19 Anchors, bowsprits and shock absorbers 01 Trefoil® anchor made of hot-galvanized cast steel With progressive penetration system. Code A mm B mm C mm 01.110.02 2 175 358 210 01.110.05 5 273 469 310 01.110.07 7.5 298 531 360 01.110.10 10 320 583 375 01.110.13 12.5 330 630 395 01.110.15 15 335 655 425 01.110.20 21 395 701 470 01.110.30 32 410 800 560 01.110.50 50 470 980 660 01.110.80 80 560 1100 720 Trefoil® anchor made of mirror-polished AISI316 stainless steel AISI 316 Hand-crafted investment cast steel. Perfect aesthetic and dimensional result. Code A mm B mm C mm 01.109.25 2.5 170 357 235 01.109.05 5 240 470 320 01.109.07 7.5 270 540 360 01.109.10 11 310 590 385 01.109.15 15 335 645 450 01.109.20 20 355 660 475 01.109.30 30 410 815 560 01.109.50 50 495 1000 665 Trefoil® stainless steel slide anchor with gripping plate Slide anchor with lock for low bows (similar to rubber dinghies) and inverted bows. Code A mm B mm C mm 01.117.10 10 320 570 385 Trefoil® folding grapnel anchor made of hot-galvanized cast steel PATENT The huge holding power of Trefoil® anchors combines with the convenience of folding grapnel anchors that are easily stowed onboard. Code A mm B mm C mm 01.104.05 5 240 469 315 01.104.07 7.5 273 531 361
20 Anchors, bowsprits and shock absorbers 01 LEWMAR C.Q.R.® anchor Lifetime warranty against breaks and Lloyd's Test Certification as High Holding Power anchor. Metal frame Forged Recommended chain mm Recommended for hulls up to m A mm B mm C mm D mm E mm 01.147.07 01.145.65 7 6 6 626 253 82 439 287 01.147.09 01.145.09 9 8 9 690 279 86 484 313 01.147.11 - 11 8 11.5 740 299 90 552 336 01.147.16 - 16 8 14 827 335 94 584 373 01.147.20 - 20 10 18 901 366 100 635 405 01.147.27 - 27 10 19 989 402 106 700 445 01.147.34 - 34 11 20 1071 435 112 754 481 - 01.145.64 66 12.5 22 1337 537 128 933 583 \ 01.127.xx LEWMAR Epsilon anchor SUPER-HIGH HOLDING POWER Deriving its sturdiness and quality from the Delta anchor, the Epsilon anchor is Super-High Holding Power certified by Lloyd. Its concave fluke and ballasted keel ensure record holding and super-fast grip. Stainless steel Recommended chain mm Recommended for hulls up to m A mm B mm C mm 01.127.06 6 6-7 10 483 271 8 01.127.10 10 8 13 573 332 10 01.127.16 16 8 15 670 376 12 01.127.20 20 10 17 720 406 12 01.127.25 25 10 18 778 438 16 01.127.32 32 10 21 839 474 16 01.127.40 40 10 23 907 512 20 01.127.50 50 12 25 974 550 20 01.127.63 63 12 27 1049 595 22 LEWMAR Delta® zinc-plated steel anchor HIGH HOLDING POWER Its best features include: - Exceptional holding power to grab into any seabed (including seaweed grounds). - Quickness to re-grab the hold when the spinning boat tends to trip the anchor. - Real ability to improve its hold when the wind increases. Tests carried out under various conditions confirm that the Delta anchor has the best hold/weight rate. Lifetime warranty against breaks and Lloyd's Test Certification as High Holding Power anchor. Code Recommended chain mm Recommended for hulls up to m A mm B mm C mm D mm E mm 01.108.04 4 6-7 7 514 228 8 387 210 01.108.06 6 6-7 9 595 263 10 450 241 01.108.10 10 8 11 695 308 12 526 283 01.108.16 16 8 13 812 360 12 614 334 01.108.20 20 10 15.5 877 389 16 663 361 01.108.25 25 10 17 945 417 16 713 384 01.108.32 32 10 18.5 1026 455 16 774 417 01.108.40 40 10 20 1099 489 20 835 446 01.108.50 50 12 23 1175 520 20 890 479 01.108.63 63 12 26.5 1278 568 22 673 518 LEWMAR Delta® DTX stainless steel anchor New version of the renowned Delta Inox, DTX is 100% of 316 stainless steel. With unchanged and patented geometry, still unmatched, it ensures high holding power to grab into any seabed and quickness to re-grab the hold under all conditions. Certified as Ordinary Holding Power, 3-year warranty. Code Recommended chain mm Recommended for hulls up to m A mm B mm C mm D mm E mm 01.106.10 10 8 9.5 695 310 13 526 282 01.106.16 16 8 13 812 362 13 614 328 01.106.20 20 10 15.5 877 392 16 663 357 01.106.25 25 10 17 945 415 16 713 387 01.106.32 32 10 19 1023 453.5 20 775 425
21 Anchors, bowsprits and shock absorbers 01 LEWMAR Delta® stainless steel anchor HIGH HOLDING POWER Ultra-resistant stainless steel version with the same high performance as the standard Delta. Lifetime warranty against breaks and Lloyd's Test Certification as High Holding Power anchor. Code Recommended chain mm Recommended for hulls up to m A mm B mm C mm D mm E mm 01.107.10 10 8 11 695 308 12 526 283 01.107.16 16 8 13 812 360 12 614 334 01.107.20 20 10 15.5 877 389 16 663 361 01.107.25 25 10 17 945 417 16 713 384 01.107.40 40 10 20 1099 489 20 835 446 01.107.50 50 12 23 1175 520 20 890 479 01.107.63 63 12 26.5 1278 568 22 673 518 Folding grapnel anchors - Hot galvanized cast steel version. Counterweight bar fitted to the shank to improve anchor balance (Norwegian SAV system). - Mirror-polished AISI 316 stainless steel version, ideal for dinghies. Hot-galvinized cast steel Mirror-polished AISI 316 SS A mm B mm C mm 01.139.00 - 0.7 175 165 48 01.139.15 01.138.15 1.5 310 265 75 01.139.25 01.138.25 2.5 360 315 85 01.139.32 - 3.2 420 365 100 01.139.04 01.138.04 4 470 380 110 01.139.06 - 6 565 440 130 01.139.08 - 8 575 490 140 01.139.10 - 10 610 595 130 01.139.12 - 12 650 640 130 \ 01.138.xx \ 01.139.xx DANFORTH type galvanized anchor Made of hot-galvanized steel. Very thick plate. Code A mm B mm C mm 01.143.04 4 505 425 295 01.143.06 6 610 450 335 01.143.08 8 670 460 380 01.143.10 10 705 525 420 01.143.15 15 885 635 570 01.143.20 20 1001 670 585 01.143.30 30 1008 760 655 DANFORTH type AISI316 anchor AISI 316 Mirror-polished AISI316 stainless steel anchors. Ideal for muddy and sandy seabeds. Code A mm B mm C mm 01.146.07 7 630 485 340 01.146.09 9 670 500 400 01.146.12 12 760 540 420 01.146.15 15 900 570 430 01.146.20 22 990 665 515 01.146.28 28 1080 695 550
22 Anchors, bowsprits and shock absorbers 01 Hall traditional anchor Sturdy hot-galvanized steel anchor for any seabed. Fitted with sharp-angle articulated arm. Code A mm L1 mm L4 mm 01.142.25 2.5 290 160 140 01.142.04 4 320 180 170 01.142.05 6 350 210 210 01.142.08 8 380 230 230 01.142.10 10 400 240 240 Hall anchor Made of hot-galvanized cast iron. Code A mm L1 mm L4 mm 01.103.18 16 330 310 230 01.103.28 23 350 350 245 01.103.36 34 410 395 280 01.103.48 45 465 445 325 01.103.65 60 505 505 315 Plough anchor Made of very thick high-strength hot-galvanized steel. Similar to CQR anchors, excellent performance on all seabeds. Code A mm B mm C mm D mm E mm F mm G mm 01.144.07 7 260 640 340 230 540 220 55 01.144.09 9 330 780 410 280 600 280 65 01.144.12 12 320 800 430 280 650 280 65 01.144.16 16 380 950 500 320 760 310 75 01.144.22 22 400 1050 490 360 800 345 80 01.144.27 27 520 1090 520 380 830 380 85 01.144.35 35 580 1110 580 410 920 410 95 Admiralty anchors. Hot-galvanized steel anchor with foldable flukes for better stowage. Code A mm B mm C mm D mm E mm F mm 01.114.05 5 382 50 60 380 205 230 01.114.10 10 490 60 70 500 255 280 01.114.15 15 550 60 80 542 290 320 01.114.20 20 590 68 90 600 340 360 01.114.25 23.5 615 68 90 640 340 360 01.114.35 35 660 75 130 780 370 400
