OSCULATI - RV Line RV Line Magnetic door stop When not in use, the plate automatically returns to a flat, recessed, obstacle-free position. AISI 316 FLUSH PATENTED (UTILITY MODEL) Magnetic door stop AISI 316 FLUSH PATENTED (UTILITY MODEL) Code 38.155.80 Magnetic doorstop consisting of two components: door block with 18° inclined magnet and ground block with retractable plate. The magnet lifts the plate when the door is approaching and the block is activated. When not in use, the plate automatically returns to a flat, recessed, obstacle-free position. Equipped with shock and anti-vibration gaskets and a set of 2 gaskets (2 mm and 4 mm) to adjust the ground block height as required. For 4 to 10 mm floor height doors stops.
1 RV Line OSCULATI - RV Line Deluxe 2 pull latch FLUSH ERGONOMIC AUTOMATIC OPEN Code 38.511.10 Handle with wide ergonomic grip equipped with automatic pull-out system and snap lock. For recess-fit mounting. Fitted with anti-vibration closing system. Fixing with M4 studs, no visible screws.
2 OSCULATI - RV Line RV Line \ 14.416.11 \ 14.416.01 \ 14.416.40 \ 14.416.02 \ 14.416.01 Cruiser 16A socket and plug 16A IP67 IEC 60309-5 Marine plug and socket for 16A - 230V shore power cord. Made of PA6, fitted with high energy efficiency contacts and IP67 cover. Plug designed for ergonomic grip, fastened to the boat socket through a rotating bezel. IP67 watertight closure. A rubber cap ensures IP44 tightness when unplugged. Simple and compact design for easy installation in any corner of the cockpit In compliance with the IEC 60309-5 European safety standards. Code Description Lid Base 14.416.02 Nylon plug Pa6 - - 14.416.01 Socket Nylon Pa6 Nylon Pa6 14.416.11 Socket Stainless steel Nylon Pa6 14.416.21 Socket Stainless steel Nylon Pa6 14.416.40 Socket Nylon Pa6 Nylon Pa6
3 RV Line OSCULATI - RV Line Retractable electric cable IP44 AISI 316 AUTOMATIC ROLLABLE Innovative electrical cable dock system. Hull hidden installation. Thanks to an automatic retractable dispenser the electrical cable is drawn from a box and directly connected to the dock pillar. To stow the cable, just unlock the seal and wait for the retractor to automatically rewind the extracted cable. Once the cable is stowed away, the system disappears inside the hull into an elegant mirror-polished stainless steel box that ensures IP44 airtight seal. The alignment between the winder and the bush can be oriented in any direction with a maximum recommended angle of 80°. Available in two versions with different cable capacities of 16A and 32A. Internal winder supplied with adjustable mounting brackets. Code Description A Cable length m Cable cross-section mm² V A mm B mm C mm 14.322.01 3P plug 16 15 3x2.5 230 220 400 150 Dock cable with braid and Cruiser plug 16A ROPE FEELING The electrical cable is sheathed in a special polyester cover for wear protection and nautical look. Equipped with a 16A Cruiser plug, boat side and a three-pole industrial plug, dock side. Code Length m A Ø outer cable mm Cable cross-sec tion mm² Dockside plug 14.416.60 10 16 12.4 2.5 14.335.01 14.416.61 15 16 12.4 2.5 14.335.01 Cruiser dock cable and plug 16A IP67 IEC 60309-5 Code Length m A Ø outer cable mm Cable cross-sec tion mm² Dockside plug 14.416.10 10 16 11.2 2.5 no 14.416.15 15 16 11.2 2.5 no 14.416.20 10 16 11.2 2.5 14.335.01 (16A) 14.416.25 15 16 11.2 2.5 14.335.01 (16A) \ 14.335.01
4 OSCULATI - RV Line RV Line Modular switches, sockets and plugs \ 14.520-533.xx \ 14.523-524-534.xx BERKER® original modular switches and sockets __logo__CE__ To be fitteded in FLOW single or double design frame models. Single frame: 59.5x59.5 mm. Double frame: 59.5x178.5 mm. \ 14.536.0x \ 14.533.01 + 14.527.01 Type Product Anthracite black white chromed Module 16A single switch 14.520.01 14.520.02 14.520.03 16A double switch 14.521.01 14.521.02 14.521.03 16A diverter 14.522.01 14.522.02 14.522.03 10A single push button 14.523.01* 14.523.02* 14.523.03* 10A double push button 14.524.01* 14.524.02* 14.524.03* 16A Italian power socket 14.525.01 14.525.02 - 16A Schuko power socket 14.526.01 14.526.02 - USB A+C port 3+3A 14.527.01 - - Flow frames Single frame 14.533.01 14.533.02 14.533.03 Double frame 14.534.01 14.534.02 14.534.03 Frame with spring hatch 14.536.01 14.536.02 14.536.03 * For push-button+dimmer operation (Art. 14.540.00 required). 