 25 500 1.2 \ Low Profile Version \ 22.505.11 \ 22.505.10 \ FLUSH Version