23 Anchors, bowsprits and shock absorbers 01 NEW Detachable anchors LEWMAR LFX anchor Made from high-quality anodized aluminum, the LFX anchor offers exceptional corrosion resistance. Code Recommended chain mm Recommended for hulls up to m OPTIONAL storage bag Amm Bmm C mm 01.111.02 2 6 8 01.098.01 564 462 342 01.111.03 3.2 6-7 10 01.098.01 672 550 407 01.111.04 4.5 8 12 01.098.01 746 610 452 01.111.07 7 10 14 01.098.02 853 699 517 01.111.10 10 10 16 01.098.02 954 781 579 Demountable FORTRESS anchors Adjustable fluke angle to adapt to any seabed. Made of sturdy nodized aluminium-magnesium alloy. Ideal as sheet anchor. Cited as the best anchor currently available on the market, it came out top in five independent tests, one of which was carried out by the U.S. Navy. Code Replaces SS anchors kg For hull size m OPTIONAL cavas stowage bag A mm B mm C mm 01.100.11 3.4 4/6 8/10 01.099.02 685 559 406 01.100.16 4.5 6/8 10/12 01.099.03 787 635 457 01.100.23 6.8 8/13 12/14 01.099.04 914 737 533 01.100.37 9.5 13/23 14/16 01.099.05 1016 813 610 01.100.55 14.4 23/29 16/18 01.099.06 1168 940 686 01.100.85 21.2 32/41 - - 1300 1040 760 \ 01.099.xx 2026 Demountable ANKERPLEX anchors EASY ASSEMBLING NO TOOL PATENT High-performance folding anchors, made of galvanized iron, stainless steel or anodized aluminum. The patented design with three flat elements ensures maximum holding power, lightness, and quick assembly without tools. Ultra-thin and space-saving, it is ideal as a primary, secondary, or emergency anchor for vessels of all kinds. Code Model Material Weight (Kg) Dimensions Stowage bag Dimensions bag mm A (mm) B (mm) C (mm) D (mm) E (mm) 01.160.01 AP1ST Stainless steel 1.5 412 199 206 5 3 01.163.01 48x24 01.161.01 AP1GZ HDG 1.5 01.160.05 AP5ST Stainless steel 5.1 595 291 301 8 4 01.163.02 70x31 01.161.05 AP5GZ HDG 5 01.162.05 AP5AL Aluminium 1.7 01.160.08 AP8ST Stainless steel 8 664 325 335 10 5 01.161.08 AP8GZ HDG 7.8 01.162.08 AP8AL Aluminium 2.6 01.160.11 AP11ST Stainless steel 11.4 794 389 402 01.163.03 87x43 01.161.11 AP11GZ HDG 11.2 01.162.11 AP11AL Aluminium 4.5 01.160.16 AP16ST Stainless steel 16.6 876 428 443 12 6 01.161.16 AP16GZ HDG 16.3 01.162.16 AP16AL Aluminium 6.9 01.160.20 AP20ST Stainless steel 19.8 955 467 482 01.163.04 110x50 01.161.20 AP20GZ HDG 19.4 01.162.20 AP20AL Aluminium 8.2 01.160.27 AP27ST Stainless steel 27.2 1004 491 506 15 8 01.161.27 AP27GZ HDG 26.8 01.162.27 AP27AL Aluminium 11.9 01.162.31 AP31AL Aluminium 13.7 1075 525 540 20 10 01.163.05 133x63 01.162.50 AP50AL Aluminium 16.5 1180 577 595 01.162.60 AP60AL Aluminium 20 1298 635 655
24 Anchors, bowsprits and shock absorbers 01 NEW Chains, connectors and anchoring accessories Hot-galvanized calibrated chain OK FOR WINDLASS Suitable for windlasses. The tangles of chain are delivered in wooden boxes or convenient packages easy to handle and stock. Each single metre of chain has an OSC distinctive mark to ensure quality. Length when stretched Ø mm Kg/m Working load kg Breaking load kg Standard P mm B mm 25 m 50 m 75 m 100 m 150 m 01.373.06-025 01.373.06-050 01.373.06-075 01.373.06-100 - 6 0.800 400 1600 DIN766 / ISO 18.5 20 01.373.08-025 01.373.08-050 01.373.08-075 01.373.08-100 - 8 1.400 800 3200 DIN766 / ISO 24 26 01.373.10-025 01.373.10-050 01.373.10-075 01.373.10-100 01.373.10-150 10 2.350 1250 5000 ISO 30 35 - 01.373.11-050 - 01.373.11-100 - 10 2.300 1250 5000 DIN766 28 36 01.373.12-025 01.373.12-050 01.373.12-075 01.373.12-100 01.373.12-150 12 3.350 1800 6500 ISO 36 40 - - - 01.373.13-100 01.373.13-150 13 3.800 2000 8000 DIN766 / ISO 36 47 - 01.373.14-050 - 01.373.14-100 01.373.14-150 14 4.400 2500 10000 DIN766 / ISO 42 47 - - - - 01.373.16-150 16 5.800 3200 12500 DIN766 45 58 - - - - 01.373.17-150 16 5.600 3200 12500 ISO 48 58 Hot-galvanized calibrated chain, Grade 70 high-resistance type OK FOR WINDLASS GRADE 70 Under the same mechanical resistance conditions, this chains enables the use of a lower section: a) 8-mm OSC-G7 instead of 10-mm standard; b) 10-mm OSC-G7 instead of 12-mm standard. This allows for a 40/60% saving in weight or, weight being equal, a 40 to 60% longer chain. The tangles of chain are delivered in wooden boxes or convenient packages easy to handle and stock. Each single metre of chain has an OSC-G7 distinctive mark to ensure quality. Length when stretched Ø mm Kg/m Working load kg Breaking load kg Standard P mm B mm 50 m 75 m 100 m 150 m 01.370.08-050 01.370.08-075 01.370.08-100 - 8 1.400 1400 5600 DIN766 / ISO 24 26 01.370.10-050 01.370.10-075 01.370.10-100 - 10 2.300 2200 8800 ISO 30 35 - 01.370.11-075 01.370.11-100 - 10 2.350 2200 8800 DIN766 28 36 - 01.370.12-075 01.370.12-100 01.370.12-150 12 3.300 3200 12800 ISO 36 40 AISI 316 stainless steel calibrated chain OK FOR WINDLASS AISI 316 Suitable for windlasses. The tangles of chain are delivered in wooden boxes or convenient packages easy to handle and stock. Each single metre of chain has an OSC distinctive mark to ensure quality. Length when stretched Ø mm Kg/m Working load kg Breaking load kg Standard P mm B mm 25 m 50 m 75 m 100 m 150 m 01.375.06-025 01.375.06-050 01.375.06-075 01.375.06-100 - 6 0.800 400 1600 DIN766 / ISO 18.5 20 01.375.08-025 01.375.08-050 01.375.08-075 01.375.08-100 - 8 1.400 800 3200 DIN766 / ISO 24 26 01.375.10-025 01.375.10-050 01.375.10-075 01.375.10-100 01.375.10-150 10 2.200 1250 5000 ISO 30 35 - 01.375.11-050 - 01.375.11-100 01.375.11-150 10 2.300 1250 5000 DIN766 28 36 - 01.375.12-050 01.375.12-075 01.375.12-100 01.375.12-150 12 3.200 1800 7240 ISO 36 40