14.538.01 White lower rear protection cover, 22-mm protrusion, suitable for all modules 14.520/521/522/523/524. 14.538.02 High protection rear cover, white color, 45 mm protrusion, suitable for modules 14.525/526/527.01. 14.538.03 Spacer required for 14.520/521/522/523/524 modules installation without recess. Colour: black anthracite. 14.538.04 Spacer required for 14.520/521/522/523/524 modules installation without recess. Colour: white. 14.540.00 Mono channel mini dimmer: operates on multi-voltage from 5V to 24V DC. To be used with 14.523/14.524.xx push-buttons or similar to adjust the brightness of ceiling lights/spotlights with incandescent or LED bulbs (when fitted). Maximum load 192W (24V). \ 14.521-524.01 \ 14.521-524.02 \ 14.527.01 \ 14.526.01 \ 14.525.01 \ 14.525.02 \ 14.533.01 \ 14.533.02 \ 14.534.01 \ 14.534.02 \ 14.534.03 \ 14.536.01 \ 14.538.01 \ 14.538.02 \ 14.538.03 \ 14.538.04 \ 14.540.00 \ 14.533.03 \ 14.536.02 \ 14.526.02 \ 14.521-524.03 Switches and circuit breakers \ 14.315.01/05 \ 14.315.02/06 \ 14.315.03/07 FLAT stainless steel switches 12/24V 12/24V SS316 LONG PIN Vandal-proof FLAT switches with AISI 316 stainless steel body, manufactured with CNC. Compatible with 12V and 24V systems and have a capacity of 20A. Protection rating IP67. LED light ring in 3 different colors. Available in variants with standard ON-OFF and momentary ON. White LED Red LED Blue LED Function V A 14.315.01 14.315.02 14.315.03 ON-OFF 12/24 20 14.315.05 14.315.06 14.315.07 (ON momentary)-OFF 12/24 20 \ 14.536.03 \ 14.520-522-523.03 \ 14.520-522-523.01 \ 14.520-522-523.02
5 RV Line OSCULATI - RV Line Battery switches Compact battery switch Supercompact model for mounting on instrument panel or bulkhead. Positions: OFF-ON-OUT to pull out the antitheft knob. Code Max capacity A Neck Ø mm Flange Ø mm Useful neck mm Ø Terminals mm in continuous intermittent 14.385.20 100 150 26 45 11 6 14.385.22 300 450 49 55 15 10 \ 14.385.22 \ 14.385.22 \ 14.385.20 \ 14.385.20 Fairleads and glands SCANSTRUT horizontal stuffing box Made of fiberglass-reinforced nylon. IPX7 watertight. Supplied with pre-drilled seal and seal to be drilled. Display blister pack. No sealant or silicone required for quick and clean installation. The dual cable version is perfect for solar panels installation. Code Model Colour Material Cable Ø mm AxBxH mm Outlets 14.171.42 DS-H6 grey Plastic 2-6 28.5x46x20 1 14.171.62 DS-H10 grey Plastic 6-10 44x78x27 1 14.176.01 DS-HD6-BLK Black Plastic 2-5/6 54x63x22 2 14.176.03 DS-HD6 grey Plastic 2-5/6 54x63x22 2 14.176.02 DS-HD10-BLK Black Plastic 6-10 66.5x75.1x28.25 2 14.176.04 DS-HD10 grey Plastic 6-10 66.5x75.1x28.25 2 14.176.10 DS-H-MULTI Black Plastic up to 15 114,8x97,6x35,8 Multi-cable \ 14.171.42/62 \ 14.176.01/02/03/04 \ 14.171.42 \ 14.171.62 \ 14.176.01/02 \ 14.176.10 \ 14.176.03/04 \ 14.176.10 Plugs, lighter jacks and accessories ROKK NEST recess-fit waterproof wireless charging pocket - 3-coil 15W IPX6 Wireless battery charging pocket for bulkhead recess-fit mounting. To be integrated on consoles, seats, cushions, etc. Just place your mobile phone on the grippy mat to instantly start wireless charging. No charging cable required. 12/24V charging. Compatible with any phone having a non-metallic casing at least 3mm thick. Qi wireless charging technology (Apple, Samsung, Huawei, etc). IPX6 waterproof. Fitted with a water drainage system, it can also be used as a storage compartment. The NEST charger features 3-coil technology that ensures a charging area over 80% larger than previous versions. This implementation is the best one for mobiles with very powerful camera phones (15 W output power). Code Input V Output W mm 14.515.26 12/24 15 142x106x157 (recess)
6 OSCULATI - RV Line RV Line Showers and deck showers Shower/Tap Removable Kit Hand shower with PVC hose and quick connector for gardening. Designed to provide fast connections and versatile solutions, it is compatible with water outlets featuring quick connect. Usable both as a handheld shower and a tap, it connects and removes easily after use. Code Length m Terminal joints For hose connectors Support for the tap 15.211.00 2.5 1/2" F + Quick Coupling for Gardening 16.441.18. 16.441.38. 16.441.75. 16.441.88.16.441.95. 16.442.60. 16.442.61. 16.442.70. 16.442.71. 16.443.00. 16.444.00 17.019.02 \ 17.019.02 Mizar spare shower head Code Model Material 15.242.02 Push-button Brass + plastic Desy spare shower head Code Model Material 15.238.03 Lever-operated Chromed plastic Spare shower head Code Model Material 15.256.02 Lever-operated Chromed plastic Keji spare shower head Code Model Material 15.237.02 Push-button Chromed plastic Tiger spare shower head Code Model Material 15.247.02 Lever-operated Stainless steel White net PVC shower hose "Full white" model more elegant than the traditional net version. Code Length m Terminal joints 15.210.00 2.5 1/2" F + 3/8" F 15.210.01 4 1/2" F + 3/8" F White nylon net shower hose Made of nylon, with EPDM inside. Compared to net PVC hoses, it's extremely flexible and can be positioned more easily in its housing. Code Length m Terminal joints 15.198.00 2.5 1/2" F + 3/8" F 15.198.01 4 1/2" F + 3/8" F Polished stainless steel shower hose Made of stainless steel with EPDM inside. Compared to net PVC hoses, it's extremely flexible and can be positioned more easily in its housing. Code Length m Terminal joints 15.199.00 2.5 1/2" F + 3/8" F 15.199.01 4 1/2" F + 3/8" F
7 RV Line OSCULATI - RV Line Europump fresh water pumps Europump 4 low-consumption fresh water pump Can serve 2 connections. Thermal protection against overloads. Can run dry without damage. Protection against polarity reversal. Code Pressure switch Flow l/min Current draw A Hose adaptor Ø mm Maximum dimensions in mm Pressure switch spare parts calibrated to 16.503.12 2,8 BAR/40 PSI 3.8 2 10 170x100x60 16.540.01 0.7 Europump 4 New Generation fresh water pump IP 54 It can serve two outlets. Overload protection. It can run dry without getting damaged. IP54 watertight. Self-priming up to 1.5 metres. Pulsation-dampening by-pass system. Code V Current draw A Flow l/min Operating pressure bar Snap hose holder mm 16.501.12 12 4.5 5.6 2.8 10 0.7 Hose connectors and water hook-ups Bayonet flush fitting for washdown The device connects under deck to Washdown pumps or similar items and it keeps the pump under pressure. When the bayonet fitting connects the washing hose, the device automatically opens and activates the pump. 100% stainless steel. Garden-type quick fitting on the end caps (36.189.02). Code Description Replacement plastic fitting 16.442.22 Bayonet fitting + straight plastic fitting 16.442.31 (right) 16.442.23 Bayonet fitting + sloped plastic fitting 16.442.30 (inclined) The sloped fitting makes opening easier in case of high-pressure washdown pumps or when the fitting is in a position difficult to plug. \ 16.442.31 \ 16.442.31 \ 16.442.30 \ 16.442.22 + 16.442.31 \ 16.442.23 + 16.442.30
8 OSCULATI - RV Line RV Line \ 16.441.55 \ 16.441.55 \ 16.441.95 \ 16.441.75 Classic EVO quick-coupling washdown hose connector It connects the onboard fresh water system or to the washdown salt water pump and it keeps the line under pressure. The washing hose plugs in onto the inlet and automatically activates the pump. UV resistant ASA box, chromed brass device. white chromed SS mm Ø Recess Internal protrusion 16.441.55 16.441.75 16.441.95 69 43 17.224.01 OPTIONAL 1/2” male elbow fitting to plug into rear inlet hose 36.189.01; 36.189.03; 36.189.04 OPTIONAL Front male plug-in fitting \ 16.441.95 \ 16.445.53 Heavy Duty Classic Evo recess-fit fresh water inlet QUICK SWIVEL CONNECTION PRESSURE REDUCING VALVE For the use of dockside