25 Anchors, bowsprits and shock absorbers 01 Hot-galvanized Genovese chain Elongated link version. Ideal for fixed and dock mooring (no winch). Length when stretched Ø mm Kg/m Working load kg Breaking load kg 50 m 100 m 01.372.06-050 01.372.06-100 6 0.73 340 1360 01.372.07-050 01.372.07-100 7 1.1 460 1840 01.372.08-050 01.372.08-100 8 1.33 600 2400 01.372.10-050 01.372.10-100 10 2.075 940 3760 01.372.12-050 01.372.12-100 12 3 1360 5440 01.372.16-050 - 16 5.08 3200 12.600 01.372.20-050 - 20 8.20 5000 19000 01.372.24-050 - 24 11.70 6800 27000 AISI 316 stainless steel Genovese chain AISI 316 Elongated link version. Ideal for fixed and dock mooring (no winch). Length when stretched 50 m Ø mm Kg/m Working load kg Breaking load kg 01.374.03-050 3 0.165 110 450 01.374.04-050 4 0.3 200 800 01.374.05-050 5 0.5 310 1250 01.374.06-050 6 0.73 450 1800 01.374.08-050 8 1.3 800 3200 01.374.10-050 10 2.05 1250 5000 Shackle with Allen-head recessed pin AISI 316 Made of AISI 316 stainless steel, it enables the anchor to fit into the bow rollers without getting tangled. Code A mm B mm D mm L1 mm 01.080.05 5 10 10 20 10 01.080.06 6 12 12 24 10 01.080.08 8 16 16 32 10 01.080.10 10 20 20 40 5 01.080.12 12 24 24 48 - 01.080.14 14 28 28 63 - 01.080.16 16 32 32 64 - Bow shackle with Allen-head recessed pin AISI 316 Made of AISI 316 stainless steel, it enables the anchor to fit into rollers without getting tangled. Code Ø mm A mm B mm 01.081.06 6 12 21 01.081.08 8 16 28 01.081.10 10 20 34 01.081.12 12 25 44 01.081.14 14 28 51 Anchor Rode Set: line, chain, connector and anchor The easy solution for anchor lines to suit a wide range of installations and requirements. These packages easily adapt to most situations. Each package is delivered "ready to use" in a special packaging. The line is already weighted with a suitable chain link. Code Anchor type Anchor kg chain Ø mm Chain length mm Chain link Line length Cable Ø mm Anchorchain connector mm Anchorchainconnector Hulls with winch Recommended for hulls up to (approx.) m 01.700.01 Umbrella 4 6 5 Genovese 35 10 8 Galvanized shackle no 4-6 01.700.02 Umbrella 6 6 10 Genovese 35 10 8 Galvanized shackle no 5-7 01.700.03 Umbrella 8 7 10 Genovese 35 12 10 Galvanized shackle no 6-8 01.710.01 Hall 4.2 6 5 Genovese 35 10 8 Galvanized shackle no 4-6 01.710.02 Hall 6.2 6 10 Genovese 35 10 8 Galvanized shackle no 5-7 01.710.03 Hall 8.8 7 10 Genovese 35 12 10 Galvanized shackle no 6-8 01.800.01 Trefoil 7.5 6 25 Sized 35 12 8 Swivelling joint Yes 5-7 01.800.02 Trefoil 10 6 25 Sized 35 12 8 Swivelling joint Yes 6-8 01.800.03 Trefoil 13 8 25 Sized 35 14 8 Swivelling joint Yes 7-10 \ 01.700.xx \ 01.800.xx \ 01.710.xx
26 Anchors, bowsprits and shock absorbers 01 Anchor connector without protrusions AISI 316 Anchor connector made of AISI 316 stainless steel without protrusions. It lets the anchor chain slide smoothly through the bow roller and avoids entangling of the shackle. Code Chain Ø mm B mm C mm L mm G mm P mm H mm 01.220.01 6/8 10 7 16 22 9 90 01.220.02 9/10 13 11 19 29 11 115 Anchor swivelling connector AISI 316 Made of precision-cast AISI 316 stainless steel without protrusions, used to connect the chain to the anchor. It lets the anchor chain slide smoothly through the bow roller and avoids entangling of the shackle. New reinforced model with additional finish, exclusively made by Osculati. Code Chain Ø mm Breaking load kg B mm C mm L mm G mm P mm H mm 01.740.08 6/8 3500 10 7 16 21 9 95 01.740.09* 6/8 - 10 7 17 20 10 90 01.740.10 9/10 6150 13 11 21 28 11 120 *Suitable for 20-kg Trefoil® anchors Anchor maxi swivelling connector AISI 316 Made of mirror polished AISI 316 stainless steel. Used to connect the chain to the anchor, maxi version for 12/14 mm chains. Code Chain Ø mm Breaking load kg B mm C mm L mm G mm P mm H mm 01.740.12 12/14 9470 19 14 29 30 23 140 Mega swivelling anchor connector made from CNC-machined bar AISI 316 Made of polished AISI316 stainless steel. Code For anchors kg Chain Ø mm Breaking load kg B mm C mm L mm G mm P mm H mm 01.740.16 50/80 14/16 15000 35 20 20 36 18 176 01.740.17 up to 100 up to 18 26000 38 24 20 36 18 176 Anchor double-joint swiveling connector AISI 316 Made of AISI 316 stainless steel without protrusions. This double-joint swivelling connection is the evolution of the single-joint 01.740.08/10 model. Code Chain Ø mm Total length mm B mm C mm L mm G mm P mm H mm 01.742.08 6/8 117 9 8 16 21 10 95 01.742.10 9/10 155 13 10 19 28 13 120 Twist joint still turns AISI 316 PATENT Made of mirror-polished AISI316 stainless steel. With the latest asymmetric anchors (Bruce, Delta, Trefoil® etc.), when the anchor is raised, it most probably turns the wrong side. The Twist swivelling connector turns the anchor correctly and it reeves into the roller or hawsehole. A shackle connects the fixed eye to the anchor. Code Chain Ø mm Connecting shackle A mm B mm C mm 01.738.01 6/8 01.080.10 220 60 28 01.738.02 10/12 01.080.10/12/14 320 83 38
27 Anchors, bowsprits and shock absorbers 01 Trimmer anchor swivelling connector AISI 316 Polished AISI 316 stainless steel. Fitted with a double joint to avoid the lever boom effect with held-on anchor. Anti-oscillation connection to the anchor during lifting when approaching the roller/bow. Safety screws. Side load 3 times as powerful as traditional connectors. Code Chain Ø mm Breaking load kg A mm B mm C mm 01.739.01 6/8 3200 200 15 7/17 01.739.02 10/12 8500 230 22 20/30 01.739.03 12 12000 235 27 30/50 Rope/chain connector AISI 316 Designed to connect the anchor chain into the respective line, without knots; it is also suitable for stern mooring. Made of mirror-polished AISI 316 stainless steel. Code Chain Ø mm For line Ø mm 01.230.01 6 10 01.230.02 8 12 Chain link for calibrated chain AISI 316 In stainless steel AISI 316. High strength due to the structure with 8 sealing pins, calibrated for winches, thus they run perfectly in the gypsy avoiding dangerous jamming. Code Breaking load kg Ø D mm A mm B mm 01.672.06 1630 6 31.5 20.5 01.672.08 3200 8 40.5 26.5 01.672.10 5000 10 50.5 35.5 01.672.12 6500 12 61 40.5 Chain link Made of stainless steel, for calibrated chain Stainless steel Ø D Chain mm Breaking load kg A1 mm A mm L mm L1 mm 01.671.06 6 700 11 23 21 21 01.671.08 8 1240 12.5 29 24 24 01.671.10 10 1940 15 34.5 29 29 01.671.12 12 2780 19 42 38 38 Galvanized steel swivel made for anchor chains and buoys Double eye, ideal for mooring lines Code Breaking load kg A mm B mm b1 mm L mm L1 mm 01.427.10 5000 10 51 30.8 125 23.5 01.427.12 8000 13 63 36 165 33 01.427.14 11700 16 75.5 42.6 200 40.8 01.427.16 16300 19 88.5 50 225 42.8 AISI316 stainless steel swivel Double eye, ideal for mooring lines. Code Breaking load kg A mm B mm b1 mm L mm L1 mm 01.018.04 450 4 19.5 11.5 50 13 01.018.05 650 5 23 13 60 13 01.018.06 1200 6 26 15 65 15 01.018.08 1900 8 35 20 90 22 01.018.10 3500 10 44 24 115 27 01.018.13 5000 13 59 33 148 33 01.018.16 6500 16 75 39 188 42 Mirror-polished AISI 316 stainless steel swivel Very sturdy, forged steel, ideal for mooring buoys, halyards, anchor chains, etc. Shackle + shackle Shackle + shackle (flush pin) Eye + shackle Eye + shackle (flush pin) A mm B mm C mm D mm 01.428.99 - 01.427.99 - 60 10 11 5 01.429.00 01.439.00 01.428.00 01.438.00 66 12 11 6 01.429.01 01.439.01 01.428.01 01.438.01 88 16 16 8 01.429.02 01.439.02 01.428.02 01.438.02 113 20 22 10 01.429.03 01.439.03 01.428.03 - 152 26 28 13 01.429.04 - 01.428.04 - 188 32 36 16 \ 01.438.xx \ 01.438.xx \ 01.428.0x; 01.427.99 \ 01.429.xx; 01.428.99 \ 01.439.xx \ 01.428.0x; 01.427.99 \ 01.429.xx; 01.428.99 \ 01.439.xx
28 Anchors, bowsprits and shock absorbers 01 Braid Made of polyester, as per regulations for anchors. Code Ø rope Length m 01.106.00 8 30 01.106.01 10 30 Line with chain Orange levilene line as per regulation for anchors. Fitted with a 2-metre galvanized chain and a shackle for connection to the anchor. Code Ø rope Ø chain Length m 01.105.00 8 6 30 Line for chain and rope windlass. Made with three-strand white rope and stainless steel chain link, the end part can be connected to the windlass chain. Code Ø rope Length m Gypsy Ø mm Chain link Ø mm For windlasses 02.636.01 10 35 6 6 Manual mooring, Lofrans: Project x1; Italwinch 02.407.01 02.636.02 12 35 6 6 Lewmar: Pro-series 1000, V-700, V1, V2 Lofrans: Project x1, Dorado 500W, Marlin; Lewmar CPX0; Italwinch Ray; Italwinch RayLux 02.834.00 14 35 8-10 8 Lewmar: Pro-series 1000, V1, V2, V3, V4 Lofrans: Project x1-x2-x3, Project 1000-1500, Dorado 700W, Clipper 700-1000; Italwinch Thunder, Italwinch ThunderLux 02.636.05 16 40 10 10 Lewmar: Pro-series 1000, V3, V4,V5 Lofrans: Project x2-x3, Project 1000-1500, Clipper 1000; Italwinch Thunder Lux Ø 16 Anchor rope made of polyester braid with lead core for the first 10 metres With thimble and spliced by hand. It comes in an elegant nylon bag with blue string. Code Ø rope Length m Lead core length m Lead weight kg Total weight kg 06.446.10 10 30 10 3 5 06.446.12 12 30 10 4 7.5 06.446.13 10 50 20 8 10 Chain Boy chain stowing system PATENT It allows tidy chain stowage on all anchor chain lockers. Minimum locker height when hauling in the anchor: 80 mm for 6/8-mm chain, 100 mm for 10/12-mm chain. Code Base Ø mm Head Ø mm Adjustable height 01.550.00 150 170 325 to 475 mm by means of the inserts included Safety Device Chain Stopper Delux in Stainless Steel 316 AISI 316 The chain stopper device prevents the anchor rode unwanted release while the boat is in use. It also prevents shock/abnormal loading of the windlass while the boat is at anchor. The Chain Stopper can be disengaged with a simple movement. Code For chain Ø mm Base mm Overhang mm 01.119.34 6/8 60x50 47 01.119.35 10/12 80x70 63 \ 01.119.50 \ 01.119.51 ITALWINCH steel chain stopper Chain lock compatible with main chains from 8 mm to 14 mm diameter with crossbar. Fully made of AISI 316 steel. Code Base mm For chain Ø mm 01.119.50 110x62 8mm ISO - 8 mm DIN 766 - 10mm ISO - 10mm DIN 766 01.119.51 130x85 12mm ISO - 13mm DIN766 - 13mm DIN 764, 14mm ISO - 12.5 C.T., 14 C.T.
29 Anchors, bowsprits and shock absorbers 01 NEW 2026 Claw Maxi steel chain stopper AISI 316 AISI 316 steel chain stopper perfect to enhance anchoring system safety. Prevents accidental descent of the anchor while sailing, and protects the winch from excessive loads and strains at anchor. Simple installation from above using countersunk screws. Two models available for 8–10mm and 12–14mm chains. Code Base mm For chain Ø mm 01.119.20 100x67 8/10 01.119.21 140x92 12/14 \ 01.119.21 \ 01.119.20 \ 01.119.21 \ 01.119.20
30 Anchors, bowsprits and shock absorbers 01 \ 01.747.06 \ 01.747.10 Anchor gripper kit It consists of eyebolt and Pad-Eye + high-resistance strap + snap-hook. Made with 100% rustproof tape, it doesn't scratch or bang against the deck. Reflective tape seams for high visibility at night. To be installed near the winch as safety gripper to prevent the anchor from falling during navigation. Code For chain Ø mm Length cm Anchorage point Snap hook 01.747.06 6/8 20 39.181.05 09.247.70 01.747.10 10/12 25 39.873.01 09.247.10 \ Rest on the first welded part Chain Rainbow marker PATENT METS NOMINATION 2003 Coloured plastic inserts for fitting into chain links. Sold in kits for marking 25 cm of calibrated chain. Insert colours For calibrated chain Ø mm No of inserts white blue yellow Red green 01.500.06BI 01.500.06BL 01.500.06GI 01.500.06RO 01.500.06VE 6 14 01.500.08BI 01.500.08BL 01.500.08GI 01.500.08RO 01.500.08VE 8 10 01.500.10BI 01.500.10BL 01.500.10GI 01.500.10RO 01.500.10VE 10 8 01.500.12BI 01.500.12BL 01.500.12GI 01.500.12RO 01.500.12VE 12 8 Chain Rainbow marker kit, assorted colours PATENT METS NOMINATION 2003 Assorted pack of Chain Rainbow sufficient to mark an entire length of calibrated chain. The kit consists of 5 colours (white, blue, yellow, red, and green). Code For calibrated chain Ø mm Number of inserts 01.501.06 6 70 01.501.08 8 50 01.501.10 10 40 01.501.12 12 40 \ 01.500.xx \ 01.501.xx Mooring device and anchor chain gripper AISI 316 It clutches the chain link and relieves the winch from the mooring effort. Made of polished 316 stainless steel. Code For chain Ø mm 01.744.06 6/8 01.744.10 10/12 KONG Chain Gripper U-bolt connector in stainless steel 316 A special U-bolt used to connect the second anchor chain to each point of the main anchor chain. A traditional shackle is very often difficult to fit into the narrow links of a calibrated chain. Code For chain Ø mm Breaking load kg 01.743.01 6/8 2500 01.743.02 10/12 5000 PAOMAR anchor retriever Made of fiberglass reinforced polymer. It always retrieves the anchor and the line. Adjustable release load from 20 to 200 kg, long lasting in the marine environment. Code To be used with anchors up to kg hulls up to m lines chains 01.101.00 8 8 Yes Yes Anchor retriever AISI 316 Made of stainless steel AISI 316. Used to release the fouled anchor from ropes and chains of other vessels. Code Ø mm 01.102.00 180