water, this innovative system stably reduces the pressure to 3 bar, protecting the piping from potential damage. The compact device, equipped with an adjustable pressure regulator and orientable brass check valve, ensures a safe and constant flow. The dockside water hose can be easily connected using a gardening snap fitting (code 36.189.02). The outlet thread is 3/4" BSP. Even if the system remains connected to the dock, the pressure is maintained stable at 3 bar, regardless of the supply network pressure. white chromed SS mm Ø Recess Internal protrusion 16.445.53 16.445.73 16.445.83 69 110-110 \ 16.445.73 \ 16.445.83 Push to close latches \ 38.147.00 \ 38.147.20 \ 38.147.21 \ 38.147.01 Plastic flush pull latches Made of white nylon, fitted with stainless steel lock stopper and two 2 mm stoppers. Code Version Colour Recess Ø mm External Ø mm Inner size mm Accepts thicknesses mm 38.147.00 without lock white 49.6 61.4 38.8 from 7 to 18 38.147.01 without lock Black 49.6 61.4 38.8 from 7 to 18 38.147.20 With lock white 49.6 61.4 38.8 from 7 to 18 38.147.21 With lock Black 49.6 61.4 38.8 from 7 to 18 \ 38.147.20
RV Line OSCULATI - RV Line Lift and turn latches 38.161.XX Characterized by a particularly easy grip, they enclose all the best features of the pull latches in a single model. AVAILABLE Ergonomic nut for easy calibration and emergency exit It can be closed every 90 (360 rotation) Casted cam Optional key lock AISI 316 Stainless steel Waterproof Open/close indicator Large ergonomic handle Flush deck design Handle can be lowered every 90 The threaded shaft allows the adjustment at any height Adaptable spacer Key LIFT & TURN compression latch Eclipse LIFT & TURN flush latch (with compression closure) - SMALL COMPRESSION SYSTEM EXTRA LARGE HANDLE Featuring a very comfortable grip, it offers all the best characteristics in a single flush deck design model. - 316 mirror-polished stainless steel; - flush aesthetics; - large ergonomic handle; - Handle can be lowered every 90°. - Foldable handle every 90°; - visual indicator open/closed; - ergonomic nut for easy calibration and allowing for emergency exit; - straight cam suitable for sliding door closure; - cam with two possible positions; - plastic spacer with invitations for custom cutting. Polished SS version Black SS version Lock External Ø mm Bore Ø mm Bulkhead thickness mm Stop stroke mm 38.161.01 38.161.61 no 60 50 3-26 22-94 38.161.02 38.161.62 Yes 60 50 3-26 22-94 \ Angled cam included 64 80 54 70 \ Universal straight cam included \ Key for 38.161.02 \ 38.161.01 \ 38.161.02 \ 38.161.61 \ 38.161.62 \ Spacer included 9
10 OSCULATI - RV Line RV Line Table pedestals and legs Coated aluminium table pedestal White epoxy coated finish. It includes two aluminium bases (one external and one for flush mounting) model 48.418.01 and an anodized aluminium tube model 48.418.21. Code Height mm Tube Ø mm Tube Table base Ø mm Floor recess base Base Spare floor base Spare table base 48.418.22 700 60 White painted aluminium 165 160 White painted aluminium 48.416.12 48.416.13 White epoxy coated. HEAVY DUTY Giant table pedestal GAS SPRING / MOLLA A GAS Made of mirror-polished anodized aluminium. Fitted with gas spring for upstroke. No need to bore the floor for downstroke. Tri-telescopic. Code Height mm Tube Ø mm Extra-flat base Ø mm Table plate mm OPTIONAL extension kit 48.720.01 345/714 100/88/72 305 305x305 48.724.01; 48.724.02 Giant Heavy Duty black table pedestal Made of black anodized aluminium with black plastic fastening collars for a total black effect. Fitted with gas spring for upstroke, no need to bore the floor for downstroke. Tri-telescopic. Code Height mm Tube Ø mm Extra-flat base Ø mm Table plate mm OPTIONAL extension kit 48.720.04 345/714 100/88/72 305 305x305 48.724.01; 48.724.02 Water heaters and accessories 12V Mini boat boiler 12V Mini boiler for boats in AISI 316L stainless steel, impact-resistant, with thermal insulation in polyurethane foam. Equipped with an incoloy heating element and a probe sheath that allows the water temperature inside the boiler to be detected via thermostat. Supplied with safety valve and adjustable brackets. Code Volume litres V W LxØ mm 50.589.06 6 12 300 459x190 4.1