31 Anchors, bowsprits and shock absorbers 01 NEW GRIPPY: light and compact anchor gripper, with self-winding top in ultra-resistant braid and automatic night lighting with solar charging MADE IN ITALY This gripper, extremely light and compact, uses 2 completely watertight chambers that house electronic and mechanical components, preventing possible malfunctions caused by saltwater. All versions feature a steel cable anchor guard, which protects the anchor's end from potential rubbing against rocks and allows for easy removal of the buoystone when not in use. The end of GRIPPY's rope is connected to the anchor's diamond, which will unfold automatically when lowered. The self-regulation allows GRIPPY to float on the perpendicular of the anchor, indicating its position. In the LIGHT, HEAVY, and ABR versions, solar cells are present for battery activation, required for nighttime lighting, which automatically activates at night. In the ABR version (Automatic Brake Rope: when the device exceeds a 90° inclination while raising the anchor, the slide of the clamp immediately stops, allowing for easy recovery of the buoy directly from the clamp) these cells also power the electronics responsible for the cable lock. In case of a jammed anchor, it can be released by recovering the gripple, thanks to its high breaking load. Upon recovery of the anchor, GRIPPY will automatically rewind its rope, positioning itself under the bow of the boat. Features a comfortable and discreet railing support and a retractable visual indicator. \ 01.211.02 \ 01.211.04 \ Protection for anchor buoy \ 01.211.04 \ Handrail support \ 01.211.09 Code Model Anchor buoy rope length m Stainless steel cable anchor guard Anchor buoy rope breaking load kg Description Handrail support Ø mm 01.211.05 Grippy BASIC 15 Yes, 500 kg 500 With visual signaller Yes 200 1.2 01.211.02 Grippy LIGHT 25 Yes, 500 kg 500 With visual signaller + night automatic lights Yes 200 1.3 01.211.03 Grippy HEAVY 20 Yes, 1200 kg 1000 With visual signaller + night automatic lights Yes 200 1.4 01.211.04 Grippy ABR 20 Yes, 1200 kg 1000 With visual signaller + night automatic lights Yes 200 1.5 01.211.09 10-m extension (1200-kg breaking load). GRIPPY TRACKER: the signalling buoy with integrated GPS and wireless handheld. MADE IN ITALY GRIPPY Tracker combines a powerful GPS receiver and mechanics able of self-adjust on the anchoring point. A microprocessor system detects high or low tide, the drift caused by currents and high wind, and counteracts any possible false alarm. It also detects attempted theft, tampering, and impacts on the anchor buoy. A very simple and userfrienfly handheld controls monitors the anchor all the time and if it drifts exceeding a preset range, the control immediately warns of the possible danger. Anchor buoy: - Automatic active adjustment of the perpendicular on the anchor for maximum point accuracy, - Autodetect high-low tide, - Possibility of fast charging via USB-C plug, - Battery life of over 5 days in full tracking mode, - ABR System (Automatic Brake Rope: when the device exceeds 90° inclination, while the anchor is sailed, thesliding of the rope is stopped immediately, allowing easy recovery of the buoy directly from its rope). - Buoy rope breaking load: 1000 kg, - Stainless steel safety buoy rope, - Nighttime lighting, - Railing support, - Solar charging. Handheld: - IPS 3.5" touch display, - Rechargeable battery (runtime of over 50 hours). Available in two versions: with or without GSM module included (SMS alarm system). Additionally available as an option, the GHOST function allows for the submersion of the buoy up to 3 meters on command, in scenarios where it might collide with the keel, and to resurface it using ultrasound controls. \ 01.221.02/03 \ Wireless handheld \ Wireless handheld \ 01.221.10 \ Handrail support \ Protection for anchor buoy Code Model Anchor buoy rope length m Anchor buoy rope breaking load kg Stainless steel cable anchor guard Handrail support Nighttime lighting ABR System Ghost call module OPTIONAL Rechargeable Battery 01.221.02 With standard handheld device 20 1000 Yes, 1200 kg Yes Yes to solar charging Yes 01.221.10 Grippiale: solar and USB Type-C. Handheld: USB Type-C. 01.221.03 With SMS alarm system included in the handheld device (GSM module) 20 1000 Yes, 1200 kg Yes Yes to solar charging Yes 01.221.10 Grippiale: solar and USB Type-C. Handheld: USB Type-C.
32 Anchors, bowsprits and shock absorbers 01 Stainless steel rollers DOUGLAS MARINE AISI316 stainless steel bow shield Mirror-polished AISI316 stainless steel bow shield, bored and countersunk. Supplied with a pre-fold, it adapts to the different bow shapes of boats when installed. With oversized thickness, it resists even the most violent impacts. Code Thickness Dimensions mm Weight 01.290.01 2 340x520 1.78 01.290.03 2 680x450 3 Bow roller for dolphin strikers Made of stainless steel 304 to be mounted under the bow roller. Code Sheave material Recess fit width mm Spare sheave 01.119.92 Hard rubber 125 01.219.94 1.3 Bow roller, compact version In satin-finished 304 stainless steel, with nylon pulley Code Length mm Width mm Height mm Spare sheave 01.118.82 155 51 72 01.218.82 0.48 Bow fairlead Very sturdy and practical, made of AISI316 stainless steel, nylon sheave suitable for ropes up to 14 mm and for chains up to 6/8 mm. Product by Osculati. Code Length mm Base mm 01.349.00 130 90x90 1.1 \ 01.118.91 \ 01.118.83 Bow roller with safety pin In satin-finished stainless steel 304. Pulley in hard rubber. Code Length mm Width with safety pin mm Spare sheave Anchor max weight kg Ø kg line mm chain mm 01.118.83 280 55 01.218.82 15 24 10 01.118.91 231.5 51 01.218.82 15 24 10 \ 01.118.83 \ 01.118.91
33 Anchors, bowsprits and shock absorbers 01 Bow roller with fairlead In stainless steel 304 satin for mounting above or below the dolphin striker Code Length mm Width mm Spare sheave 01.118.86 393 52 01.218.82 1.1 01.119.94 500 84 01.219.94 2.6 01.119.95 588 98 01.219.95 3.5 \ 01.119.94 \ 01.119.95 \ 01.118.86 Bow rollers for small vessels AISI 316 Mirror-polished stainless steel with thermopolymer sheave. Code Length mm Width mm Height mm Spare sheave 01.118.80 205 45 53 01.346.51 Bow roller for anchor retrieval In stainless steel 304, Chromelux® finish, complete with nylon pulley and upper safety pin. Code Length mm Width mm Height mm Version Spare sheave 01.484.12 210 57 70 Standard 01.346.50 0.63 01.484.13 210 57 70 With anchor locker 01.346.50 1 01.484.14 170 57 70 short 01.346.50 0.55 \ 01.484.12/14 \ 01.484.13 Cast AISI316 stainless steel bow roller, compact version AISI 316 Mirror-polished precision-cast AISI 316 stainless steel bow roller with nylon sheave. Code Length mm Width mm Height mm Base mm Spare sheave 01.484.09 155 62 75 90x62 01.346.50 0.68 AISI316 cast bow roller AISI 316 Mirror-polished precision-cast AISI316 stainless steel, white nylon sheave. Universal for lines or chains up to approximately 10 kg. Code Length mm Width mm Height mm Base mm Spare sheave 01.484.10 221 82 80 132x82 01.346.30 2 Roller Constructed from polished 304 stainless steel. Pulleys in nylon. Code A mm B mm C mm Plate thickness mm Suitable for anchors max kg 01.332.01 200 54 80 2 7.5 0.59 01.332.02 270 54 80 2 10 0.71
34 Anchors, bowsprits and shock absorbers 01 Classic heavy hinged roller In polished 304 stainless steel. Nylon pulleys. Universal for DELTA / BRUCE / TREFOIL / CQR / SOC. Code A mm B mm C mm Plate thickness mm Suitable for anchors max kg 01.333.01 330 70 117 4 10 3 01.333.02 400 70 117 4 15 3.4 01.333.03 495 90 150 5 20 6.7 01.333.04 595 90 150 5 30 7.5 01.333.05 695 90 150 5 30 8.6 Compact lightweight hinged roller In polished 304 stainless steel. Nylon pulleys. Universal for DELTA / BRUCE / TREFOIL / CQR / SOC. Code A mm B mm C mm Plate thickness mm Suitable for anchors max kg 01.333.10 300 80 80 3 10 2.7 01.333.11 400 80 80 3 15 3 \ 01.350.01 \ 01.350.02 Bow roller with anchor locker AISI 316 Made of mirror-polished precision-cast AISI 316 stainless steel. Fitted with lock for anchor models Danforth, Bruce, Trefoil®, CQR, etc. Unbreakable stainless steel sheave. Code A mm B mm C mm Width mm Version 01.350.01 205 105 155 75 short 2.5 01.350.02 340 240 160 75 Standard 3.3 Hinged bow roller with safety pin AISI 316 Made of stainless steel, suitable for all anchors up to 14 kg. Nylon sheave. Code Length A mm Width C mm Height L mm Spare sheave Large small 01.419.00 320 90 70 01.519.01 01.519.02 Hinged bow roller with fairlead up to 20 kg In polished 304 stainless steel, with chain guide, for anchors of any type from 10 to 20 kg. Manufactured from 4 mm thick sheet metal. Stainless steel pulleys. Code A mm B mm C mm D mm E mm L mm 01.337.00 416 230 186 114 47 81 4
35 Anchors, bowsprits and shock absorbers 01 Self-locking roller AISI 316 Suitable for Bruce and Trefoil® anchors, made of mirror-polished precision-cast AISI 316 stainless steel. Unbreakable stainless steel sheave, fitted with U-shape anchor stopper. Code A mm B mm C mm L mm Suitable for anchors max kg For calibrated chains Ø mm 01.341.99 380 261 196 67 10 6/8 4.1 01.341.96 480 300 210 75 15 8/10 6.9 01.341.98 590 340 235 78 20 10/12 9 01.341.97 590 340 240 82 30 10/12 9 Shimming chock AISI 316 Designed to ease anchor pay-out if the bow section does not allow for the correct angle of the anchor into the roller. Code Length mm Width mm Height mm For rollers 01.341.90 50 45 32 01.341.99 01.341.91 50 57 32 01.341.96/97/98 Special roller for Bruce and Trefoil® anchors In polished stainless steel 304, made from sheet metal. Utilizes the shape of Bruce and Trefoil® to be self-locking. Nylon pulley. Code A mm B mm C mm L mm Suitable for 01.342.10 370 250 187 89 Bruce/Trefoil® up to 10 kg 2.5 01.342.20 542 375 250 88 Bruce/Trefoil® up to 20 kg 6.4 Roller with fairlead AISI 316 Suitable for Delta, Bruce and Trefoil® anchors, made of mirror-polished AISI stainless steel, fitted with a double sheave. It does not include an anchor locker kit. Code For anchors kg A mm B mm C mm L mm Suitable for 01.336.01 6/10 620 300 200 83 Delta 6/16 kg - Bruce/Trefoil® 7,5/15 kg 10 01.336.03* 16/25 670 340 170 85 Delta 16/25 kg - Bruce/Trefoil® 7,5/20 kg 12.7 *01.339.21Anchor locker kit including rollers, anchor stopper and screw knob for 01.336.03 \ 01.339.21 Bow roller with anchor locker kit AISI 316 Mirror-polished cast AISI 316 stainless steel, wide overhang area to prevent anchors from touching the bow. Stainless steel sheaves, suitable for anchors CQR, Bruce, Danforth, Trefoil®, Delta etc. Code A mm B mm C mm D mm E mm L mm Suitable for anchors max kg For chains Ø mm 01.339.10 410 160 250 62 25 85 12 6/8 6.9 01.339.20* 530 240 290 88 22 102 20 8/10 10 *01.339.21 Anchor lock kit including rollers, anchor stopper and screw knob for 01.339.20 \ 01.339.21 \ 01.339.10 \ 01.339.20
36 Anchors, bowsprits and shock absorbers 01 \ 01.120.07/10/15/20 \ 01.121.07/10/20 \ 01.121.xx \ 01.120.xx Bow roller + Trefoil® anchor with anti-water plate AISI 316 SELF LAUNCHING Bow roller for anchor with coupling plate for perfect closure of the hull hole. This system makes the plate strike against the roller preventing water from leaking into the forepeak. The roller is designed to match the Trefoil anchor for a combination of high-level products in style and performance. The system can be easily installed by 4 studs behind the roller and is fitted with two sheaves for smooth sliding of the chain. Entirely made of mirror-polished AISI 316 stainless steel. It is recommended to install it on the chain by means of the Twist joint 01.738.01. Windlass ideal pull angle at 5° / 20° from the roller horizontal axis. Code Description mm MatchingA B C D 01.120.07 Trefoil anchor 7.5 kg 535 230 352 - 7.5 01.121.07 01.120.10 Trefoil anchor 10 kg 588 331 383 - 10 01.121.10 01.120.15 Trefoil anchor 15 kg 650 348 430 - 15 01.121.10 01.120.20 Trefoil anchor 20 kg 702 370 468 - 20 01.121.20 01.121.07 Bow roller 7.5 kg 150 168 232 322 6.3 01.120.07 01.121.10 Bow roller 10 kg 117 203 279 305 9.3 01.120.10/15 01.121.20 Bow roller 20 kg 206 224 270 254 12.6 01.120.20 \ Video
37 Anchors, bowsprits and shock absorbers 01 NEW Mr. Fantastic extendable roller EXTENDABLE IDEAL FOR VERTICAL BOW SELF LAUNCHING Made from mirror-polished stainless steel, ideal for Trefoil anchors or similar. It is equipped with an innovative system with gas springs that allows the anchor to move away from the bow before being lowered. Simultaneously, a tilting motion enables the automatic drop of the anchor, maintaining a safe distance from the bow. Its lightweight and sports shape is well-suited to the hull and its steel frame is designed to withstand high loads. Code For anchors kg Extension mm A mm B mm C mm D mm Ø mm Plate thickness mm Version 01.338.07 7.5 - 10 130 468 357 120 228 8.4 5 Mirror-polished 01.338.15 10 - 15 200 625 480 120 270 10.4 5 Mirror-polished 01.338.30 20 - 30 220 750 600 140 310 10.4 8 Electropolished 01.338.31 20 - 30 220 750 600 140 310 10.4 8 Mirror-polished \ Video Universal anchor locker Adjustable to roller 01.337.00 and others, made of stainless steel. Code Height mm Base mm 01.337.10 92 + knob 68x55