11 RV Line OSCULATI - RV Line OSCULATI refrigerators Fridge Frigo° with clean touch front panel Versatile and compact fridges. Easily installed in any boat or vehicle. Features a convenient freezer compartment. Equipped with a high-performance compressor and low energy consumption, with internal control command to adjust the temperature and an antifingerprint treated, anodized brushed aluminum door panel. Reversible door opening. Available finishing frames that allow flush or protruding installation. Code Capacity l V mm OPTIONAL frame Width depth Height 50.961.00 50 12/24 380 500 535 17 50.961.30 50.961.02 85 12/24 475 555 635 21 50.961.32 \ 50.961.00 \ 50.961.02 Integrated crystal glass/stainless steel hob units Cooktops with steel glass lid Stainless steel cooktops with smoked tempered glass lid, complete with hot and cold water mixer tap. Code With sink No of burners mm Burners W OPTIONAL pot holder outside inside recess depth 50.714.01 right 1 526x326 515x325 163 1800 50.100.91 50.714.02 left 1 526x326 515x325 163 1800 50.100.91 50.714.03 right 2 726x346 688x319 140 1800+1000 50.100.92 50.714.04 left 2 720x346 688x319 140 1800+1000 50.100.92 \ 50.100.92 \ 50.100.91 \ 50.714.01/02 \ 50.714.03 \ 50.714.01 \ 50.714.02 \ 50.714.03 \ 50.714.04
12 OSCULATI - RV Line RV Line Water tanks \ 52.194.21/22 \ 52.194.21/22 Tank with fresh water pump, can be rotated by 90° Polyethylene tank already assembled with fresh water pump type 16.503.12. Recommended for one outlet. When rotated at 90°, it height varies from 34 to 26 cm according to your needs. Code Capacity Capacity l Fresh water tank oulet Ø mm Inlet joint Ø mm Vent Ø mm Bracket Standard thickness mm +/- 5%* outside mm 52.194.21 3.8 l/min at 12 V 31 10 38 16 52.195.00 4 400x260x340 52.194.22 3.8 l/min at 12 V 48 10 38 16 52.195.00 4 600x260x340 Can be installed with base 340x400 (height 260 mm) or base 400x260 (height 340 mm). Made-ready for bracket mounting 52.195.00. * Our fresh water tank thickness is calculated for standard use of tanks to be installed on leisure boats. The installer or the designer shall be responsible for checking that both the tanks and their mounting systems comply with the required use. Technical support shall be requested, if necessary. The option to require on demand tanks increased in thickness. \ 52.195.00 \ 52.194.21/22 Electric inflator pumps ATMOS Integrated Air Station 12V IPX6 INFLATE/DEFLATE IGNITION PROTECTION The built-in ATMOS onboard inflator combines a high airflow able to reach high pressures (20 psi / 1.37 Bar). Suitable for any type of inflatable: tender, SUP, towables Waterproof (IPX6) and designed to withstand harsh marine environmental conditions. The next-generation technology provides fast and effortless inflation and deflation. Compact and flat, ATMOS fits almost all panels on board. It comes with inflation tube (2.5 mt.) and a universal valve fittings kit. User-friendly and ready for use: you just have to set the target pressure on the display and start it. The inflator automatically stops when the desired pressure is reached. ATMOS is ignition protection certiifed (ISO 8846), allowing the inflator to be installed near boat areas containing flammable gases or fuel. It complies with EMC CE-RED directive (2014/53/EU) and EN 62368 standard. Comes with a comfortable and durable Storage Bag complete with accessories. Average inflation time for SUP: 6-8 minutes. Certifications: CE, ROHS, UN ECE R10, UKCA Compliant with standards: ISO 8846 and SAE J1171 Code Scanstrut Code Function V W A Max pressure Flowrate / Pressure Installation angle mm 66.452.01 SCAOB-A2 Inflation+deflation 12 140 12 1.37 BAR (20 PSI) 350 l/min (0-1 PSI) - 70 l/min (1-20 PSI) +10° to -30° 297x123x198 66.452.10Sun Cover white ATMOS optional to the black one. \ 66.452.10