38 Anchors, bowsprits and shock absorbers 01 Aluminium and brass rollers Alloy fairlead with round base plate Made of anodized aluminium by Osculati. Excellent finish. Nylon sheave. Code Length mm Base mm For ropes up to mm 01.341.00 140 90x73 13 0.28 Triple roller bow fairlead Smooth-sliding interchangeable nylon sheaves. Chromed brass body. Code Length mm Width mm Height mm For boats 01.345.00 107 100 73 6 to 10 m 1 Light alloy bow roller with anchor locker kit up to 10 kg Made of anodized aluminium, fitted with locker. Suitable for anchors Danforth, Bruce, Trefoil® or CQR. Polished finish. Nylon sheaves. Code A mm B mm C mm L mm For anchors up to max kg 01.347.10 340 242 160 75 10 2 Alloy hinged bow roller up to 12 kg Made of anodized polished aluminium. Suitable for anchors Danforth, Bruce,Trefoil®, CQR and Delta. Nylon sheave. Code A mm B mm C mm D mm E mm L mm For anchors up to max kg 01.335.10 365 205 160 60 13 88 12 2.6 Alloy hinged bow roller up to 15 kg Made of anodized aluminium, wide overhang to prevent the anchor from touching the bow. Suitable for anchors Danforth, CQR, Trefoil®, Bruce, Delta etc. Nylon sheave. Code A mm B mm C mm D mm E mm L mm For anchors up to max kg 01.336.10 410 160 250 62 25 95 15 3.7 Bruce and Trefoil® anchor roller Made of anodized polished aluminium, it makes the most of the Bruce and Trefoil® anchors' shape to provide self-locking features. When the anchor is raised it is firmly fitted into the roller to avoid manual locking interventions. Nylon sheave. Code A mm B mm C mm L mm For anchors 01.343.10 380 261 196 67 Bruce, Trefoil® kg 5/7.5/10 2.4
39 Anchors, bowsprits and shock absorbers 01 Hawseholes Oval hawsehole AISI 316 In stainless steel AISI 316 mirror-polished, no screws visible from the outside. Code Outside mm Inside mm Trimming ring Hull thickness max mm 01.352.00 140x63 97x37 no 17 01.352.01 140x63 97x37 no 22 01.352.02 152x82 101x50 no 29 01.352.03 238x136 194x89 no 22 01.352.04 241x146 171x76 Yes 54 \ 01.352.01/00 \ 01.352.02 \ 01.352.04 \ 01.352.03 Anchor line hawsehole with lid AISI 316 Made of mirror-polished AISI 316 stainless steel. Code Opening mm Ring mm Version 01.353.01 95x60 137x100 With hinge opening Roller hawsehole AISI 316 Made of mirror-polished AISI 316 stainless steel, fitted with trimming ring. The hull thickness can be cut at the required size. Code A mm B mm C mm D mm E mm Cut size mm Hull thickness (to be cut) mm Studs mm 01.353.00 340 160 270 91 105 280x100 125 8 01.353.06 248 148 180 82 60 190x92 80 6x8 Sheaves for rollers Hard rubber spare sheave for rollers Code Ø mm Width mm Bore mm For rollers 01.218.82 64 43 12 01.118.82; 01.118.83; 01.118.86; 01.118.91 01.219.94 71 74 16 01.119.94 01.219.95 78 88 16 01.119.92; 01.119.95 \ 01.218.82 \ 01.219.94 \ 01.219.95 Spare nylon sheave for rollers Universal spare parts for bow rollers. Code Ø mm Width mm Bore mm For rollers 01.519.01 86 49 13 01.419.00 (large roller) 01.519.02 61 49 13 01.419.00 (small roller) 01.346.20 69 43 10.1 01.347.10; 01.335.10; 01.336.10; 01.339.10; 01.343.10 01.346.22 54 49 12.5 01.333.01; 01.333.02 01.346.30 88 53 12.5 01.484.10 01.346.40 40 33.5 8.3 01.340.00; 01.341.00; 01.349.00 01.346.50 52 50.5 8.3 01.484.12; 01.484.13; 01.484.14 01.346.51 41 40 8.3 01.118.80 \ 01.519.01 \ 01.519.02 \ 01.346.20 \ 01.346.22 \ 01.346.30 \ 01.346.40 \ 01.346.50 \ 01.346.51 Spare AISI316 stainless steel sheave for rollers Code Ø mm Width mm Bore mm For rollers 01.346.60 88 60.5 14.2 01.336.01; 01.336.03 01.346.62 68 43.5 14.7 01.339.10 01.346.64 87 54 12.4 01.339.20; 01.341.96 01.346.66 67 43.5 12.8 01.341.99 01.346.68 67.5 43.5 10.3 01.350.01; 01.350.02 01.346.70 99 58.5 14.5 01.341.97; 01.341.98
40 Anchors, bowsprits and shock absorbers 01 UNIMER mooring compensators UNIMER mooring compensator Made of salt-resistant EPDM rubber. Code Length mm For line Ø mm 01.495.01 332 10/12 218 01.495.02 416 12/14 448 01.495.03 520 14/18 710 01.495.04 600 20/24 1365 UNIMER U-Cleat mooring compensator with line locking mechanism Made of salt-resistant EPDM rubber. Code Length mm For line Ø mm 01.495.11 332 10/12 218 01.495.12 416 12/16 448 01.495.13 520 16/20 710 UNIMER Classic inline mooring compensators Made of salt-resistant EPDM rubber. Code Length mm For line Ø mm 01.496.01 156 10/12 75 01.496.02 210 12/16 194 01.496.03 260 14/18 335 UNIMER Snubber elastic mooring system Made of polyurethane material that gives it long enduring elasticity in any weather. It is fitted directly on to the line, no matter what position. Add more Snubbers for increased compensation effect. Code For line Ø mm 01.155.02 14/16 2 01.155.04 18/20 2
41 Anchors, bowsprits and shock absorbers 01 Mooring compensators and springs AISI 316 stainless steel chain piece AISI 316 To be used for fixing stern mooring lines to stern rings or bollards in harbours. Code chain Ø mm Piece length m 01.474.06 6 1 2 01.474.08 8 1.25 2 01.474.10 10 1.5 2 Mooring spring This mooring springs ensure a non-yielding and long-lasting compensation effect. - Version made of high-strength galvanized steel. - Version made of high-strength polished stainless steel. To be installed with a safety chain. Code Version Ø mm Max length mm Wire Ø mm Max compression load For hulls up to m. (approx.) Hull max weight kg (approx.) 01.189.06 Galvanized steel 53 276 5.5 140 0.6 5 1000 01.189.09 Galvanized steel 66 330 6.5 200 0.9 7 2000 01.189.12 Galvanized steel 74 397 7.5 250 1.6 9 3500 01.189.17 Galvanized steel 90 455 9 350 2.7 11 7000 01.189.19 Galvanized steel 93 406 11 630 2.9 13 10000 01.199.06 Polished S.S. 50 270 5 95 0.4 5 1000 01.199.08 Polished S.S. 62 320 6 140 0.6 7 2000 01.199.11 Polished S.S. 69 335 7 200 0.9 9 3500 01.199.14 Polished S.S. 81 380 9 250 1.7 11 7000 01.199.16 Polished S.S. 89 370 10 450 2.3 13 10000 \ 01.199.0x \ 01.189.0x Polished stainless steel mooring spring High-resistant low-noise model fitted with friction inserts ]and stainless steel tension rods and bolts. To be installed with a safety chain. Code External Ø mm Length mm Wire Ø mm For hulls up to m. (approx.) 01.202.06 57 300 5 0.6 7 01.202.08 59 300 6 0.8 7 01.202.11 73 400 7 1.4 9 01.202.14 87 470 9 2.4 11 01.202.16 91 470 11 3.3 13/14 Polished stainless steel mooring spring with variable pitch This technology means that the load is increased progressively as the spring is pulled. The coils that are close together start working first, then the coils that are further apart begin to work as the load increases. This helps to prevent the spring violently 'bottoming out' and becoming damaged under the sudden shock loading when this occurs. Safety chain to be installed. Code Ø mm Length mm Lock load For hulls up to m. (approx.) Hull max weight kg (approx.) 01.201.02 60 250 180 0.8 10-12 7000-10000 01.201.03 70 300 350 1.6 13-14 12000-15000
42 Anchors, bowsprits and shock absorbers 01 DOUGLAS MARINE Master Moorings devices Thanks to the use of components (High resistance stainless and special elastomers), this product resists temperatures ranging from -40°C to +120°C and can endure more than 400,000 compressions (max compress). Weight and overall dimensions are reduced by up to 25% compared to equivalent products on the market. The Master Mooring devices deliver a gradual shock absorbing action due to the differentiated hardness of the elastomer materials. Wear-and-tear resistant compression stoppers included. They ensure a progressive cushioning action thanks to elastomers with differentiated hardness. Structure already including end stop for anti-deterioration. DOUGLAS MARINE Silenced Springs mooring device PATENT Made of specific HR stainless steel, they are equipped with anti-tension end-ofstroke and the particular heads allow a perfect axiality during traction. Code For boats up to m Ø mm Length mm Wire Ø mm Elastic capability kg Breaking load kg 01.198.06 6 70 310 5 1.4 60 1370 01.198.08 8 70 350 6 1.2 100 1830 01.198.11 11 75 380 8 1.9 120 2500 01.198.14 14 90 480 9 3.2 190 3800 01.198.16 16 90 480 12 3.9 400 6200 DOUGLAS MARINE Cardan mooring device Mooring spring equipped with a cardanic rotation device on stainless steel balls with an articulated head, which prevents the twisting of ropes or chains by making the spring work with perfect axiality and parallelism. Code For boats up to m Ø mm Length mm Wire Ø mm Elastic capability kg Breaking load kg 01.203.11 11 75 380 8 120 2500 01.203.14 14 90 480 9 190 3800 01.203.16 16 90 480 12 400 6200 \ 01.207.01 DOUGLAS MARINE Master Mooring Junior device PATENT Mooring compensators for 7- to 20-ton vessels. Code For boats tons Breaking load kg Stroke mm Elasticity kg 01.207.01 7-9 2.2 15.000 120 160 01.207.02 9-13 2.3 15.000 120 250 01.207.03 13-17 2 15.000 120 450 01.207.04 17-20 2.4 20.000 120 750 \ 01.208.03 DOUGLAS MARINE Master Mooring 20 PATENT Mooring compensators for 20- to 45-ton vessels. Code For boats tons Breaking load kg Stroke mm Elasticity kg 01.208.01 20-25 3.4 27.000 90 1400 01.208.02 25-35 3.4 27.000 90 1600 01.208.03 35-45 3.4 27.000 90 2300
43 Anchors, bowsprits and shock absorbers 01 DOUGLAS MARINE Master Mooring 30 device PATENT Mooring compensators for 45- to 90-ton vessels. Code For boats tons Breaking load kg Stroke mm Elasticity kg 01.209.01 45-55 3.8 27.000 140 2400 01.209.02 55-70 3.8 27.000 140 2600 01.209.03 70-90 3.8 27.000 140 2800 \ 01.209.03 DOUGLAS MARINE Master Mooring GIGA device 40 PATENT Mooring compensators for 90- to 150-ton vessels. Code For boats tons Breaking load kg Stroke mm Elasticity kg 01.210.01 90-130/150 5.2 30.000 180 3500 DOUGLAS MARINE Master Mooring GIGA 45 mooring device PATENT Mooring compensators for 150- to 350-ton vessels. Code For boats tons Breaking load kg Stroke mm Elasticity kg 01.210.02 150-350 7.8 35.000 165 4800 DOUGLAS MARINE mooring belt PATENT They eliminate the main disadvantages caused by the use of the chain. Extremely resilient (breaking load greater than a chain of 14 mm diameter), they are light and safe as they prevent damage to the gelcoat in case of impact and do not bring rust on board. Code Length mm Colour Breaking load kg 01.206.00 1.10 blue 11.800 01.206.01 1.70 blue 11.800
44 LEWMAR stainless steel anchor winches and spare parts \ FALL SAFE LEWMAR V700 windlass AISI 316 FALL SAFE IP67 Designed in 316 stainless steel and easy to install. No need to cut into the deck, just a hole saw is sufficient. Waterproof IP67 up to one meter. Shock-resistant motor cover. Chain lock integrated in the winch housing (see photo “fall safe”). Complete with: - control from the console; - Contactor; suitable for Lewmar anchor winches up to 700 W with 2 wires, models V-700; ProSeries. - magnetothermal protection; - clutch release lever; - fixing pins; - template and seal; - instructions in 6 languages (including Italian). Prepared for chain counter sensor. Code Motor Gypsy Pull kg Line speed m/min Current draw A Recommended circuit breaker A For boats Single parts V W chain Ø mm Line Ø mm max continuous max continuous Only gypsy Clutch lever Only solenoid 02.534.06 12 320 6 12 320 79 25 15 45 35 6 to 9 m 6.5 02.534.86 02.531.99 02.590.21 \ 02.534.12 \ 02.534.14/16 \ 02.534.18 \ 02.534.22 \ 02.534.20 Spare parts V700 Code Description 02.534.10 Chainpusher kit 02.534.12 Lid 02.534.14 Fixing kit (UDM inches) 02.534.16 Fixing kit (UDM metres) 02.534.18 Full Safe Kit 02.534.20 Kit of bearings and seals 02.534.22 Mast kit 02.534.24 Engine kit 02.534.26 Gearbox casing 02.534.28 Complete gear kit 02.534.34 Magnet and sensor kit \ 02.534.34 \ 02.534.26 \ 02.534.24
45 Winches and thrusters 02 LEWMAR PRO-Series 1000 windlass AISI 316 Mirror-polished AISI316 SS construction. Manual ascent system integrated via the multifunction lever included. Complete with: - control from the console; - Contactor; suitable for Lewmar anchor winches up to 700 W with 2 wires, models V-700; ProSeries. - magnetothermal protection; - clutch release lever; - quick-mount studs; - template and seal; - instructions in 6 languages (including Italian). It's the ideal product for construction sites seeking fast installation, quality, and style, perfect also for the aftermarket thanks to the all-inclusive package and easy assembly. Code Motor Gypsy Pull kg Line speed m/min Current draw A Recommended circuit breaker A For boats Single parts V W chain Ø mm Line Ø mm max continuous max continuous Only gypsy Clutch release lever Remote circuit breaker only 02.531.06 12 700 6 12 454 113 32 27 50 70 9 to 12 m 9.5 02.531.86 02.531.99 02.590.21 02.531.08 12 700 8 14/16 454 113 32 27 50 70 9 to 12 m 9.5 02.531.88 02.531.99 02.590.21 Pro-Series 1000 Spare Parts Code Description 02.531.78 Chainejector kit 02.531.80 Side cover gasket 02.531.82 Engine kit 02.531.84 Seal and screw kit \ 02.531.78 \ 02.531.80 \ 02.531.82 \ 02.531.84 Pro-Sport LEWMAR anchor windlass Sturdy central aluminium body and durable composite side covers. Ideal for boats up to 9 meters. Simple installation requiring only one hole for chain passage. Complete with: - Dashboard switch - Magnetothermal Protection - Clutch release lever - Quick-mount studs - Template and gasket - Instructions in 6 languages (including Italian). Code Motor Gypsy Pull kg Line speed m/min Current draw A Recommended magnetothermal protection A For boats V W chain Ø mm Line Ø mm max continuous max continuous 02.521.06 12 150 6 12 250 63 30 25 20 50 6 to 9 m 6.5 The kit includes: anchor winch, fastening pins, seal, installation tool, control panel and thermomagnetic switch.
